Single Board Computers

Industrial SBCs Built On AMD, ARM, Intel and NVIDIA Technology

Our range of industrial single board computers (SBCs) encompasses a comprehensive range of industry-standard form factors, ensuring compatibility and flexibility across various applications. These SBCs are available in both x86 and ARM-based architectures, providing options that cater to different computing requirements and preferences.

For those seeking the power and compatibility of x86 architecture, our  industrial SBCs deliver exceptional performance and compatibility with a wide range of software applications based on either Windows or Linux operating systems. The x86 architecture, backed by industry-leading AMD Ryzen and Intel processors, offers a robust foundation for running resource-intensive applications, handling complex calculations, and efficiently managing data.

On the other hand, our ARM SBCs provide a compelling alternative for those looking for power-efficient and cost-effective solutions. ARM architecture, known for its energy efficiency and scalability, is widely adopted in embedded systems and mobile devices. Our ARM single board computers offer a balance between performance and power consumption, making them ideal for applications where energy efficiency and compact form factors are critical.

Browse Our Range Of Embedded SBC Solutions

Performance

Graphics

I/O

Expansion

Storage

Power

Environmental Conditions

  • CPU: Celeron J Series Elkhart Lake
  • Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x Display Port, 1x eDP, 1x HDMI, 1x LVDS
  • Ethernet: 2 x 2.5 GbE LAN [RJ45]
  • USB: 2 x USB 3.1 Gen 1 [Type A], 2 x USB 3.2 Gen 2 [Type A], 4 x USB 2.0 [Board]
  • Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
  • M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/2280/3042], 1x M.2 E-Key [PCIe/USB] [3042/3052]
  • PCIe: 1x PCIe [x4 Slot]
  • Storage: 1x M.2 SSD, 2x SATA Ports
  • Power: 9-36V DC [Barrel Connector]
  • Temp: -5°C to 65°C [23°F to 149°F]
  • Certification: CE, FCC, UKCA
  • CPU: Celeron J Series Elkhart Lake
  • Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x Display Port, 1x eDP, 1x HDMI, 1x LVDS
  • Ethernet: 2 x 2.5 GbE LAN [RJ45]
  • USB: 2 x USB 3.1 Gen 1 [Type A], 2 x USB 3.2 Gen 2 [Type A], 4 x USB 2.0 [Board]
  • Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
  • M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/2280/3042], 1x M.2 E-Key [PCIe/USB] [3042/3052]
  • PCIe: 1x PCIe [x4 Slot]
  • Storage: 1x M.2 SSD, 2x SATA Ports
  • Power: 12V DC [Barrel Connector]
  • Temp: -5°C to 65°C [23°F to 149°F]
  • Certification: CE, FCC, UKCA
  • CPU: Atom X Series Elkhart Lake
  • Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x LVDS, 2x Display Port
  • Ethernet: 1 x 2.5 GbE LAN [RJ45], 2 x GbE LAN [RJ45]
  • USB: 2 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A], 4 x USB 2.0 [Board]
  • Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
  • M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe] [2242/2260]
  • Storage: 1x SATA Port, 2x M.2 SSD
  • Power: 9-36V DC Input [Terminal Block]
  • Temp: 0°C to 60°C [32°F to 147°F]
  • Certification: CE, FCC
  • CPU: 13th Gen Raptor Lake
  • Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x Display Port, 1x eDP, 1x HDMI, 1x LVDS, 2x USB Type C
  • Ethernet: 2 x 2.5 GbE LAN [RJ45]
  • USB: 1 x USB 3.2 Gen 2 [Board], 2 x USB 2.0 [Board], 2 x USB 3.2 Gen 2 [Type A], 2 x USB 3.2 Gen 2 [Type C]
  • Serial: 3 x RS232/422/485 [Board]
  • M.2: 1x M.2 B-Key [PCIe x2/USB 3.0/SATA] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4] [2242/2260/2280]
  • Storage: 1x M.2 SSD, 1x SATA Port
  • RAID: RAID 0, RAID 1
  • Power: 12-36V DC Input [Terminal Block]
  • Temp: -20°C to 70°C [-4°F to 158°F]
  • Certification: CE, FCC
  • CPU: 8th Gen Whiskey Lake
  • Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x Display Port / HDMI, 1x eDP
  • Ethernet: 2 x GbE LAN [RJ45]
  • USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
  • Serial: 1 x RS232/422/485 [Board]
  • M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
  • Storage: 2x M.2 SSD
  • Power: 12V DC [Terminal Block]
  • Temp: -30°C to 80°C [-22°F to 176°F]
  • Certification: CE, FCC, RoHS, UKCA
  • CPU: R-Series
  • Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x LVDS, 2x Display Port
  • Ethernet: 3 x GbE LAN [RJ45]
  • USB: 1 x USB 2.0 [Board], 1 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
  • Serial: 1 x RS232/422/485 [Board]
  • M.2: 1x M.2 M-Key [PCIe x4] [2242/2280]
  • mPCIe: 1 x mPCIe [PCIe/USB]
  • Storage: 1x M.2 SSD, 1x SATA Port
  • Power: 12V DC [4-Pin]
  • Temp: -5°C to 65°C [23°F to 149°F]
  • Certification: CE, FCC, RoHS
  • CPU: R-Series
  • Memory: 2x DDR4 2400MHz SO-DIMM Slots, 32GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x Display Port, 1x HDMI, 1x LVDS
  • Ethernet: 2 x GbE LAN [RJ45]
  • USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
  • Serial: 2 x RS232/422/485 [Board]
  • M.2: 1x M.2 B-Key [SATA] [3042]
  • mPCIe: 1 x mPCIe [PCIe/USB]
  • Storage: 1x M.2 SSD, 1x SATA Port
  • Power: 12V DC [4-Pin]
  • Temp: -40°C to 75°C [-40°F to 167°F]
  • Certification: CE, FCC
  • CPU: 8th Gen Whiskey Lake
  • Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x Display Port, 1x eDP, 1x HDMI, 1x LVDS
  • Ethernet: 2 x GbE LAN [RJ45]
  • USB: 2 x USB 2.0 [Board], 4 x USB 3.2 Gen 2 [Type A]
  • Serial: 4 x RS232/422/485 [Board]
  • mPCIe: 1 x mPCIe [PCIe/USB], 1x mPCIe [PCIe/USB/SATA]
  • Storage: 1x mSATA, 2x SATA Ports
  • Power: 12V DC [4-Pin]
  • Temp: -40°C to 70°C [-40°F to 158°F]
  • Certification: CE, FCC

CT-DBT02

3.5 Inch SBC with Dual LAN and mSATA

  • CPU: Celeron J Series Bay Trail
  • Memory: 1x DDR3L 1600MHz SO-DIMM Slot, 4GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x HDMI, 1x VGA
  • Ethernet: 2 x GbE LAN [RJ45]
  • USB: 1 x USB 2.0 [Type A], 1 x USB 3.0 [Type A], 4 x USB 2.0 [Board]
  • Serial: 1 x RS232/422/485 [DB9], 3 x RS232/422/485 [Board]
  • mPCIe: 1 x mPCIe [PCIe/USB], 1 x mPCIe [SATA]
  • Storage: 1x Micro SD, 1x mSATA, 2x SATA Ports
  • Power: 12V DC [4-Pin]
  • Temp: -20°C to 70°C [-4°F to 158°F]
  • Certification: CE, FCC

CT-DBT01

3.5 Inch Single Board Computer with Dual LAN and J1900 CPU

  • CPU: Celeron J Series Bay Trail
  • Memory: 1x DDR3L 1600MHz SO-DIMM Slot, 4GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x HDMI, 1x VGA
  • Ethernet: 2 x GbE LAN [RJ45]
  • USB: 1 x USB 2.0 [Type A], 1 x USB 3.0 [Type A], 4 x USB 2.0 [Board]
  • Serial: 1 x RS232/422/485 [DB9], 3 x RS232/422/485 [Board]
  • mPCIe: 2 x mPCIe [PCIe/USB]
  • Storage: 1x Micro SD, 2x SATA Ports
  • Power: 12V DC [4-Pin]
  • Temp: -20°C to 70°C [-4°F to 158°F]
  • Certification: CE, FCC

X100

3.5" Quad Core SBC with LVDS and Celeron J3455 CPU

  • CPU: Celeron J Series Apollo Lake
  • Memory: 1x DDR3L 1600MHz SO-DIMM Slot, 8GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x LVDS, 2x HDMI
  • Ethernet: 2 x GbE LAN [RJ45]
  • USB: 2 x USB 2.0 [Board], 2 x USB 2.0 [Type A], 2 x USB 3.0 [Type A]
  • Serial: 1 x RS232 [Board], 1 x RS232/422/485 [Board]
  • M.2: 1x M.2 B/M-Key [SATA] [2242]
  • mPCIe: 1 x mPCIe [PCIe/USB]
  • Storage: 1x M.2 SSD
  • Power: 12V DC [Barrel Connector]
  • Temp: 0°C to 60°C [32°F to 147°F]
  • Certification: CE, FCC

X101

3.5" Quad Core Single Board Computer with eDP and Celeron J3455 CPU

  • CPU: Celeron J Series Apollo Lake
  • Memory: 1x DDR3L 1600MHz SO-DIMM Slot, 8GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x eDP, 2x HDMI
  • Ethernet: 2 x GbE LAN [RJ45]
  • USB: 2 x USB 2.0 [Board], 2 x USB 2.0 [Type A], 2 x USB 3.0 [Type A]
  • Serial: 1 x RS232 [Board], 1 x RS232/422/485 [Board]
  • M.2: 1x M.2 B/M-Key [SATA] [2242]
  • mPCIe: 1 x mPCIe [PCIe/USB]
  • Storage: 1x M.2 SSD
  • Power: 12V DC [Barrel Connector]
  • Temp: 0°C to 60°C [32°F to 147°F]
  • Certification: CE, FCC
  • CPU: 11th Gen Tiger Lake
  • Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
  • OS: Linux, Windows 10
  • Display Outputs: 1x Display Port, 1x eDP, 1x HDMI
  • Ethernet: 2 x GbE LAN [RJ45]
  • USB: 4 x USB 2.0 [Board], 4 x USB 3.2 Gen 2 [Type A]
  • Serial: 1 x RS232 [Board], 1 x RS232/422/485 [Board]
  • M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4] [2280]
  • Storage: 1x M.2 SSD, 1x SATA Port
  • Power: 12V DC [Barrel Connector]
  • Temp: -20°C to 70°C [-4°F to 158°F]
  • Certification: CE, FCC
  • CPU: 11th Gen Tiger Lake
  • Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
  • OS: Linux, Windows 10
  • Display Outputs: 2x HDMI, 2x LVDS
  • Ethernet: 2 x GbE LAN [Board]
  • USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Board]
  • Serial: 4 x RS232/422/485 [Board]
  • M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
  • mPCIe: 2 x mPCIe [SATA/USB/PCIe]
  • Storage: 1x M.2 SSD, 2x mSATA
  • Power: 12V DC, 18-36V DC [Terminal Block]
  • Temp: -40°C to 85°C [-40°F to 185°F]
  • Certification: CE, FCC
Showing 1–15 of 42 results

Innovation & Technology Insights

Our expertise lies in manufacturing single-board computers (SBCs) specifically designed for embedded applications at the edge. Our team of skilled system design engineers provides personalized recommendations and configurations for durable solutions that cater to your industry and unique application needs. Explore how we support companies similar to yours in transforming their operations and launching innovative products, or stay informed with the most recent industry updates.

Need Help Choosing a Single Board Computer?

Tell us about your application and a member of the team will get right back to you.
