PCIe Video Capture Cards

Our PCIe video capture cards accept high-channel input signals from HDMI, DP, DVI, SDI, TVI, VGA, S-Video, YPbPr, and Composite video sources.

Video Capture

Displaying of 97 items
View All
SC542N4 HYBRID PCIe 4-ch SDI/DVI-I UXGA/HD60 Real-Time Video Capture Card

Yuan

PCIe 4-ch SDI/DVI-I UXGA/HD60 Real-Time Video Capture Card

SC542N4 HYBRID

PCIe 4-ch SDI/DVI-I UXGA/HD60 Real-Time Video Capture Card

SC542N4 HYBRID

PCIe 4-ch SDI/DVI-I UXGA/HD60 Real-Time Video Capture Card

  • Host: PCIe [x4, Gen2]
  • Simultaneous Video Inputs: 1, 4
  • Video Input: 1x DVI-I, 4x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50fps]
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50/30/25/24fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC542N4 HDMI PCIe Quad Channel High Definition 60FPS HDMI Capture Card

Yuan

PCIe Quad Channel High Definition 60FPS HDMI Capture Card

SC542N4 HDMI

PCIe Quad Channel High Definition 60FPS HDMI Capture Card
View SC542N4 HDMI

SC542N4 HDMI

PCIe Quad Channel High Definition 60FPS HDMI Capture Card

  • Host: PCIe [x4, Gen2]
  • Simultaneous Video Inputs: 4
  • Video Input: 4x HDMI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50fps]
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50/30/25/24fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC542N4 SDI PCIe Quad Channel High Definition 3G-SDI Frame Grabber

Yuan

PCIe Quad Channel High Definition 3G-SDI Frame Grabber

SC542N4 SDI

PCIe Quad Channel High Definition 3G-SDI Frame Grabber
View SC542N4 SDI

SC542N4 SDI

PCIe Quad Channel High Definition 3G-SDI Frame Grabber

  • Host: PCIe [x4, Gen2]
  • Simultaneous Video Inputs: 4
  • Video Input: 4x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC542N4-L SDI PCIe Quad Channel 3G-SDI 1080P60 Video Capture Card with Hardware Compression

Yuan

PCIe Quad Channel 3G-SDI 1080P60 Video Capture Card with Hardware Compression

SC542N4-L SDI

PCIe Quad Channel 3G-SDI 1080P60 Video Capture Card with Hardware Compression

SC542N4-L SDI

PCIe Quad Channel 3G-SDI 1080P60 Video Capture Card with Hardware Compression

  • Host: PCIe [x4, Gen2]
  • Simultaneous Video Inputs: 4
  • Video Input: 4x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC542N2 HDV PCIe Dual Channel DVI-I Frame Grabber with Software Compression

Yuan

PCIe Dual Channel DVI-I Frame Grabber with Software Compression

SC542N2 HDV

PCIe Dual Channel DVI-I Frame Grabber with Software Compression
View SC542N2 HDV

SC542N2 HDV

PCIe Dual Channel DVI-I Frame Grabber with Software Compression

  • Host: PCIe [x1, Gen2]
  • Simultaneous Video Inputs: 2
  • Video Input: 2x DVI-I
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50fps]
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50/30/25/24fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC542N2-L Hybrid PCIe Dual Channel SDI/AIO Hybrid 1080P60 Video Capture Card

Yuan

PCIe Dual Channel SDI/AIO Hybrid 1080P60 Video Capture Card

SC542N2-L Hybrid

PCIe Dual Channel SDI/AIO Hybrid 1080P60 Video Capture Card

SC542N2-L Hybrid

PCIe Dual Channel SDI/AIO Hybrid 1080P60 Video Capture Card

  • Host: PCIe [x1, Gen2]
  • Simultaneous Video Inputs: 1
  • Video Input: 1x DVI-I, 1x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50fps]
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50/30/25/24fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC542N2-L HDMI PCIe 2-ch HD60 Video Capture Card with Loop Through

Yuan

PCIe 2-ch HD60 Video Capture Card with Loop Through

SC542N2-L HDMI

PCIe 2-ch HD60 Video Capture Card with Loop Through

SC542N2-L HDMI

PCIe 2-ch HD60 Video Capture Card with Loop Through

  • Host: PCIe [x1, Gen2]
  • Simultaneous Video Inputs: 2
  • Video Input: 2x HDMI
  • Max Input Resolution: 2K60 [2048x1080p @ 60/50fps], HD60 [1920x1080p @ 60/50fps]
  • Video Output: 2x HDMI
  • Max Video Capture Resolution: 2K60 [2048x1080p @ 60/50fps], HD60 [1920x1080p @ 60/50fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC542N2-L SDI PCIe 2-ch 3G-SDI Video Capture Card with Loop Through

Yuan

PCIe 2-ch 3G-SDI Video Capture Card with Loop Through

SC542N2-L SDI

PCIe 2-ch 3G-SDI Video Capture Card with Loop Through

SC542N2-L SDI

PCIe 2-ch 3G-SDI Video Capture Card with Loop Through

  • Host: PCIe [x1, Gen2]
  • Simultaneous Video Inputs: 2
  • Video Input: 2x SDI
  • Max Input Resolution: HD30 [1920x1080p @ 30/25fps]
  • Video Output: 2x SDI
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC542N1 PCIe High Definition All-In-One Video Capture Card

Yuan

PCIe High Definition All-In-One Video Capture Card

SC542N1

PCIe High Definition All-In-One Video Capture Card
View SC542N1

SC542N1

PCIe High Definition All-In-One Video Capture Card

  • Host: PCIe [x1, Gen2]
  • Simultaneous Video Inputs: 1
  • Video Input: 1x CVBS, 1x DVI-I, 1x HDMI, 1x S-Video, 1x SDI, 1x YPbPr
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50fps]
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50/30/25/24fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC542N1-L HDV Low Profile PCIe DVI-I/YPbPr/S-Video/Composite UXGA/HD60 Capture Card

Yuan

Low Profile PCIe DVI-I/YPbPr/S-Video/Composite UXGA/HD60 Capture Card

SC542N1-L HDV

Low Profile PCIe DVI-I/YPbPr/S-Video/Composite UXGA/HD60 Capture Card

SC542N1-L HDV

Low Profile PCIe DVI-I/YPbPr/S-Video/Composite UXGA/HD60 Capture Card

  • Host: PCIe [x1, Gen2]
  • Simultaneous Video Inputs: 1
  • Video Input: 1x Composite, 1x DVI-I, 1x S-Video, 1x YPbPr
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50fps]
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50/30/25/24fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC542N1-L HDAV Low Profile PCIe AIO HDMI/YPbPr/S-Video/CVBS HDAV Frame Grabber

Yuan

Low Profile PCIe AIO HDMI/YPbPr/S-Video/CVBS HDAV Frame Grabber

SC542N1-L HDAV

Low Profile PCIe AIO HDMI/YPbPr/S-Video/CVBS HDAV Frame Grabber

SC542N1-L HDAV

Low Profile PCIe AIO HDMI/YPbPr/S-Video/CVBS HDAV Frame Grabber

  • Host: PCIe [x1, Gen1]
  • Simultaneous Video Inputs: 1
  • Video Input: 1x CVBS, 1x HDMI, 1x S-Video, 1x YPbPr
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50fps]
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50/30/25/24fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC542N1-L SDI Low Profile PCIe 1080P60 3G-SDI Capture Card with Loop Through

Yuan

Low Profile PCIe 1080P60 3G-SDI Capture Card with Loop Through

SC542N1-L SDI

Low Profile PCIe 1080P60 3G-SDI Capture Card with Loop Through

SC542N1-L SDI

Low Profile PCIe 1080P60 3G-SDI Capture Card with Loop Through

  • Host: PCIe [x1, Gen1]
  • Simultaneous Video Inputs: 1
  • Video Input: 1x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Video Output: 1x 3G-SDI
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC540N1-L Low Profile PCIe SDI/DVI-I AIO UXGA/HD30 Frame Grabber

Yuan

Low Profile PCIe SDI/DVI-I AIO UXGA/HD30 Frame Grabber

SC540N1-L

Low Profile PCIe SDI/DVI-I AIO UXGA/HD30 Frame Grabber
View SC540N1-L

SC540N1-L

Low Profile PCIe SDI/DVI-I AIO UXGA/HD30 Frame Grabber

  • Host: PCIe [x1, Gen1]
  • Simultaneous Video Inputs: 1
  • Video Input: 1x DVI-I, 1x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50fps]
  • Max Video Capture Resolution: HD30 [1920x1080p @ 30/25fps], UXGA60 [1920x1200 @ 60/50/30/25/24fps]
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
SC3C0N16 PCIe 10-bit 16-ch BNC Composite SD Frame Grabber with Hardware Compression

Yuan

PCIe 10-bit 16-ch BNC Composite SD Frame Grabber with Hardware Compression

SC3C0N16

PCIe 10-bit 16-ch BNC Composite SD Frame Grabber with Hardware Compression
View SC3C0N16

SC3C0N16

PCIe 10-bit 16-ch BNC Composite SD Frame Grabber with Hardware Compression

  • Host: PCIe [x1, Gen1]
  • Simultaneous Video Inputs: 16
  • Video Input: 16x Composite
  • Max Input Resolution: 480p30 [960x480 @ 30fps], 576p25 [960x576 @ 25fps]
  • Max Video Capture Resolution: 480p30 [960x480 @ 30fps], 576p25 [960x576 @ 25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: YUY2, YV12
SC3C0N8-L PCIe 10-bit 8-ch BNC Composite SD Capture Card with Hardware Encoder

Yuan

PCIe 10-bit 8-ch BNC Composite SD Capture Card with Hardware Encoder

SC3C0N8-L

PCIe 10-bit 8-ch BNC Composite SD Capture Card with Hardware Encoder
View SC3C0N8-L

SC3C0N8-L

PCIe 10-bit 8-ch BNC Composite SD Capture Card with Hardware Encoder

  • Host: PCIe [x1, Gen1]
  • Simultaneous Video Inputs: 8
  • Video Input: 8x Composite
  • Max Input Resolution: 480p30 [960x480 @ 30fps], 576p25 [960x576 @ 25fps]
  • Max Video Capture Resolution: 480p30 [960x480 @ 30fps], 576p25 [960x576 @ 25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: YUY2, YV12
Displaying of 97 items
