PCIe Video Capture Cards

Our PCIe video capture cards accept high-channel input signals from HDMI, DP, DVI, SDI, TVI, VGA, S-Video, YPbPr, and Composite video sources.

Loading...

Video Capture

Displaying of 97 items
View All

Yuan

SC5C0N2-L HDMI

PCIe 2-ch UXGA/HD60 HDMI Capture Card with Hardware Compression

SC5C0N2-L HDMI

PCIe 2-ch UXGA/HD60 HDMI Capture Card with Hardware Compression

  • Host: PCIe [x1, Gen2]
  • Simultaneous Video Inputs: 2
  • Video Input: 2x HDMI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50fps]
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps], UXGA30 [1920x1200 @ 30/25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5C0N2-L SDI

PCIe 2-ch 3G-SDI Frame Grabber with Loop Through and Hardware Encoder

SC5C0N2-L SDI

PCIe 2-ch 3G-SDI Frame Grabber with Loop Through and Hardware Encoder

  • Host: PCIe [x1, Gen2]
  • Simultaneous Video Inputs: 2
  • Video Input: 2x 3G-SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Video Output: 2x SDI
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5C0N1

PCIe AIO SDI UXGA/1080P60 Capture Card with HardwareEncoder
View SC5C0N1

SC5C0N1

PCIe AIO SDI UXGA/1080P60 Capture Card with HardwareEncoder

  • Host: PCIe [x1, Gen1]
  • Simultaneous Video Inputs: 1
  • Video Input: 1x Composite, 1x DVI-I, 1x HDMI, 1x S-Video, 1x SDI, 1x YPbPr
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50fps]
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps], UXGA30 [1920x1200 @ 30/25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5C0N1-L

PCIe HD60/UXGA SDI/DVI Frame Grabber with Hardware Compression
View SC5C0N1-L

SC5C0N1-L

PCIe HD60/UXGA SDI/DVI Frame Grabber with Hardware Compression

  • Host: PCIe [x1, Gen1]
  • Simultaneous Video Inputs: 1
  • Video Input: 1x DVI-I, 1x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50fps]
  • Max Video Capture Resolution: HD30 [1920x1080p @ 30/25fps], UXGA30 [1920x1200 @ 30/25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5C0N1-L HDV

PCIe DVI-I Video Capture Card with DVI Loop Through Output

SC5C0N1-L HDV

PCIe DVI-I Video Capture Card with DVI Loop Through Output

  • Host: PCIe [x1, Gen1]
  • Simultaneous Video Inputs: 1
  • Video Input: 1x DVI-I
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps], UXGA60 [1920x1200 @ 60/50fps]
  • Video Output: 1x Composite, 1x DVI-I, 1x S-Video, 1x YPbPr
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps], UXGA30 [1920x1200 @ 30/25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5C0N1-L SDI

PCIe 3G-SDI Capture Card with Loop Through and Hardware Encoder

SC5C0N1-L SDI

PCIe 3G-SDI Capture Card with Loop Through and Hardware Encoder

  • Host: PCIe [x1, Gen1]
  • Simultaneous Video Inputs: 1
  • Video Input: 1x 3G-SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Video Output: 1x SDI
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5A0N8 HDMI

PCIe 8-ch HDMI Frame Grabber with Hardware Compression
View SC5A0N8 HDMI

SC5A0N8 HDMI

PCIe 8-ch HDMI Frame Grabber with Hardware Compression

  • Host: PCIe [x4, Gen2]
  • Simultaneous Video Inputs: 8
  • Video Input: 8x HDMI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Max Video Capture Resolution: HD30 [1920x1080p @ 30/25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5A0N8 SDI

PCIe 8-ch HD-SDI Capture Card with Hardware Encoder
View SC5A0N8 SDI

SC5A0N8 SDI

PCIe 8-ch HD-SDI Capture Card with Hardware Encoder

  • Host: PCIe [x4, Gen2]
  • Simultaneous Video Inputs: 8
  • Video Input: 8x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Max Video Capture Resolution: HD30 [1920x1080p @ 30/25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5A0N6 Hybrid

PCIe 6-ch 1080P30 SDI/DVI Video Capture Card with Hardware Encoder

SC5A0N6 Hybrid

PCIe 6-ch 1080P30 SDI/DVI Video Capture Card with Hardware Encoder

  • Host: PCIe [x4, Gen2]
  • Simultaneous Video Inputs: 6
  • Video Input: 1x DVI-A, 1x DVI-D, 5x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Max Video Capture Resolution: HD30 [1920x1080p @ 30/25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5A0N4 Hybrid

PCIe 4-ch HD30 SDI/DVI Frame Grabber with Hardware Compression

SC5A0N4 Hybrid

PCIe 4-ch HD30 SDI/DVI Frame Grabber with Hardware Compression

  • Host: PCIe [x4, Gen2]
  • Simultaneous Video Inputs: 4
  • Video Input: 1x DVI-A, 1x DVI-D, 4x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Max Video Capture Resolution: HD30 [1920x1080p @ 30/25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5A0N4 SDI

PCIe 4-ch 1080P30 SDI Capture Card with Hardware Compression
View SC5A0N4 SDI

SC5A0N4 SDI

PCIe 4-ch 1080P30 SDI Capture Card with Hardware Compression

  • Host: PCIe [x4, Gen2]
  • Simultaneous Video Inputs: 4
  • Video Input: 4x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Max Video Capture Resolution: HD30 [1920x1080p @ 30/25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5A0N4-L SDI

PCIe 4-ch SDI Input Video Capture Card with Hardware Encoder

SC5A0N4-L SDI

PCIe 4-ch SDI Input Video Capture Card with Hardware Encoder

  • Host: PCIe [x4, Gen2]
  • Simultaneous Video Inputs: 4
  • Video Input: 4x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Max Video Capture Resolution: HD30 [1920x1080p @ 30/25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5A0N2 HDV

PCIe 2-ch DVI-D/DVI-A Capture Card with Hardware Compression
View SC5A0N2 HDV

SC5A0N2 HDV

PCIe 2-ch DVI-D/DVI-A Capture Card with Hardware Compression

  • Host: PCIe [x1, Gen2]
  • Simultaneous Video Inputs: 2
  • Video Input: 2x DVI-A, 2x DVI-D
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Max Video Capture Resolution: HD30 [1920x1080p @ 30/25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5A0N2-L Hybrid

PCIe 2-ch DVI-I/SDI Frame Grabber with Hardware Encoder

SC5A0N2-L Hybrid

PCIe 2-ch DVI-I/SDI Frame Grabber with Hardware Encoder

  • Host: PCIe [x1, Gen2]
  • Simultaneous Video Inputs: 2
  • Video Input: 1x DVI-I, 1x SDI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Max Video Capture Resolution: HD60 [1920x1080p @ 60/50fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12

Yuan

SC5A0N2-L HDMI

PCIe 2-ch HDMI Capture Card with 2-ch HDMI Loop Through Output

SC5A0N2-L HDMI

PCIe 2-ch HDMI Capture Card with 2-ch HDMI Loop Through Output

  • Host: PCIe [x1, Gen2]
  • Simultaneous Video Inputs: 2
  • Video Input: 2x HDMI
  • Max Input Resolution: HD60 [1920x1080p @ 60/50fps]
  • Video Output: 2x HDMI
  • Max Video Capture Resolution: HD30 [1920x1080p @ 30/25fps]
  • Recording Mode: Hardware Compression
  • Colour Formats: NV12, RGB24, RGB32, YUY2, YV12
Displaying of 97 items
