Avalue

3.5 Inch Intel Atom X6425RE Rugged Elkhart Lake SBC

ECM-EHL3

3.5 Inch Intel Atom X6425RE Rugged Elkhart Lake SBC

Available in 4 variations

View ECM-EHL3-X25RE-A1R ECM-EHL3 Datasheet

View ECM-EHL3-X13E-A1R ECM-EHL3 Datasheet

View ECM-EHL3-J6413-A1R ECM-EHL3 Datasheet

View ECM-EHL3-J6412-A1R ECM-EHL3 Datasheet

ECM-EHL3

Available in 4 variations

CPU: Atom X Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x LVDS, 2x Display Port
Ethernet: 1 x 2.5 GbE LAN [RJ45], 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A], 4 x USB 2.0 [Board]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe] [2242/2260]
Storage: 1x SATA Port, 2x M.2 SSD
Power: 9-36V DC Input [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

CPU: Atom X Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x LVDS, 2x Display Port
Ethernet: 1 x 2.5 GbE LAN [RJ45], 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A], 4 x USB 2.0 [Board]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe] [2242/2260]
Storage: 1x SATA Port, 2x M.2 SSD
Power: 9-36V DC Input [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

CPU: Celeron J Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x LVDS, 2x Display Port
Ethernet: 1 x 2.5 GbE LAN [RJ45], 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A], 4 x USB 2.0 [Board]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe] [2242/2260]
Storage: 1x SATA Port, 2x M.2 SSD
Power: 9-36V DC Input [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

CPU: Celeron J Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x LVDS, 2x Display Port
Ethernet: 1 x 2.5 GbE LAN [RJ45], 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A], 4 x USB 2.0 [Board]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe] [2242/2260]
Storage: 1x SATA Port, 2x M.2 SSD
Power: 9-36V DC Input [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

Avalue

11th Gen Intel Core i3 Wide Temp 3.5 Inch Single Board Computer

ECM-TGU

11th Gen Intel Core i3 Wide Temp 3.5 Inch Single Board Computer

Available in 7 variations

View ECM-TGU-15W-A1R ECM-TGU Datasheet

View ECM-TGU-45W-A1R ECM-TGU Datasheet

View ECM-TGU-85W-A1R ECM-TGU Datasheet

View ECM-TGU-15-A1R ECM-TGU Datasheet

View ECM-TGU-45-A1R ECM-TGU Datasheet

View ECM-TGU-85-A1R ECM-TGU Datasheet

View ECM-TGU-6305-A1R ECM-TGU Datasheet

ECM-TGU

Available in 7 variations

CPU: 11th Gen Tiger Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x eDP, 2x Display Port, 2x LVDS
Ethernet: 1 x 2.5 GbE LAN [RJ45], 2 x GbE LAN [RJ45]
USB: 4 x USB 2.0 [Board], 4 x USB 3.2 Gen 2 [Type A]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 B-Key [PCIe/USB/SATA] [2242], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2242]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12-24V DC [Terminal Block]
Temp: -20°C to 60°C [-4°F to 147°F]
Certification: CE, FCC

CPU: 11th Gen Tiger Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x eDP, 2x Display Port, 2x LVDS
Ethernet: 1 x 2.5 GbE LAN [RJ45], 2 x GbE LAN [RJ45]
USB: 4 x USB 2.0 [Board], 4 x USB 3.2 Gen 2 [Type A]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 B-Key [PCIe/USB/SATA] [2242], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2242]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12-24V DC [Terminal Block]
Temp: -20°C to 60°C [-4°F to 147°F]
Certification: CE, FCC

CPU: 11th Gen Tiger Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x eDP, 2x Display Port, 2x LVDS
Ethernet: 1 x 2.5 GbE LAN [RJ45], 2 x GbE LAN [RJ45]
USB: 4 x USB 2.0 [Board], 4 x USB 3.2 Gen 2 [Type A]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 B-Key [PCIe/USB/SATA] [2242], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2242]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12-24V DC [Terminal Block]
Temp: -20°C to 60°C [-4°F to 147°F]
Certification: CE, FCC

CPU: 11th Gen Tiger Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x eDP, 2x Display Port, 2x LVDS
Ethernet: 1 x 2.5 GbE LAN [RJ45], 2 x GbE LAN [RJ45]
USB: 4 x USB 2.0 [Board], 4 x USB 3.2 Gen 2 [Type A]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 B-Key [PCIe/USB/SATA] [2242], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2242]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12-24V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

CPU: 11th Gen Tiger Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x eDP, 2x Display Port, 2x LVDS
Ethernet: 1 x 2.5 GbE LAN [RJ45], 2 x GbE LAN [RJ45]
USB: 4 x USB 2.0 [Board], 4 x USB 3.2 Gen 2 [Type A]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 B-Key [PCIe/USB/SATA] [2242], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2242]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12-24V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

CPU: 11th Gen Tiger Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x eDP, 2x Display Port, 2x LVDS
Ethernet: 1 x 2.5 GbE LAN [RJ45], 2 x GbE LAN [RJ45]
USB: 4 x USB 2.0 [Board], 4 x USB 3.2 Gen 2 [Type A]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 B-Key [PCIe/USB/SATA] [2242], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2242]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12-24V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

CPU: Celeron 6000 Series Tiger Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x eDP, 2x Display Port, 2x LVDS
Ethernet: 1 x 2.5 GbE LAN [RJ45], 2 x GbE LAN [RJ45]
USB: 4 x USB 2.0 [Board], 4 x USB 3.2 Gen 2 [Type A]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 B-Key [PCIe/USB/SATA] [2242], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2242]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12-24V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

Avalue

Tiger Lake Intel Core i5 Embedded Single Board Computer

ECM-TGUC

Tiger Lake Intel Core i5 Embedded Single Board Computer

Available in 2 variations

View ECM-TGUC-35-A1R ECM-TGUC Datasheet

ECM-TGUC

Available in 2 variations

CPU: 11th Gen Tiger Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 2x Display Port, 2x eDP, 2x LVDS
Ethernet: 1 x 2.5 GbE LAN [RJ45], 1 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Type A], 3 x USB 3.2 Gen 2 [Type A], 4 x USB 2.0 [Board]
Serial: 1 x RS232/422/485 [Board], 5 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SIM] [2242/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4] [2280]
Storage: 1x SATA Port, 2x M.2 SSD
Power: 12V DC [Barrel Connector]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

Avalue

Pico ITX Industrial Motherboard with Elkhart Lake Atom X6413E CPU

EPX-EHLP

Pico ITX Industrial Motherboard with Elkhart Lake Atom X6413E CPU

Available in 3 variations

View EPX-EHLP-X13E-A1R EPX-EHLP Datasheet

View EPX-EHLP-J6413-A1R EPX-EHLP Datasheet

View EPX-EHLP-J6412-A1R EPX-EHLP Datasheet

EPX-EHLP

Available in 3 variations

CPU: Atom X Series Elkhart Lake
Memory: 1x DDR4 2666MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x LVDS, 2x Display Port
Ethernet: 1 x 2.5 GbE LAN [RJ45], 1 x GbE LAN [RJ45]
USB: 2 x USB 3.1 Gen 1 [Type A], 4 x USB 2.0 [Board]
Serial: 1 x RS232 [Board], 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 1x M.2 SSD
Power: 12V DC [Barrel Connector]
Temp: -20°C to 60°C [-4°F to 147°F]
Certification: CE, FCC

CPU: Celeron J Series Elkhart Lake
Memory: 1x DDR4 2666MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x LVDS, 2x Display Port
Ethernet: 1 x 2.5 GbE LAN [RJ45], 1 x GbE LAN [RJ45]
USB: 2 x USB 3.1 Gen 1 [Type A], 4 x USB 2.0 [Board]
Serial: 1 x RS232 [Board], 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 1x M.2 SSD
Power: 12V DC [Barrel Connector]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

CPU: Celeron J Series Elkhart Lake
Memory: 1x DDR4 2666MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x LVDS, 2x Display Port
Ethernet: 1 x 2.5 GbE LAN [RJ45], 1 x GbE LAN [RJ45]
USB: 2 x USB 3.1 Gen 1 [Type A], 4 x USB 2.0 [Board]
Serial: 1 x RS232 [Board], 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 1x M.2 SSD
Power: 12V DC [Barrel Connector]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

Avalue

Industrial Femto-ITX Motherboard with Elkhart Lake Atom X6413E CPU

EZX-EHLP

Industrial Femto-ITX Motherboard with Elkhart Lake Atom X6413E CPU

Available in 3 variations

View EZX-EHLP-X13E-A1R EZX-EHLP Datasheet

View EZX-EHLP-J6413-A1R EZX-EHLP Datasheet

View EZX-EHLP-J6412-A1R EZX-EHLP Datasheet

EZX-EHLP

Available in 3 variations

CPU: Atom X Series Elkhart Lake
Memory: 4GB Soldered On-board
OS: Linux, Windows 10
Display Outputs: 1x eDP, 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 3.1 Gen 1 [Type A], 4 x USB 2.0 [Board]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 1x M.2 SSD
Power: 12V DC [Terminal Block]
Temp: -40°C to 85°C [-40°F to 185°F]
Certification: CE, FCC

CPU: Celeron J Series Elkhart Lake
Memory: 4GB Soldered On-board
OS: Linux, Windows 10
Display Outputs: 1x eDP, 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 3.1 Gen 1 [Type A], 4 x USB 2.0 [Board]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 1x M.2 SSD
Power: 12V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

CPU: Celeron J Series Elkhart Lake
Memory: 4GB Soldered On-board
OS: Linux, Windows 10
Display Outputs: 1x eDP, 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 3.1 Gen 1 [Type A], 4 x USB 2.0 [Board]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 1x M.2 SSD
Power: 12V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

Avalue

Intel Atom X6425RE Elkhart Lake 3.5″ Rugged Single Board Computer

ECM-EHL

Intel Atom X6425RE Elkhart Lake 3.5″ Rugged Single Board Computer

Available in 4 variations

View ECM-EHL-X25RE-A1R ECM-EHL Datasheet

View ECM-EHL-X13E-A1R ECM-EHL Datasheet

View ECM-EHL-J6413-A1R ECM-EHL Datasheet

View ECM-EHL-J6412-A1R ECM-EHL Datasheet

ECM-EHL

Available in 4 variations

CPU: Atom X Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x eDP, 1x HDMI
Ethernet: 1 x 2.5 GbE LAN [RJ45], 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [DB9], 3 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC Input [Terminal Block]
Temp: -40°C to 85°C [-40°F to 185°F]
Certification: CE, FCC

CPU: Atom X Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x eDP, 1x HDMI
Ethernet: 1 x 2.5 GbE LAN [RJ45], 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [DB9], 3 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC Input [Terminal Block]
Temp: -40°C to 85°C [-40°F to 185°F]
Certification: CE, FCC

CPU: Celeron J Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x eDP, 1x HDMI
Ethernet: 1 x 2.5 GbE LAN [RJ45], 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [DB9], 3 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC Input [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC

CPU: Celeron J Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x eDP, 1x HDMI
Ethernet: 1 x 2.5 GbE LAN [RJ45], 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [DB9], 3 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC Input [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC
