US Jetson Thor Carrier Boards
Mil-Grade and Industrial Jetson Thor Carrier Boards
A Jetson Thor carrier board is the baseboard that turns an AGX Thor T5000 or T4000 module into the heart of your own robot, vehicle or mission system. The range covers mil-grade and industrial AGX Thor carrier boards.
Options include 10 Gigabit Ethernet, GMSL and SDI camera inputs, CAN bus, serial and PCIe Gen5 expansion, with selected boards rated from -40 °C to 85 °C, suited to humanoid and mobile robots, defense platforms and autonomous machines. For a finished system, see our Jetson Thor computers.
Speak to a Jetson Thor carrier board specialist to match the board, the module and the interfaces to your platform.
Browse Our NVIDIA AGX Thor Carrier Boards
- AI Performance: 1,200–2,070 TOPS
- SOM: NVIDIA Jetson T4000, NVIDIA Jetson T5000
- Memory: 128GB Soldered On-board, 64GB Soldered On-board
- OS: Linux Ubuntu 24.04, Linux
- Display Outputs: 1x Display Port, 1x HDMI
- Ethernet: 1x 100GbE LAN [QSFP28], 1x 5 GbE LAN [RJ45]
- USB: 2x USB 3.2 Gen 2 [Type C], 4x USB 3.2 Gen 2 [Type A]
- CANbus: 4x CANbus [Board]
- M.2: 1x M.2 B-Key [USB] [2242/3042/3052], 1x M.2 E-Key [PCIe x1 Gen4/USB 2.0] [2230], 1x M.2 M-Key [PCIe x2 Gen5] [2280]
- Power: 20-32V DC Input
- Temp: -25°C to 45°C [-13°F to 113°F]
- Certification: CE, FCC
- AI Performance: 1,200–2,070 TOPS
- SOM: NVIDIA Jetson T4000, NVIDIA Jetson T5000
- Memory: 128GB Soldered On-board, 64GB Soldered On-board
- OS: Linux Ubuntu 24.04, Linux
- Display Outputs: 1x HDMI
- Ethernet: 1x 5 GbE LAN [RJ45]
- USB: 8x USB 3.2 Gen 2 [Type C], 2x USB 3.2 Gen 2 [Type C]
- Serial: 2x RS485 [Board]
- CANbus: 2x CANbus [Board]
- M.2: 1x M.2 B-Key [USB] [2242/3042/3052], 1x M.2 E-Key [PCIe x1 Gen4/USB 2.0] [2230], 1x M.2 M-Key [PCIe x2 Gen5] [2280]
- Power: 20-57V DC Input
- Temp: -20°C to 45°C [-4°F to 113°F]
- Certification: CE, FCC
- AI Performance: 1,200–2,070 TOPS
- SOM: NVIDIA Jetson T4000, NVIDIA Jetson T5000
- Memory: 128GB Soldered On-board, 64GB Soldered On-board
- OS: Linux Ubuntu 24.04, Linux
- Display Outputs: 1x HDMI
- Ethernet: 1x 5 GbE LAN [RJ45]
- USB: 3x USB 3.2 Gen 2 [Type C], 2x USB 3.2 Gen 2 [Type C]
- Serial: 2x RS485 [Board]
- CANbus: 2x CANbus [Board]
- M.2: 1x M.2 B-Key [USB] [2242/3042/3052], 1x M.2 E-Key [PCIe x1 Gen4/USB 2.0] [2230], 1x M.2 M-Key [PCIe x2 Gen5] [2280]
- Power: 20-57V DC Input
- Temp: -20°C to 45°C [-4°F to 113°F]
- Certification: CE, FCC
- OS: Linux
- Display Outputs: 2x HDMI
- Ethernet: 4x 10 GbE LAN [Board]
- USB: 3x USB 3.2 [Board]
- Serial: 4x RS232/422/485 [Board]
- CANbus: 4x Isolated CANbus [Board]
- M.2: 1x M.2 M-Key [PCIe x1 Gen5] [2280], 1x M.2 M-Key [PCIe x2 Gen5] [2280], 1x M.2 M-Key [PCIe x4 Gen5] [2280]
- Storage: 1x M.2 M-Key [PCIe x4 Gen5] [2280], 1x M.2 M-Key [PCIe x1 Gen5] [2280], 1x M.2 M-Key [PCIe x2 Gen5] [2280]
- Power: 18-36V DC [4-Pin]
- Temp: -40°C to 85°C [-40°F to 185°F]
- AI Performance: 1,200 TOPS
- SOM: NVIDIA Jetson T4000
- OS: Linux
- Display Outputs: 2x HDMI
- USB: 2x USB 3.2 Gen 2 [Type C]
- Serial: 1x RS232/422/485 [Terminal Block]
- CANbus: 2x CAN FD [Board], 2x CAN FD [Terminal Block]
- M.2: 1x M.2 B-Key [USB/SIM] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x2 Gen4] [2242], 1x M.2 M-Key [PCIe x4 Gen4] [2280]
- Storage: 1x M.2 SSD [M-Key 2242, PCIe Gen 4 x2], 1x M.2 SSD [M-Key 2280, PCIe Gen 4 x4]
- Power: 18-36V DC [Terminal Block]
- Temp: -40°C to 85°C [-40°F to 185°F]
- AI Performance: 1,200 TOPS
- SOM: NVIDIA Jetson T4000
- Ethernet: 3x 25GbE LAN [QSFP28], 1x GbE LAN [RJ45]
Explore Thor Computers and Other Jetson Boards
Rather start from a finished system, or reusing an AGX Orin design? Compare Thor carrier boards with our Jetson Thor computers and AGX Orin boards.
What a Jetson Thor Carrier Board Does
NVIDIA Jetson Thor carrier boards are the baseboards that turn an AGX Thor module into a working edge AI computer, breaking out its interfaces, including 10 Gigabit Ethernet, SDI and GMSL camera inputs, CAN bus, serial, and PCIe Gen5, into the connectors and form factor a system needs. They are used to build custom robotics, defense, and autonomous-machine platforms around the Jetson AGX Thor T5000 and T4000.
We offer mil-grade and industrial Jetson Thor carrier boards, and where an off-the-shelf board does not fit, we adapt one or design a custom board. We also provide full integration services, including module fitting, software imaging, and pre-configuration, to accelerate your development cycle.
Jetson Thor Carrier Boards Ranges Configured by Things Embedded
We work with the leading manufacturers of Jetson Thor carrier boards, so the ranges below are every board family we carry for this module. Compare them by size and interfaces, then browse the boards above or ask a specialist which one suits your platform.
MILBOARD Militarised Jetson Carrier Boards
A MIL-STD-designed carrier board for integrators building their own sealed enclosure around NVIDIA Jetson AGX Thor or AGX Orin. MILBOARD-THR is the board-level half of the MILBOX-THR, and MILBOARD-AGXMAX and MILBOARD-AGX carry AGX Orin.
DSBOARD Industrial Jetson Carrier Boards
Bare carrier boards for integrating NVIDIA Jetson into your own enclosure or product, from Orin Nano and Orin NX through AGX Orin to the AGX Thor T4000 and T5000. Wide-temperature industrial designs with the camera, Ethernet and storage interfaces exposed for your build.
NVIDIA Jetson and IGX Edge AI Boards and Computers
Edge AI hardware built around video input: Jetson Thor and AGX Orin carrier boards and computers, an AI NVR with eight PoE ports, the NEAR T7X on NVIDIA IGX Thor, the AIR6N0-C-MB NX carrier for Orin NX and Orin Nano, compact Pandora systems including Pandora Health builds with HDMI and SDI capture, VPP6N0 computers, and Holoscan sensor bridges that feed live video into NVIDIA Holoscan.
Not sure which range fits? Tell us the application and we will recommend the right model.
What to Specify in a Thor Baseboard
Our embedded engineers specify every carrier board against the module, the interfaces and the enclosure it goes into. These are the choices we work through with you before recommending a board.
Module Fit
Boards for the AGX Thor T5000 and T4000 modules. AGX Orin carrier boards do not take the Thor module: it uses a different connector, higher power and new I/O.
Interfaces and Expansion
Gigabit and multi-gigabit Ethernet, serial and CAN for control networks, and M.2 or mini PCIe slots for NVMe storage, Wi-Fi, 4G and 5G.
Camera Inputs
Camera connectors on the board itself, or an M.2 or mini PCIe frame grabber for GMSL, SDI and HDMI video where the board has none.
Temperature Range
Selected boards rated from -40 °C to 85 °C for vehicle and defense installs.
Off-the-Shelf or Custom
Start from an off-the-shelf board, or we adapt one or design a custom carrier around your interfaces, connectors and enclosure.
Board Support Package
The carrier manufacturer's board support package matched to the JetPack release you need, flashed and tested with the module fitted.
Jetson Thor Carrier Board Innovation & Custom Design Insights
Speak to a Jetson Thor Carrier Board Specialist.
Tell us the module, the interfaces you need and where the board will be installed. We will recommend the right Thor carrier board, or adapt one, then fit the module, image and test it before it ships.
