US Intel Elkhart Lake Motherboards
Intel Elkhart Lake motherboards represent a new phase in embedded computing, showcasing impressive features and outstanding performance. These industrial motherboards take advantage of Intel’s Elkhart Lake processor design, offering exceptional processing power and efficient energy usage. With a remarkable 1.7 times increase in single-thread performance and a 1.5 times improvement in multi-thread performance compared to older models, our Elkhart Lake embedded motherboards, equipped with Atom X6000E, Pentium, and Celeron CPUs, effortlessly manage demanding tasks in industrial automation, manufacturing, kiosk computing, and smart robotics.
// LOADING...
- CPU: Intel Celeron J Series Elkhart Lake
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
- OS: Linux, Windows 11
- Display Outputs: 1x Display Port, 1x HDMI, 1x LVDS
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 2.0 [Board], 3x USB 2.0 [Type A], 3x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232 [Board], 1x RS232/422/485 [Board]
- M.2: 1x M.2 B-Key [3042], 1x M.2 E-Key [2230], 1x M.2 M-Key [PCIe] [2280]
- Storage: 1x M.2 SSD, 1x SATA Port
- Power: 12-24V DC [Barrel Connector]
- Temp: 0°C to 60°C [32°F to 140°F]
-
EMX-EHLP-X25RE-A1R
EMX-EHLP with Intel Atom x6425RE, quad 2.5GbE, ECC and -20 to 60 °C -
EMX-EHLP-J12-A1-1R
EMX-EHLP with Intel Celeron J6412 and dual 2.5GbE -
EMX-EHLP-J6412-A1R
EMX-EHLP with Intel Celeron J6412 and quad 2.5GbE -
EMX-EHLP-J6413-A1R
EMX-EHLP with Intel Celeron J6413 (Elkhart Lake) and quad 2.5GbE -
EMX-EHLP-X13E-A1R
EMX-EHLP with Intel Atom x6413E, quad 2.5GbE, ECC and -20 to 60 °C
- Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
- OS: Linux, Windows 10
- Display Outputs: 1x Display Port, 1x HDMI, 1x LVDS
- USB: 2x USB 3.1 Gen 1 [Type A], 2x USB 3.1 Gen 2 [Type A], 4x USB 2.0 [Board]
- Serial: 2x RS232/422/485 [Board], 4x RS232 [Board]
- M.2: 1x M.2 B-Key [USB 3.1 Gen 2/USB 2.0/SATA/SIM] [2242/2260/2280/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
- Storage: 1x M.2 SSD [SATA], 2x SATA Ports
- Power: 12-24V DC Input [4-Pin], 12-24V DC [Barrel Connector]
- Certification: CE, FCC, RoHS
- CPU: Intel Atom X Series Elkhart Lake
- Ethernet: 4x 2.5 GbE LAN [RJ45]
- Temp: -20°C to 60°C [-4°F to 140°F]
- Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB, 4GB Soldered On-board, 8GB Soldered On-board
- OS: Linux
- Display Outputs: 1x Display Port, 1x VGA
- Serial: 2x RS232 [Board], 2x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [PCIe/USB 3.0/SIM] [3042/3052], 1x M.2 E-Key [USB/PCIe] [2230], 1x M.2 M-Key [USB 2.0/SATA] [2280]
- Storage: 1x M.2 SSD, 1x SATA Port
- Power: 9-36V DC [4-Pin], 9-36V DC [Barrel Connector]
- Certification: CE, FCC
- CPU: Intel Atom X Series Elkhart Lake
- Ethernet: 1x 2.5 GbE LAN [RJ45], 3x GbE LAN [RJ45]
- USB: 3x USB 2.0 [Board], 2x USB 3.1 [Type A]
- Temp: -40°C to 80°C [-40°F to 176°F]
-
EHL051-BCD-N6210
EHL051 with Intel Celeron N6210, two cores at 6.5~W, HDMI and LVDS -
EHL051-BCD-J6412
EHL051 with Intel Celeron J6412, four cores, HDMI and LVDS, -5 to 65~°C -
EHL051-TCD-6211E
EHL051 with Intel Atom x6211E, two cores at 6~W and -40 to 85~°C -
EHL051-TCD-6214RE
EHL051 with Intel Atom x6214RE, two cores at 6~W and -40 to 85~°C -
EHL051-TCD-6413E
EHL051 with Intel Atom x6413E, four cores at 9~W and -40 to 85~°C -
EHL051-TCD-6416RE
EHL051 with Intel Atom x6416RE, four cores at 9~W and -40 to 85~°C -
EHL051-TCD-6425E
EHL051 with Intel Atom x6425E, four cores up to 3.0~GHz and -40 to 85~°C -
EHL051-TCD-6425RE
EHL051 with Intel Atom x6425RE, four cores, in-band ECC and -40 to 85~°C
- Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
- OS: Linux, Windows 11
- Display Outputs: 1x HDMI, 1x LVDS
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 2.0 [Board], 2x USB 3.2 Gen 2 [Type A]
- Serial: 2x RS232/422/485 [Board]
- M.2: 1x M.2 B-Key [PCIe/USB 3.0/SIM] [2242/3042], 1x M.2 E-Key [USB/PCIe] [2230]
- Storage: 1x M.2 SSD, 1x SATA Port
- Power: 12V DC [Terminal Block]
- Certification: CE, FCC, KC, RoHS, UKCA
- CPU: Intel Celeron N Series Elkhart Lake
- Temp: -5°C to 65°C [23°F to 149°F]
- CPU: Intel Atom X Series Elkhart Lake
- Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
- OS: Linux
- Display Outputs: 1x HDMI, 1x LVDS, 1x VGA
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 2.0 [Board], 2x USB 2.0 [Type A], 2x USB 3.2 Gen 1 [Type A]
- Serial: 1x RS232 [Board], 2x RS232/422/485 [Board]
- M.2: 1x M.2 B-Key [PCIe/SATA/USB/SIM] [3042]
- mPCIe: 1x mPCIe [PCIe/USB/SIM]
- Storage: 1x M.2 SSD, 1x SATA Port
- Power: 12-24V DC Input [4-Pin]
- Temp: -40°C to 80°C [-40°F to 176°F]
- Certification: CE, FCC, UKCA
- CPU: Intel Atom X Series Elkhart Lake
- Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
- OS: Linux
- Display Outputs: 1x HDMI, 1x LVDS, 1x VGA
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 2.0 [Board], 2x USB 2.0 [Type A], 2x USB 3.2 Gen 1 [Type A]
- Serial: 1x RS232/422/485 [Board], 3x RS232 [Board]
- M.2: 1x M.2 B-Key [PCIe/SATA/USB/SIM] [3042]
- mPCIe: 1x mPCIe [PCIe/USB/SIM]
- Storage: 1x M.2 SSD, 1x SATA Port
- Power: 12-24V DC Input [4-Pin]
- Temp: 0°C to 60°C [32°F to 140°F]
- Certification: CE, FCC, UKCA
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
- OS: Linux, Windows 10
- Display Outputs: 1x Display Port, 1x eDP, 1x HDMI, 1x LVDS
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 2x USB 3.1 Gen 1 [Type A], 2x USB 3.2 Gen 2 [Type A], 4x USB 2.0 [Board]
- Serial: 2x RS232/422/485 [Board], 4x RS232 [Board]
- M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/2280/3042], 1x M.2 E-Key [PCIe/USB] [3042/3052]
- PCIe: 1x PCIe [x4 Slot]
- Storage: 1x M.2 SSD, 2x SATA Ports
- Power: 9-36V DC [Barrel Connector]
- Certification: CE, FCC, UKCA
- CPU: Intel Celeron J Series Elkhart Lake
- Temp: -5°C to 65°C [23°F to 149°F]
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
- OS: Linux, Windows 10
- Display Outputs: 1x Display Port, 1x eDP, 1x HDMI, 1x LVDS
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 2x USB 3.1 Gen 1 [Type A], 2x USB 3.2 Gen 2 [Type A], 4x USB 2.0 [Board]
- Serial: 2x RS232/422/485 [Board], 4x RS232 [Board]
- M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/2280/3042], 1x M.2 E-Key [PCIe/USB] [3042/3052]
- PCIe: 1x PCIe [x4 Slot]
- Storage: 1x M.2 SSD, 2x SATA Ports
- Power: 12V DC [Barrel Connector]
- Certification: CE, FCC, UKCA
- CPU: Intel Celeron J Series Elkhart Lake
- Temp: -5°C to 65°C [23°F to 149°F]
- Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
- OS: Linux, Windows 10
- Display Outputs: 1x LVDS, 2x Display Port
- Ethernet: 1x 2.5 GbE LAN [RJ45], 2x GbE LAN [RJ45]
- USB: 2x USB 2.0 [Type A], 2x USB 3.1 Gen 1 [Type A], 4x USB 2.0 [Board]
- Serial: 2x RS232/422/485 [Board], 4x RS232 [Board]
- M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe] [2242/2260]
- Storage: 1x SATA Port, 2x M.2 SSD
- Power: 9-36V DC Input [Terminal Block]
- Temp: 0°C to 60°C [32°F to 140°F]
- Certification: CE, FCC
- CPU: Intel Atom X Series Elkhart Lake
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
- OS: Linux, Windows 11
- Display Outputs: 1x eDP, 1x HDMI, 1x LVDS, 1x VGA
- Ethernet: 2x GbE LAN [RJ45]
- USB: 1x USB 2.0 [Board], 1x USB 2.0 [Type A], 1x USB 3.2 Gen 1 [Board], 1x USB 3.2 Gen 2 [Type A], 4x USB 2.0 [Board]
- Serial: 1x RS232/422/485 [Board], 3x RS232 [Board]
- M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe] [2280/3042/3060]
- Storage: 1x M.2 SSD, 1x SATA Port
- Power: 9-36V DC Input [Terminal Block]
- Temp: 0°C to 70°C [32°F to 158°F]
- Certification: CE, FCC
- CPU: Intel Pentium N Series Elkhart Lake
- Memory: 1x DDR4 2666MHz SO-DIMM Slot, 32GB
- OS: Linux, Windows 10
- Display Outputs: 1x LVDS, 2x Display Port
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 2x USB 3.1 Gen 2 [Type A], 4x USB 2.0 [Board]
- Serial: 1x RS232 [Board], 1x RS232/422/485 [Board]
- M.2: 1x M.2 B-Key [PCIe x1/USB 3.1 Gen 1/USB 2.0/SATA] [2242/2260], 1x M.2 E-Key [USB/PCIe] [2230]
- Storage: 1x M.2 SSD
- Power: 12V DC [Barrel Connector]
- Certification: CE, FCC, RoHS, UKCA
- CPU: Intel Atom X Series Elkhart Lake
- Temp: -20°C to 60°C [-4°F to 140°F]
- Memory: 4GB Soldered On-board
- OS: Linux, Windows 10
- Display Outputs: 1x eDP, 1x Mini Display Port
- Ethernet: 1x GbE LAN [RJ45]
- USB: 2x USB 3.1 Gen 1 [Type A], 4x USB 2.0 [Board]
- Serial: 1x RS232/422/485 [Board]
- M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
- Storage: 1x M.2 SSD
- Power: 12V DC [Terminal Block]
- Certification: CE, FCC
- CPU: Intel Atom X Series Elkhart Lake
- Temp: -40°C to 85°C [-40°F to 185°F]
- Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
- OS: Linux, Windows 10
- Display Outputs: 1x Display Port, 1x eDP, 1x HDMI
- Ethernet: 1x 2.5 GbE LAN [RJ45], 1x GbE LAN [RJ45]
- USB: 2x USB 2.0 [Board], 2x USB 2.0 [Type A], 2x USB 3.1 Gen 1 [Type A]
- Serial: 1x RS232/422/485 [DB9], 3x RS232 [Board]
- M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
- Storage: 1x M.2 SSD, 1x SATA Port
- Power: 9-36V DC Input [Terminal Block]
- Certification: CE, FCC
- CPU: Intel Atom X Series Elkhart Lake
- Temp: -40°C to 85°C [-40°F to 185°F]
- CPU: Intel Atom X Series Elkhart Lake
- Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
- OS: Linux, Windows 10
- Display Outputs: 1x Display Port
- Ethernet: 2x GbE LAN [RJ45]
- USB: 1x USB 2.0 [Board], 2x USB 3.1 Gen 1 [Type A]
- Serial: 1x RS232 [Board], 1x RS232/422/485 [Board]
- M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2280], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
- Storage: 1x SATA Port
- Power: 12V DC [Terminal Block]
- Temp: -40°C to 70°C [-40°F to 158°F]
- Certification: CE, FCC
- CPU: Intel Pentium N Series Elkhart Lake
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
- OS: Linux, Windows 11
- Display Outputs: 1x Display Port, 1x HDMI
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 2.0 [Board], 2x USB 2.0 [Type A], 2x USB 3.2 Gen 2 [Type A], 2x USB 3.2 Gen 2 [Type C]
- Serial: 1x RS232/422/485 [Board]
- M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2242/2260/2280]
- Storage: 1x M.2 SSD, 1x SATA Port
- Power: 12-19V DC [Barrel Connector], AC Power Supply Included
- Temp: 0°C to 60°C [32°F to 140°F]
- Certification: CE, FCC
