US Waterproof Monitors
Waterproof Touch Screen Monitors by IP Rating
Waterproof monitors keep water out of the display, from a front IP65 or IP66 bezel on a cabinet door to units sealed on every face for open mounting on a wet line, in an outdoor enclosure or on a vehicle. Choose by the rating the area needs: front IP65 and front IP66 for panel mount displays, and full IP65, IP66, IP67 and IP69K for chassis units in the open, which are the models below.
Options include 304 and 316 stainless steel, M12 connectors, optical bonding, wireless display and IP69K builds for hot high-pressure washdown, suited to food and beverage, pharmaceutical, marine and outdoor installations where water reaches the whole unit.
Speak to a display specialist to match the rating, material and mounting to your cleaning regime.
Browse Our Waterproof Industrial Monitors
- Display: 5.7"[4:3, 640 x 480, VGA]
- Touch: Optional Resistive Touch
- Brightness: 900
- Format: Standard
- Display Inputs: 1x Optional DVI Input, 1x Optional HDMI Input, 1x VGA Input
- Power: 12V DC, AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 6.5"[4:3, 640 x 480, VGA]
- Touch: Optional Resistive Touch
- Brightness: 700
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- Display Inputs: 1x Optional DVI Input, 1x Optional HDMI Input, 1x VGA Input
- Power: 12V DC, AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 7"[17:10, 1024 x 600, WSVGA]
- Touch: Optional Resistive Touch
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x Optional DVI Input, 1x Optional HDMI Input, 1x VGA Input
- Power: 12V DC, AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 7"[17:10, 1024 x 600, WSVGA]
- Touch: Multi Touch PCAP
- Brightness: 320
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x USB Type C
- Power: 5V [USB-C]
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 7"[17:10, 1024 x 600, WSVGA]
- Touch: Multi Touch PCAP
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x USB Type C
- Power: 5V [USB-C]
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 7"[17:10, 1024 x 600, WSVGA]
- Touch: Multi Touch PCAP
- Brightness: 320
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x Optional DVI Input, 1x Optional HDMI Input, 1x VGA Input
- Power: 12V DC, AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 7"[17:10, 1024 x 600, WSVGA]
- Touch: Multi Touch PCAP
- Brightness: 320
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x Optional DVI Input, 1x Optional HDMI Input, 1x VGA Input
- Power: 12V DC, AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 7"[17:10, 1024 x 600, WSVGA]
- Touch: Multi Touch PCAP
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x Optional DVI Input, 1x Optional HDMI Input, 1x VGA Input
- Power: 12V DC, AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 7"[16:9, 1280 x 720, HD]
- Touch: Multi Touch PCAP
- Brightness: 560
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x DVI Input, 1x HDMI Input
- Power: 9-48V DC Input
- Temp: -20°C to 60°C [-4°F to 140°F]
- IP Rating: Front IP65
- Certification: CE, E-Mark, FCC
- Mounting Options: VESA Mount
- Display: 7"[17:10, 1024 x 600, WSVGA]
- Touch: Multi Touch PCAP
- Brightness: 320
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x Optional DVI Input, 1x Optional HDMI Input, 1x VGA Input
- Power: 12V DC
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 7"[17:10, 1024 x 600, WSVGA]
- Touch: Multi Touch PCAP
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x VGA Input
- Power: 12V DC [M12]
- Temp: -15°C to 55°C [5°F to 131°F]
- IP Rating: IP65
- Certification: CE, FCC
- Display: 7"[17:10, 1024 x 600, WSVGA]
- Touch: Multi Touch PCAP
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x Optional DVI Input, 1x Optional HDMI Input, 1x VGA Input
- Power: 12V DC
- Temp: -10°C to 60°C [14°F to 140°F], -25°C to 60°C [-13°F to 140°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 7"[17:10, 1024 x 600, WSVGA]
- Touch: Multi Touch PCAP
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x Optional DVI Input, 1x Optional HDMI Input, 1x VGA Input
- Power: 12V DC
- Temp: -10°C to 60°C [14°F to 140°F], -25°C to 60°C [-13°F to 140°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 7"[17:10, 1024 x 600, WSVGA]
- Touch: Projective Capacitive Touch
- Brightness: 320
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x VGA Input
- Power: 12V DC [M12]
- Temp: -15°C to 55°C [5°F to 131°F]
- IP Rating: IP65
- Certification: CE, FCC, MIL-STD-810
- Display: 8.4"[4:3, 800 x 600, SVGA]
- Touch: Optional Resistive Touch
- Brightness: 600
- Format: Standard
- Display Inputs: 1x VGA Input
- Power: 12V DC [M12], AC Power Supply Included
- Temp: 0°C to 45°C [32°F to 113°F]
- IP Rating: IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
Waterproof Monitor Ranges Configured by Things Embedded
We work with the leading manufacturers of sealed displays, so the ranges below are the ones we specify for washdown lines, outdoor sites and vehicles. Compare them by rating, material and touch, then browse the models above or ask a display specialist which range suits your area.
Winmate Rugged Waterproof Monitors
Fully sealed screens from 7 to 19 inches, IP65 with M12 connectors or IP67, with optical bonding and stainless options on selected models.
Winmate Stainless Steel Washdown Displays
Chassis-mount screens from 10.4 to 32 inches in stainless steel with PCAP touch, sealed to IP65 or IP69K, for food, beverage and pharmaceutical lines.
Winmate Outdoor and G-WIN Chassis Displays
PCAP touch screens from 7 to 55 inches with a front IP65 face, in high-bright outdoor and PoE builds, for kiosks, gates and outdoor control points.
Winmate IP65 Stainless and ATEX Displays
IP65 stainless steel monitors from 8.4 to 55 inches with M12 connectors, resistive touch or 4K UHD, including an ATEX-rated model for classified areas.
Winmate Front IP65 PCAP Chassis Monitor
A 32 inch full HD chassis monitor with PCAP multi-touch and front IP65 sealing, for splash-prone walls and consoles.
TPM-36 Arestech IP66/IP69K Stainless Steel Displays
Washdown screens from 10.1 to 23.8 inches in stainless steel, sealed to IP66 and IP69K, with PCAP or resistive touch and wireless options for hygienic lines.
VDM Sintrones Front-Sealed In-Vehicle Monitors
In-vehicle PCAP touch monitors sealed to IP65 or IP66 at the front, in 7 inch and sunlight readable 10.1 inch E-Mark versions.
Not sure which range fits? Tell us the application and we will recommend the right model.
What to Specify in a Washdown Display
A washdown display has to survive the cleaning method used on the line every shift. The IP rating, steel grade, connectors and touch decide whether it lasts in that area.
IP65, IP66, IP67 or IP69K
Low-pressure jets, powerful jets, temporary immersion or hot high-pressure washdown: match the rating to the cleaning.
Stainless Steel Grade
304 stainless suits most food and dry areas, while 316 resists chlorides, brine and aggressive sanitizers.
M12 Connectors
Sealed, screw-locking M12 connectors keep water out of the power, video and touch ports on fully sealed monitors.
Touch When Wet
Resistive touch ignores water on the glass, while PCAP gives a flush, easy-clean front with multi-touch.
Hygienic Enclosure
Smooth, crevice-free stainless housings with no exposed fixings, for hygienic food and pharmaceutical areas.
Arm and Yoke Mounting
Sealed on every face, the monitor mounts in the open on VESA arms and yokes where the operator works.
Waterproof Display Innovation & Washdown Insights
Speak to a Display Specialist.
Tell us where the display will be installed, the approvals it must meet and the video inputs you need to connect. We will recommend the right size, brightness and mounting, then configure and test it before it ships.
