NVIDIA GPU Computing at the Edge
NVIDIA has designed graphics processors in Santa Clara since 1993, and CUDA, launched in 2006, made its GPUs the standard platform for AI. At the industrial edge they come in two forms: Jetson modules, with the GPU built into a low-power system-on-module, and discrete RTX, L4 and RTX PRO GPUs on PCIe cards or MXM modules inside rugged computers. The same CUDA, TensorRT and DeepStream software runs on both.
01 NVIDIA GPU Families
NVIDIA GPUs for Edge Computing by Family
Six NVIDIA GPU families, from the Jetson modules inside compact edge AI computers to the RTX PRO Blackwell cards in rugged AI servers, with the series and models we carry on each. Pick the family that fits the models you run, the power budget and the enclosure, then the system built around it.
NVIDIA Jetson Edge AI Computers
Jetson puts the NVIDIA GPU, Arm CPU cores and memory on one system-on-module, so a fanless computer can run vision and AI models at 7 to 130 W. Orin, at up to 275 TOPS, runs most of our edge AI computers; Thor adds a Blackwell GPU for robotics and multi-camera work.
Suited to
RoboticsDronesMachine VisionIn-Vehicle
Jetson
Orin and Thor Modules
- GPUs
- Jetson Orin Nano · Orin NX · AGX Orin · AGX Thor T4000 and T5000
- Architecture
- Ampere on Orin · Blackwell on Thor
- Memory
- 4 to 64 GB on Orin · 64 or 128 GB on Thor, shared with the CPU
- Power
- 7 to 60 W on Orin · 40 to 130 W on Thor
- Form Factor
- System-on-module on a carrier board
- Systems
- Fanless edge AI PCs · IP66 and IP67 · rail · drone and robot computers
Series and Models With This GPU
NVIDIA MXM GPU Computers
MXM puts an NVIDIA GPU on a compact module that mounts flat inside the chassis and cools through the enclosure, so a fanless, rail or vehicle computer can carry a discrete GPU without a PCIe card. Modules follow the MXM 3.1 standard, so the GPU can change within the same system.
Suited to
RailIn-VehicleMachine VisionFanless Installs
MXM GPUs
Embedded GPU Modules
- GPUs
- RTX A2000 · T1000 · A500 · Ampere MXM modules
- Architecture
- Turing on T1000 · Ampere on A500 and RTX A2000
- Memory
- Up to 8 GB GDDR6 on the RTX A2000 module
- Power
- 35 to 95 W on the RTX A2000 module
- Form Factor
- MXM 3.1 modules, conduction cooled through the chassis
- Systems
- Fanless GPU box PCs · rail certified computers · in-vehicle computers
Series and Models With This GPU
NVIDIA RTX A-Series Ampere GPU Computers
Ampere is the NVIDIA generation still validated across many inference and visualization projects, with ECC memory on the professional RTX A-series cards. We fit the RTX A4500 and A6000 in rugged edge servers, and GeForce RTX 30 cards in PEG systems where a consumer card suits the workload.
Suited to
Edge ServersVideo AnalyticsSimulationVisualization
RTX A-Series
Ampere Professional GPUs
- GPUs
- RTX A2000 · RTX A4500 · RTX A6000 · GeForce RTX 3080 Ti and 3090
- Architecture
- Ampere, 2nd Gen RT and 3rd Gen Tensor cores
- Memory
- 6 to 48 GB GDDR6, ECC on the RTX A-series
- Power
- 70 W on the RTX A2000 to 450 W on the GeForce RTX 3090 Ti
- Form Factor
- PCIe cards, low profile to dual slot full length
- Systems
- Rugged 2U edge servers · fanless PEG GPU computers
Series and Models With This GPU
NVIDIA RTX Ada GPU Computers
Ada Lovelace brought 4th Gen Tensor cores and FP8 to NVIDIA professional GPUs. The 70 W RTX 2000 Ada and the single-slot RTX 2000E Ada fit compact, fanless and rackmount chassis that cannot take a full-size card.
Suited to
RailInspection VehiclesMachine VisionRack Installs
RTX Ada
Ada Lovelace Professional GPUs
- GPUs
- RTX 2000 Ada · RTX 2000E Ada · RTX 4000 SFF Ada
- Architecture
- Ada Lovelace, 4th Gen Tensor cores with FP8
- Memory
- 16 to 20 GB GDDR6 with ECC
- Power
- 50 W on the RTX 2000E Ada · 70 W on the RTX 2000 Ada and 4000 SFF Ada
- Form Factor
- Low-profile PCIe, single or dual slot
- Systems
- Fanless 2U rackmount · EN 50155 rail GPU computers · compact rugged PCs
Series and Models With This GPU
NVIDIA L4 Edge AI Computers
The L4 is the NVIDIA low-profile data centre GPU for inference and video: Ada Lovelace with 24 GB of memory on a single-slot, 72 W card. Its hardware video engines decode many camera streams at once, which suits video analytics and vision AI in sealed rugged computers.
Suited to
Video AnalyticsSmart CitiesDefenseWashdown Areas
L4
Ada Inference GPU
- GPUs
- NVIDIA L4
- Architecture
- Ada Lovelace, FP8 Tensor cores, AV1 encode and decode
- Memory
- 24 GB GDDR6
- Power
- 72 W
- Form Factor
- Single-slot, low-profile PCIe, passively cooled
- Systems
- IP69K waterproof GPU computers · mission critical and UL certified rugged PCs
Series and Models With This GPU
NVIDIA RTX PRO Blackwell GPU Computers
Blackwell is the current NVIDIA GPU generation, with 5th Gen Tensor cores, FP4 support and GDDR7 memory. The RTX PRO range runs from the 70 W RTX PRO 2000 in compact box PCs to the 600 W RTX PRO 6000 with 96 GB, for large language models and generative AI in rugged edge servers.
Suited to
Generative AILLM InferenceAMRsSensor Fusion
RTX PRO Blackwell
The Newest NVIDIA Professional GPUs
- GPUs
- RTX PRO 2000 · 4000 · 4000 SFF · 4500 · 5000 · 6000
- Architecture
- Blackwell, 5th Gen Tensor cores with FP4
- Memory
- 16 to 96 GB GDDR7 with ECC
- Power
- 70 W on the RTX PRO 2000 and 4000 SFF to 600 W on the RTX PRO 6000
- Form Factor
- PCIe cards, small form factor to dual slot full length
- Systems
- Compact edge AI box PCs · AMR computers · rugged edge AI servers with up to two GPUs
Series and Models With This GPU
Holoscan Sensor Bridges
Holoscan sensor bridges carry live video and camera data into NVIDIA Holoscan systems over SFP+ fiber, for low-latency AI in medical imaging, inspection and robotics. Inputs cover HDMI 2.0, 12G-SDI, DisplayPort and GMSL2.
- HDMI 2.0 and 12G-SDI inputs at up to 4K60
- GMSL2 camera bridges in one and four channels
- SFP+ fiber links into the Holoscan system
Products in This Family
// LOADING...
Browse NVIDIA GPU Computers and Modules
Or choose a product family above.
-
LLM-1U-RPL-2E8-600W-DC
LLM-1U-RPL with two PCIe x8 Gen4 slots and redundant 600W DC power -
LLM-1U-RPL-1E16-600W-AC
LLM-1U-RPL with one PCIe x16 Gen4 GPU slot and redundant 600W AC power -
LLM-1U-RPL-1E16-600W-DC
LLM-1U-RPL with one PCIe x16 Gen4 GPU slot and redundant 600W DC power -
LLM-1U-RPL-2E8-600W-AC
LLM-1U-RPL with two PCIe x8 Gen4 slots and redundant 600W AC power
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core 12th Gen Alder Lake, Intel Core 13th Gen Raptor Lake
- GPU / AI Accelerator: Discrete GPU (PCIe)
- GPU: RTX 4000 SFF Ada, RTX 4500 Ada, RTX 5000 Ada, RTX A1000, NVIDIA RTX PRO 2000 Blackwell, NVIDIA RTX PRO 4000 Blackwell, NVIDIA RTX PRO 4000 Blackwell SFF, NVIDIA RTX PRO 4500 Blackwell, NVIDIA RTX 2000 Ada, NVIDIA RTX 4000 Ada
- AI Performance: 54–1,617 TOPS
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
- OS: Linux, Windows 11
- Display Outputs: 1x HDMI, 2x Display Port
- Ethernet: 3x 2.5 GbE LAN [RJ45]
- USB: 2x USB 3.2 Gen 1 [Type A], 6x USB 3.2 Gen 2 [Type A]
- Serial: 2x RS232 [Board], 2x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [PCIe x1/USB/SIM] [3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4] [2242/2280]
- Storage: 2x 2.5" HDD/SSD, 2x M.2 SSD
- Hot Swappable Storage: Hot Swappable SSD Support
- RAID: RAID 0, RAID 1
- Ignition Sensing: Supports Ignition Control
- Temp: 0°C to 35°C [32°F to 95°F]
- Certification: IEC 62368-1, CB, CE, FCC, IC (ICES-003), UKCA, UL 62368-1
- Mounting Options: 19" Rack Mount
- PCIe: 2x PCIe [x8 Slot] [Gen4]
- Power: 36-72V DC Input
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core 12th Gen Alder Lake, Intel Core 13th Gen Raptor Lake
- GPU / AI Accelerator: Discrete GPU (PCIe)
- GPU: RTX 4000 SFF Ada, NVIDIA RTX PRO 2000 Blackwell, NVIDIA RTX PRO 4000 Blackwell SFF, NVIDIA RTX 2000 Ada
- AI Performance: 192–770 TOPS
- Memory: 4x DDR4 2666MHz LONG-DIMM Slots, 128GB
- OS: Linux, Windows 11
- Display Outputs: 4x Display Ports
- Ethernet: 1x 2.5 GbE LAN [RJ45], 1x GbE LAN [RJ45]
- USB: 1x USB 3.2 Gen 2x2 [Type C], 2x USB 3.2 Gen 1 [Board], 4x USB 2.0 [Type A], 6x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [Board], 2x RS232 [DB9], 3x RS232 [Board]
- M.2: 1x M.2 E-Key [PCIe x1 Gen3/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4 Gen4/SATA] [2242/2260/2280], 1x M.2 M-Key [PCIe x4 Gen4] [2242/2260/2280]
- PCIe: 1x PCIe [x16 Slot] [Gen5], 1x PCIe [x16 Slot] [x4 Signal] [Gen4], 1x PCIe [x4 Slot] [Gen3], 1x PCIe [x4 Slot] [Gen4]
- Storage: 1x 2.5" HDD/SSD, 2x M.2 SSD, 4x SATA Ports
- Hot Swappable Storage: Hot Swappable SSD Support
- RAID: RAID 0, RAID 1, RAID 5, RAID 10
- Power: 100-240V AC, AC Power Supply Included
- Temp: 0°C to 40°C [32°F to 104°F]
- Certification: IEC 62368-1, CB, CE, FCC, IC (ICES-003), UKCA, UL 62368-1
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core 12th Gen Alder Lake, Intel Core 13th Gen Raptor Lake
- GPU / AI Accelerator: Discrete GPU (PCIe)
- GPU: RTX 4000 SFF Ada, NVIDIA RTX PRO 2000 Blackwell, NVIDIA RTX PRO 4000 Blackwell, NVIDIA RTX PRO 4000 Blackwell SFF, NVIDIA RTX 2000 Ada, NVIDIA RTX 4000 Ada
- AI Performance: 192–1,290 TOPS
- Memory: 4x DDR4 2666MHz LONG-DIMM Slots, 128GB
- OS: Linux, Windows 11
- Display Outputs: 4x Display Ports
- Ethernet: 1x 2.5 GbE LAN [RJ45], 1x GbE LAN [RJ45]
- USB: 1x USB 3.2 Gen 2x2 [Type C], 2x USB 3.2 Gen 1 [Type A], 4x USB 2.0 [Type A], 6x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [Board], 2x RS232 [DB9], 3x RS232 [Board]
- M.2: 1x M.2 E-Key [PCIe x1 Gen3/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4 Gen4/SATA] [2242/2260/2280], 1x M.2 M-Key [PCIe x4 Gen4] [2242/2260/2280]
- PCIe: 1x PCIe [x16 Slot] [Gen5], 1x PCIe [x16 Slot] [x4 Signal] [Gen4], 1x PCIe [x4 Slot] [Gen3], 1x PCIe [x4 Slot] [Gen4]
- Storage: 2x 2.5" HDD/SSD, 2x M.2 SSD, 4x SATA Ports
- RAID: RAID 0, RAID 1, RAID 5, RAID 10
- Power: 100-240V AC, AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- Certification: IEC 62368-1, CB, CE, FCC, IC (ICES-003), UKCA, UL 62368-1
- Mounting Options: Desktop, Rack Mount
-
VCO-6000-RPL-3-2PWR-4B
VCO-6000-RPL-3-2PWR-4B with 16-lane PCIe x16 Gen4, 600W GPU power and six SATA bays -
VCO-6000-RPL-3-2PWR
VCO-6000-RPL-3-2PWR with 16-lane PCIe x16 Gen4, 600W GPU power and two SATA bays -
VCO-6000-RPL-3-2PWR-2B
VCO-6000-RPL-3-2PWR-2B with 16-lane PCIe x16 Gen4, 600W GPU power and four SATA bays -
VCO-6000-RPL-3-2PWR-2N
VCO-6000-RPL-3-2PWR-2N with 16-lane PCIe x16 Gen4, 600W GPU power and two U.2 NVMe bays -
VCO-6000-RPL-4-2PWR
VCO-6000-RPL-4-2PWR with dual PCIe x16 Gen4 slots, 600W GPU power and two SATA bays -
VCO-6000-RPL-4-2PWR-2B
VCO-6000-RPL-4-2PWR-2B with dual PCIe x16 Gen4, 600W GPU power and four SATA bays -
VCO-6000-RPL-4-2PWR-2N
VCO-6000-RPL-4-2PWR-2N with dual PCIe x16 Gen4, 600W GPU power and two U.2 NVMe bays -
VCO-6000-RPL-4-2PWR-4B
VCO-6000-RPL-4-2PWR-4B with dual PCIe x16 Gen4, 600W GPU power and six SATA bays
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core Series 2 Bartlett Lake, Intel Core 12th Gen Alder Lake, Intel Core 13th Gen Raptor Lake
- GPU / AI Accelerator: Discrete GPU (PCIe)
- GPU: RTX 4000 SFF Ada, RTX 4500 Ada, RTX 5000 Ada, RTX A1000, NVIDIA RTX PRO 2000 Blackwell, NVIDIA RTX PRO 4000 Blackwell, NVIDIA RTX PRO 4000 Blackwell SFF, NVIDIA RTX PRO 4500 Blackwell, NVIDIA RTX PRO 5000 Blackwell, NVIDIA RTX PRO 6000 Blackwell Max-Q, NVIDIA RTX 2000 Ada, NVIDIA RTX 4000 Ada
- AI Performance: 54–3,511 TOPS
- Memory: 2x DDR5 5600MHz SO-DIMM Slot, 96GB
- OS: Linux, Windows 11
- Display Outputs: 1x DVI, 2x Display Port
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 2x USB 3.2 Gen 1 [Board], 4x USB 3.2 Gen 2 [Type A]
- Serial: 2x RS232/422/485 [DB9], 4x RS232/422/485 [Board]
- M.2: 1x M.2 B-Key [PCIe/USB/SIM] [2242/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
- mPCIe: 1x mPCIe [PCIe/USB/SIM/SATA]
- Front Accessible Storage: Front Accessible Storage
- Hot Swappable Storage: Hot Swappable SSD Support
- Power: 48V DC [Terminal Block], 9-48V DC Input [Terminal Block]
- Ignition Sensing: Supports Ignition Control
- Temp: -25°C to 70°C [-13°F to 158°F]
- Certification: IEC 62368-1, CB, CE, FCC, IC (ICES-003), UKCA, UL 62368-1
- Mounting Options: Wall Mount
- PCIe: 1x PCIe [x16 Slot] [x16 Signal] [Gen4], 2x PCIe [x4 Slot] [x1 Signal] [Gen2]
- Storage: 1x M.2 SSD, 1x mSATA, 6x 2.5" HDD/SSD
- RAID: RAID 0, RAID 1, RAID 5, RAID 10
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core 12th Gen Alder Lake, Intel Core 13th Gen Raptor Lake
- GPU / AI Accelerator: Discrete GPU (PCIe)
- GPU: RTX 4000 SFF Ada, RTX A1000, NVIDIA RTX PRO 2000 Blackwell, NVIDIA RTX PRO 4000 Blackwell SFF, NVIDIA RTX 2000 Ada
- AI Performance: 54–770 TOPS
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
- OS: Linux, Windows 11
- Display Outputs: 1x HDMI, 2x Display Port
- Ethernet: 3x 2.5 GbE LAN [RJ45]
- USB: 2x USB 2.0 [Type A], 2x USB 3.2 Gen 1 [Type A], 6x USB 3.2 Gen 2 [Type A]
- Serial: 2x RS232 [DB9], 2x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [PCIe x1/USB/SIM] [3042], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4] [2242/2280]
- Storage: 1x M.2 SSD [M-Key 2242/2280, PCIe Gen 3 x4]
- Power: 9-36V DC Input [Terminal Block]
- Temp: 0°C to 50°C [32°F to 122°F]
- Certification: IEC 62368-1, CB, CE, FCC, IC (ICES-003), UKCA, UL 62368-1
- Mounting Options: Wall Mount
- PCIe: 2x PCIe [x8 Slot] [Gen4]
-
RCO-6000-RPL-4N
RCO-6000-RPL-4N with 4-bay removable U.2 NVMe canister, PCIe x16 GPU slot and dual 2.5GbE -
RCO-6000-RPL
RCO-6000-RPL with LGA1700 Intel Core, dual 2.5GbE, 8x USB 3.2 and EDGEBoost I/O brackets -
RCO-6000-RPL-2E16
RCO-6000-RPL-2E16 with PCIe x16 Gen4 and x1 node, dual 2.5GbE and fanless design -
RCO-6000-RPL-2E16-2B15M
RCO-6000-RPL-2E16-2B15M with 2x hot-swap SATA bays, PCIe x16 Gen4 slots and dual 2.5GbE -
RCO-6000-RPL-2E16-2N15M
RCO-6000-RPL-2E16-2N15M with 2x hot-swap U.2 NVMe bays, PCIe x16 Gen4 slots and dual 2.5GbE -
RCO-6000-RPL-2E16-2PWR
RCO-6000-RPL-2E16-2PWR with PCIe x16 Gen4 node, dedicated GPU power input and dual 2.5GbE -
RCO-6000-RPL-2E16-4B7M
RCO-6000-RPL-2E16-4B7M with 4x hot-swap SATA bays, PCIe x16 Gen4 slots and dual 2.5GbE -
RCO-6000-RPL-2E8
RCO-6000-RPL-2E8 with dual eight-lane PCIe Gen4 node, dual 2.5GbE and fanless design -
RCO-6000-RPL-2E8-2B15M
RCO-6000-RPL-2E8-2B15M with 2x hot-swap SATA bays, dual PCIe x8 Gen4 slots and dual 2.5GbE -
RCO-6000-RPL-2E8-2N15M
RCO-6000-RPL-2E8-2N15M with 2x hot-swap U.2 NVMe bays, dual PCIe x8 Gen4 slots and dual 2.5GbE -
RCO-6000-RPL-2E8-2PWR
RCO-6000-RPL-2E8-2PWR with dual PCIe x8 Gen4 node, dedicated GPU power input and dual 2.5GbE -
RCO-6000-RPL-2E8-4B7M
RCO-6000-RPL-2E8-4B7M with 4x hot-swap SATA bays, dual PCIe x8 Gen4 slots and dual 2.5GbE -
RCO-6000-RPL-2N
RCO-6000-RPL-2N with 2-bay removable U.2 NVMe canister, PCIe x16 GPU slot and dual 2.5GbE -
RCO-6000-RPL-4NH
RCO-6000-RPL-4NH with 4x hot-swap U.2 NVMe, hardware RAID 0/1/5/6/10 and dual 2.5GbE -
RCO-6000-RPL-4NH-1E
RCO-6000-RPL-4NH-1E with 4-bay U.2 NVMe canister, optional hardware RAID and two PCIe Gen4 slots -
RCO-6000-RPL-4NS
RCO-6000-RPL-4NS with 4x hot-swap U.2 NVMe, software RAID and dual 2.5GbE -
RCO-6000-RPL-8NS
RCO-6000-RPL-8NS with 8x hot-swap U.2 NVMe, software RAID and dual 2.5GbE
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core Series 2 Bartlett Lake, Intel Core 12th Gen Alder Lake, Intel Core 13th Gen Raptor Lake
- Memory: 2x DDR5 5600MHz SO-DIMM Slot, 96GB
- OS: Linux, Windows 11
- Display Outputs: 1x DVI, 2x Display Port
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 1x USB 2.0 [Board], 8x USB 3.2 Gen 2 [Type A]
- Serial: 2x RS232/422/485 [DB9], 4x RS232/422/485 [Board]
- CANbus: 2x CANbus [Board]
- M.2: 1x M.2 B-Key [PCIe/USB/SIM] [2242/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
- mPCIe: 1x mPCIe [PCIe/USB/SATA]
- Front Accessible Storage: Front Accessible Storage
- Hot Swappable Storage: Hot Swappable SSD Support
- Power: 9-48V DC Input [Terminal Block]
- Ignition Sensing: Supports Ignition Control
- Certification: IEC 62368-1, CB, CE, FCC, IC (ICES-003), UKCA, UL 62368-1
- Mounting Options: Wall Mount
- GPU / AI Accelerator: Discrete GPU (PCIe)
- GPU: RTX 4000 SFF Ada, RTX A1000, NVIDIA RTX PRO 2000 Blackwell, NVIDIA RTX PRO 4000 Blackwell SFF, NVIDIA RTX 2000 Ada
- AI Performance: 54–770 TOPS
- PCIe: 1x PCIe [x16 Slot] [x8 Signal] [Gen3], 1x PCIe [x4 Slot] [x1 Signal] [Gen3]
- Storage: 1x M.2 SSD, 1x mSATA, 2x 2.5" HDD/SSD, 4x 2.5" U.2 NVMe SSD
- RAID: RAID 0, RAID 1, RAID 5
- Temp: -25°C to 45°C [-13°F to 113°F]
- Display: 15.6"[16:9, 3840 x 2160, UHD]
- Touch: Multi Touch PCAP
- Brightness: 400
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- CPU: Intel Core 12th Gen Alder Lake
- GPU / AI Accelerator: Discrete GPU (MXM)
- GPU: RTX A1000 Embedded (MXM), NVIDIA RTX Ampere Embedded
- OS: Windows 11
- Display Outputs: 1x Optional HDMI, 1x USB Type C
- Ethernet: 2x GbE LAN [RJ45]
- USB: 1x USB 3.0 [Type C], 3x USB 3.0 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- Storage: 1x Micro SD
- Power: 19V DC, AC Power Supply Included
- Temp: -29°C to 63°C [-20°F to 145°F]
- IP Rating: IP65
- Certification: CE, FCC, MIL-STD-461, MIL-STD-810, STANAG 4370
- Display: 15.6"[16:9, 1920 x 1080, FHD]
- Touch: Multi Touch PCAP
- Brightness: 1000, 800
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- CPU: Intel Core 12th Gen Alder Lake
- GPU / AI Accelerator: Discrete GPU (MXM)
- GPU: RTX A1000 Embedded (MXM), NVIDIA RTX Ampere Embedded
- OS: Windows 11
- Display Outputs: 1x Optional HDMI, 1x USB Type C
- Ethernet: 2x GbE LAN [RJ45]
- USB: 1x USB 4 [Type C], 3x USB 3.2 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- Storage: 1x Micro SD
- Power: 19V DC, AC Power Supply Included
- Temp: -29°C to 63°C [-20°F to 145°F]
- IP Rating: IP65
- Certification: CE, FCC, MIL-STD-461, MIL-STD-810, STANAG 4370
- Display: 15.6"[16:9, 1920 x 1080, FHD]
- Touch: Multi Touch PCAP
- Brightness: 800
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- CPU: Intel Core 12th Gen Alder Lake
- GPU / AI Accelerator: Discrete GPU (MXM)
- GPU: RTX A500 Embedded (MXM)
- OS: Windows 11
- Display Outputs: 1x USB Type C, 2x Optional HDMI
- Ethernet: 2x GbE LAN [RJ45]
- USB: 1x USB 3.0 [Type C], 3x USB 3.0 [Type A]
- Storage: 1x Micro SD
- Power: 19V DC, AC Power Supply Included
- Temp: -20°C to 60°C [-4°F to 140°F]
- IP Rating: IP65
- Certification: CE, FCC, MIL-STD-461, MIL-STD-810
- Display: 32"[16:9, 1920 x 1080, FHD]
- Touch: Multi Touch PCAP
- Brightness: 400
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core 12th Gen Alder Lake
- GPU / AI Accelerator: Discrete GPU (PCIe), Hailo-8 AI Accelerator
- GPU: RTX 4000E Ada, RTX A1000, NVIDIA RTX 2000E Ada
- AI Performance: 26–142 TOPS
- OS: Linux Ubuntu 24.04, Windows 11
- Display Outputs: 1x Display Port
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230]
- Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
- Power: 90-264V AC
- Temp: 0°C to 55°C [32°F to 131°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 23.8"[16:9, 1920 x 1080, FHD]
- Touch: Multi Touch PCAP
- Brightness: 250
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core 12th Gen Alder Lake
- GPU / AI Accelerator: Discrete GPU (PCIe), Hailo-8 AI Accelerator
- GPU: RTX 4000E Ada, RTX A1000, NVIDIA RTX 2000E Ada
- AI Performance: 26–142 TOPS
- OS: Linux Ubuntu 24.04, Windows 11
- Display Outputs: 1x Display Port
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230]
- Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
- Power: 80-264V AC
- Temp: 0°C to 55°C [32°F to 131°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 19"[5:4, 1280 x 1024, SXGA]
- Touch: Multi Touch PCAP
- Brightness: 250
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core 12th Gen Alder Lake
- GPU / AI Accelerator: Discrete GPU (PCIe), Hailo-8 AI Accelerator
- GPU: RTX 4000E Ada, RTX A1000, NVIDIA RTX 2000E Ada
- AI Performance: 26–142 TOPS
- OS: Linux Ubuntu 24.04, Windows 11
- Display Outputs: 1x Display Port
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230]
- Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
- Power: 80-264V AC
- Temp: 0°C to 55°C [32°F to 131°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 21.5"[16:9, 1920 x 1080, FHD]
- Touch: Multi Touch PCAP
- Brightness: 250
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core 12th Gen Alder Lake
- GPU / AI Accelerator: Discrete GPU (PCIe), Hailo-8 AI Accelerator
- GPU: RTX 4000E Ada, RTX A1000, NVIDIA RTX 2000E Ada
- AI Performance: 26–142 TOPS
- OS: Linux Ubuntu 24.04, Windows 11
- Display Outputs: 1x Display Port
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230]
- Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
- Power: 80-264V AC
- Temp: 0°C to 55°C [32°F to 131°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 27"[16:9, 1920 x 1080, FHD]
- Touch: Multi Touch PCAP
- Brightness: 300
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core 12th Gen Alder Lake
- GPU / AI Accelerator: Discrete GPU (PCIe), Hailo-8 AI Accelerator
- GPU: RTX 4000E Ada, RTX A1000, NVIDIA RTX 2000E Ada
- AI Performance: 26–142 TOPS
- OS: Linux Ubuntu 24.04, Windows 11
- Display Outputs: 1x Display Port
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230]
- Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
- Power: 90-264V AC
- Temp: 0°C to 55°C [32°F to 131°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- CPU: Xeon 600 Series Granite Rapids-WS
- GPU / AI Accelerator: Discrete GPU (PCIe)
- GPU: Arc A770, Arc B580, Arc Pro B50, Arc Pro B60, Arc Pro B65, Arc Pro B70, Radeon AI PRO R9700, NVIDIA RTX PRO 2000 Blackwell, RTX PRO 5000 Blackwell 72GB, NVIDIA RTX PRO 4000 Blackwell, NVIDIA RTX PRO 4000 Blackwell SFF, NVIDIA RTX PRO 4500 Blackwell, NVIDIA RTX PRO 5000 Blackwell, NVIDIA RTX PRO 6000 Blackwell Max-Q
- AI Performance: 170–3,511 TOPS
- Memory: 8x DDR5 6400MHz LONG-DIMM Slots, 2TB
- OS: Linux, Windows 11
- Display Outputs: 1x VGA
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 3.2 Gen 1 [Board], 3x USB 2.0 [Board], 4x USB 3.2 Gen 1 [Type A], 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232 [Board], 1x RS232 [DB9]
- M.2: 1x M.2 M-Key [PCIe x4 Gen4] [2242/2280], 1x M.2 M-Key [PCIe x4 Gen5] [2242/2280/3052/25110]
- PCIe: 1x PCIe [x8 Slot] [Gen5], 2x PCIe [x16 Slot] [x16 Signal] [Gen5], 4x PCIe [x16 Slot] [x16 Signal] [Gen5]
- Storage: 1x 3.5" HDD [SATA], 2x M.2 SSD, 8x SATA Ports
- RAID: RAID 0, RAID 1, RAID 5, RAID 10
- Power: 100-240V AC, AC Power Supply Included
- Mounting Options: 19" Rack Mount, Desktop
Shop by Form Factor
Industrial GPU ComputersNVIDIA RTX, L4 and MXM GPUs in industrial PCs
Rugged GPU ComputersNVIDIA GPU computers for vehicles, rail and harsh sites
Edge AI ComputersGPU
Edge AI ServersRugged servers with 300 to 750 W of GPU powerMXM GPU ComputersConduction-cooled GPU modules for fanless, rail and vehicle buildsNVIDIA Jetson
02 Guides
NVIDIA GPU Computing Guides
Case studies, white papers, news and FAQs from our engineers on NVIDIA GPUs and how they are chosen for industrial edge systems.
GPU Computers Command Edge AI Inference Systems for Automated Food Factory
A USA muffin manufacturer replaced manual bake checks with AI vision inspection: a GPU training server builds the models, and fanless machine vision PCs on the line inspect every muffin and adjust the ovens.
Rugged Fanless PC Powers Real-Time AI Inference on Smart Factory Floor
A material handling equipment maker runs pedestrian avoidance and route navigation on its autonomous vehicles with a rugged fanless PC built on NVIDIA Jetson Orin NX.
Fanless GPU Computer Built On A Custom Jetson Carrier Board
A customer needed a compact fanless GPU computer on a custom NVIDIA Orin carrier board, with serial control, 3G-SDI capture and GPIO sleep and shutdown, in battery and DC-powered versions.
NVIDIA Jetson Edge Computing Platforms Enable Safe Human-Robot Collaboration
GMSL cameras and Jetson Orin NX AI on Vecow's fanless EAC-6100 robotics controller let factories detect people near robots in real time, making human robot collaboration safer on the line.
// NVIDIA at the Edge
Speak to an Edge AI Specialist.
Things Embedded configures, images and tests NVIDIA GPU systems from our partners in the USA. Tell us the models you need to run, the cameras and the environment, and we will point you to the right NVIDIA GPU and the system built around it.
Phone · USA
+1 407 214 9446
