DFI

EN50155 MXM GPU Computer

RC300-CS

EN50155 MXM GPU Computer

Available in 3 variations

View RC300L-CS111 RC300-CS Datasheet

View RC300H-CS122 RC300-CS Datasheet

View RC300H-CS111 RC300-CS Datasheet

RC300-CS

Available in 3 variations

CPU: 8th Gen Coffee Lake, 9th Gen Coffee Lake
Memory: 2x DDR4 2400MHz SO-DIMM, 16GB
OS: Linux
AI Accelerator: Optional Graphics Cards
Display Outputs: 1x Display Port, 1x HDMI, 1x VGA
Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [M12] [PoE]
USB: 2 x USB 2.0 [Type A], 4 x USB 3.0 [Type A]
Serial: 2x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe x1/USB/SIM] [3042/3052], 1x M.2 M-Key [PCIe x4/SATA] [2242/2260/2280], 1x M.2 M-Key [PCIe x4] [2280]
mPCIe: 1 x Half-Size mPCIe [PCIe, USB], 2x mPCIe [PCIe/SIM/USB]
Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
Power: 9-36V DC Input [Terminal Block]
Temp: -25°C to 55°C [-13°F to 131°F], -25°C to 70°C [-13°F to 158°F]
Certification: CE, EN50155, FCC
Mounting Options: Wall Mount

CPU: 8th Gen Coffee Lake, 9th Gen Coffee Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 32GB
OS: Linux
AI Accelerator: Optional Graphics Cards
Display Outputs: 1x Display Port, 1x HDMI, 1x VGA
Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [M12] [PoE]
USB: 2 x USB 2.0 [Type A], 4 x USB 3.0 [Type A]
Serial: 2x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe x1/USB/SIM] [3042/3052], 1x M.2 M-Key [PCIe x4/SATA] [2242/2260/2280], 1x M.2 M-Key [PCIe x4] [2280]
mPCIe: 1 x Half-Size mPCIe [PCIe, USB], 2x mPCIe [PCIe/SIM/USB]
Storage: 1x M.2 SSD, 4x 2.5" HDD/SSD
Power: 110V DC Input [Terminal Block]
Temp: -25°C to 55°C [-13°F to 131°F], -25°C to 70°C [-13°F to 158°F]
Certification: CE, EN50155, FCC
Mounting Options: Wall Mount

CPU: 8th Gen Coffee Lake, 9th Gen Coffee Lake
Memory: 2x DDR4 2400MHz SO-DIMM, 16GB
OS: Linux
AI Accelerator: Optional Graphics Cards
Display Outputs: 1x Display Port, 1x HDMI, 1x VGA
Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [M12] [PoE]
USB: 2 x USB 2.0 [Type A], 4 x USB 3.0 [Type A]
Serial: 2x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe x1/USB/SIM] [3042/3052], 1x M.2 M-Key [PCIe x4/SATA] [2242/2260/2280], 1x M.2 M-Key [PCIe x4] [2280]
mPCIe: 1 x Half-Size mPCIe [PCIe, USB], 2x mPCIe [PCIe/SIM/USB]
Storage: 1x M.2 SSD, 4x 2.5" HDD/SSD
Power: 110V DC Input [Terminal Block]
Temp: -25°C to 55°C [-13°F to 131°F], -25°C to 70°C [-13°F to 158°F]
Certification: CE, EN50155, FCC
Mounting Options: Wall Mount

DFI

Wide Temp Quad Core SBC with PoE-PD

AL05P

Wide Temp Quad Core SBC with PoE-PD

Available in 5 variations

View AL05P-EC-23E40 AL05P Datasheet

View AL05P-EC-23E30 AL05P Datasheet

View AL05P-BC-23N50 AL05P Datasheet

View AL05P-BC-23E40 AL05P Datasheet

View AL05P-BC-23E30 AL05P Datasheet

AL05P

Available in 5 variations

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR4 2400MHz SDRAM Slot, 4GB
OS: Linux
Display Outputs: 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45] [PoE-PD]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 16GB eMMC, 1x M.2 SSD, 32GB eMMC, 64GB eMMC
Power: PoE Powered Device (PD) [RJ45]
Temp: -20°C to 70°C [-4°F to 158°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR4 2400MHz SDRAM Slot, 4GB
OS: Linux
Display Outputs: 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45] [PoE-PD]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 16GB eMMC, 1x M.2 SSD, 32GB eMMC, 64GB eMMC
Power: PoE Powered Device (PD) [RJ45]
Temp: -20°C to 70°C [-4°F to 158°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR4 2400MHz SDRAM Slot, 4GB
OS: Linux
Display Outputs: 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45] [PoE-PD]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 16GB eMMC, 1x M.2 SSD, 32GB eMMC, 64GB eMMC
Power: PoE Powered Device (PD) [RJ45]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR4 2400MHz SDRAM Slot, 4GB
OS: Linux
Display Outputs: 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45] [PoE-PD]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 16GB eMMC, 1x M.2 SSD, 32GB eMMC, 64GB eMMC
Power: PoE Powered Device (PD) [RJ45]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR4 2400MHz SDRAM Slot, 4GB
OS: Linux
Display Outputs: 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45] [PoE-PD]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 16GB eMMC, 1x M.2 SSD, 32GB eMMC, 64GB eMMC
Power: PoE Powered Device (PD) [RJ45]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

DFI

Extended Temp 2.5″ SBC with Quad Core Atom CPU

AL053

Extended Temp 2.5″ SBC with Quad Core Atom CPU

Available in 7 variations

View AL053-TC-E3950 AL053 Datasheet

View AL053-TC-E3930 AL053 Datasheet

View AL053-EC-E3930 AL053 Datasheet

View AL053-BC-N3350 AL053 Datasheet

View AL053-BC-E3950 AL053 Datasheet

View AL053-BC-E3940 AL053 Datasheet

View AL053-BC-E3930 AL053 Datasheet

AL053

Available in 7 variations

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC Input [Terminal Block]
Temp: -40°C to 85°C [-40°F to 185°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC Input [Terminal Block]
Temp: -40°C to 85°C [-40°F to 185°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC Input [Terminal Block]
Temp: -20°C to 70°C [-4°F to 158°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC Input [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC Input [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC Input [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC Input [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

DFI

Compact Quad Core Single Board Computer

AL051

Compact Quad Core Single Board Computer

Available in 6 variations

View AL051-TC-E3930 AL051 Datasheet

View AL051-EC-E3930 AL051 Datasheet

View AL051-BC-N3350 AL051 Datasheet

View AL051-BC-E3950 AL051 Datasheet

View AL051-BC-E3940 AL051 Datasheet

View AL051-BC-E3930 AL051 Datasheet

AL051

Available in 6 variations

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [Terminal Block]
Temp: -40°C to 85°C [-40°F to 185°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [Terminal Block]
Temp: -20°C to 70°C [-4°F to 158°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Apollo Lake, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux
Display Outputs: 1x LVDS, 1x Mini Display Port, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

DFI

Intel Celeron 3965U Wide Temperature Dual Core SBC

KU551

Intel Celeron 3965U Wide Temperature Dual Core SBC

Available in 8 variations

View KU551-EN-3965U KU551 Datasheet

View KU551-EN-7100U KU551 Datasheet

View KU551-EN-7300U KU551 Datasheet

View KU551-EN-7600U KU551 Datasheet

View KU551-BN-3965U KU551 Datasheet

View KU551-BN-7100U KU551 Datasheet

View KU551-BN-7300U KU551 Datasheet

View KU551-BN-7600U KU551 Datasheet

KU551

Available in 8 variations

CPU: Intel Core 7th Generation Kaby Lake Processors, Celeron 3000 Series Kaby Lake
Memory: 1x DDR4 2133MHz SO-DIMM Slot, 16GB
OS: Linux
Display Outputs: 1x Display Port, 1x eDP, 1x LVDS, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 4 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: Intel Core 7th Generation Kaby Lake Processors, Celeron 3000 Series Kaby Lake
Memory: 1x DDR4 2133MHz SO-DIMM Slot, 16GB
OS: Linux
Display Outputs: 1x Display Port, 1x eDP, 1x LVDS, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 4 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: Intel Core 7th Generation Kaby Lake Processors, Celeron 3000 Series Kaby Lake
Memory: 1x DDR4 2133MHz SO-DIMM Slot, 16GB
OS: Linux
Display Outputs: 1x Display Port, 1x eDP, 1x LVDS, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 4 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: Intel Core 7th Generation Kaby Lake Processors, Celeron 3000 Series Kaby Lake
Memory: 1x DDR4 2133MHz SO-DIMM Slot, 16GB
OS: Linux
Display Outputs: 1x Display Port, 1x eDP, 1x LVDS, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 4 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: Intel Core 7th Generation Kaby Lake Processors, Celeron 3000 Series Kaby Lake
Memory: 1x DDR4 2133MHz SO-DIMM Slot, 16GB
OS: Linux
Display Outputs: 1x Display Port, 1x eDP, 1x LVDS, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 4 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: Intel Core 7th Generation Kaby Lake Processors, Celeron 3000 Series Kaby Lake
Memory: 1x DDR4 2133MHz SO-DIMM Slot, 16GB
OS: Linux
Display Outputs: 1x Display Port, 1x eDP, 1x LVDS, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 4 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: Intel Core 7th Generation Kaby Lake Processors, Celeron 3000 Series Kaby Lake
Memory: 1x DDR4 2133MHz SO-DIMM Slot, 16GB
OS: Linux
Display Outputs: 1x Display Port, 1x eDP, 1x LVDS, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 4 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: Intel Core 7th Generation Kaby Lake Processors, Celeron 3000 Series Kaby Lake
Memory: 1x DDR4 2133MHz SO-DIMM Slot, 16GB
OS: Linux
Display Outputs: 1x Display Port, 1x eDP, 1x LVDS, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 4 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

DFI

Industrial Grade Mini ITX Elkhart Lake Motherboard with VGA and HDMI

EHL173

Industrial Grade Mini ITX Elkhart Lake Motherboard with VGA and HDMI

Available in 4 variations

View EHL173-CT-6413 EHL173 Datasheet

View EHL173-CT-6413E EHL173 Datasheet

View EHL173-CT-6211E EHL173 Datasheet

View EHL173-CT-6425E EHL173 Datasheet

EHL173

Available in 4 variations

CPU: Celeron J Series Elkhart Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x eDP, 1x HDMI, 1x LVDS
Ethernet: 2 x 2.5 GbE LAN [RJ45]
USB: 2 x USB 3.1 Gen 1 [Type A], 2 x USB 3.2 Gen 2 [Type A], 4 x USB 2.0 [Board]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/2280/3042], 1x M.2 E-Key [PCIe/USB] [3042/3052]
PCIe: 1x PCIe [x4 Slot]
Storage: 1x M.2 SSD, 2x SATA Ports
Power: 9-36V DC [Barrel Connector]
Temp: -5°C to 65°C [23°F to 149°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Elkhart Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x eDP, 1x HDMI, 1x LVDS
Ethernet: 2 x 2.5 GbE LAN [RJ45]
USB: 2 x USB 3.1 Gen 1 [Type A], 2 x USB 3.2 Gen 2 [Type A], 4 x USB 2.0 [Board]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/2280/3042], 1x M.2 E-Key [PCIe/USB] [3042/3052]
PCIe: 1x PCIe [x4 Slot]
Storage: 1x M.2 SSD, 2x SATA Ports
Power: 9-36V DC [Barrel Connector]
Temp: -40°C to 85°C [-40°F to 185°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Elkhart Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x eDP, 1x HDMI, 1x LVDS
Ethernet: 2 x 2.5 GbE LAN [RJ45]
USB: 2 x USB 3.1 Gen 1 [Type A], 2 x USB 3.2 Gen 2 [Type A], 4 x USB 2.0 [Board]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/2280/3042], 1x M.2 E-Key [PCIe/USB] [3042/3052]
PCIe: 1x PCIe [x4 Slot]
Storage: 1x M.2 SSD, 2x SATA Ports
Power: 9-36V DC [Barrel Connector]
Temp: -40°C to 85°C [-40°F to 185°F]
Certification: CE, FCC, UKCA

CPU: Atom X Series Elkhart Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x eDP, 1x HDMI, 1x LVDS
Ethernet: 2 x 2.5 GbE LAN [RJ45]
USB: 2 x USB 3.1 Gen 1 [Type A], 2 x USB 3.2 Gen 2 [Type A], 4 x USB 2.0 [Board]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/2280/3042], 1x M.2 E-Key [PCIe/USB] [3042/3052]
PCIe: 1x PCIe [x4 Slot]
Storage: 1x M.2 SSD, 2x SATA Ports
Power: 9-36V DC [Barrel Connector]
Temp: -40°C to 85°C [-40°F to 185°F]
Certification: CE, FCC, UKCA

DFI

12V DC Industrial Mini-ITX Embedded Motherboard with Celeron Elkhart Lake J6413 CPU

EHL171

12V DC Industrial Mini-ITX Embedded Motherboard with Celeron Elkhart Lake J6413 CPU

Available in 2 variations

View EHL171-CT-6413 EHL171 Datasheet

EHL171

Available in 2 variations

CPU: Celeron J Series Elkhart Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x eDP, 1x HDMI, 1x LVDS
Ethernet: 2 x 2.5 GbE LAN [RJ45]
USB: 2 x USB 3.1 Gen 1 [Type A], 2 x USB 3.2 Gen 2 [Type A], 4 x USB 2.0 [Board]
Serial: 2 x RS232/422/485 [Board], 4 x RS232 [Board]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242/2280/3042], 1x M.2 E-Key [PCIe/USB] [3042/3052]
PCIe: 1x PCIe [x4 Slot]
Storage: 1x M.2 SSD, 2x SATA Ports
Power: 12V DC [Barrel Connector]
Temp: -5°C to 65°C [23°F to 149°F]
Certification: CE, FCC, UKCA

DFI

Pico ITX Fanless Motherboard with Celeron 4305UE

WL051

Pico ITX Fanless Motherboard with Celeron 4305UE

Available in 8 variations

View WL051-ECC-4305UE WL051 Datasheet

View WL051-ECC-8145UE WL051 Datasheet

View WL051-ECC-8365UE WL051 Datasheet

View WL051-ECC-8665UE WL051 Datasheet

View WL051-BCA-4305UE WL051 Datasheet

View WL051-BCA-8145UE WL051 Datasheet

View WL051-BCA-8365UE WL051 Datasheet

View WL051-BCA-8665UE WL051 Datasheet

WL051

Available in 8 variations

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI, 1x eDP
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 12V DC [Terminal Block]
Temp: -30°C to 80°C [-22°F to 176°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI, 1x eDP
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 12V DC [Terminal Block]
Temp: -30°C to 80°C [-22°F to 176°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI, 1x eDP
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 12V DC [Terminal Block]
Temp: -30°C to 80°C [-22°F to 176°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI, 1x eDP
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 12V DC [Terminal Block]
Temp: -30°C to 80°C [-22°F to 176°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI, 1x eDP
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 12V DC [Terminal Block]
Temp: -5°C to 60°C [23°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI, 1x eDP
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 12V DC [Terminal Block]
Temp: -5°C to 60°C [23°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI, 1x eDP
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 12V DC [Terminal Block]
Temp: -5°C to 60°C [23°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI, 1x eDP
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 12V DC [Terminal Block]
Temp: -5°C to 60°C [23°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

DFI

AMD Ryzen 3.5″ Single Board Computer with LVDS

GH551

AMD Ryzen 3.5″ Single Board Computer with LVDS

Available in 10 variations

View GH551-BC1-R2312 GH551 Datasheet

View GH551-BC1-R2314 GH551 Datasheet

View GH551-BC1-R2514 GH551 Datasheet

View GH551-EC1-R1606G GH551 Datasheet

View GH551-EC1-V1605B GH551 Datasheet

View GH551-BC1-R1505G GH551 Datasheet

View GH551-BC1-R1606G GH551 Datasheet

View GH551-EC1-V1404I GH551 Datasheet

View GH551-BC1-V1202B GH551 Datasheet

View GH551-BC1-V1605B GH551 Datasheet

GH551

Available in 10 variations

CPU: R-Series
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux, Windows 10
Display Outputs: 1x LVDS, 2x Display Port
Ethernet: 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Board], 1 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 M-Key [PCIe x4] [2242/2280]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: -5°C to 65°C [23°F to 149°F]
Certification: CE, FCC, RoHS

CPU: R-Series
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux, Windows 10
Display Outputs: 1x LVDS, 3x Display Port
Ethernet: 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Board], 1 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 M-Key [PCIe x4] [2242/2280]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: -5°C to 65°C [23°F to 149°F]
Certification: CE, FCC, RoHS

CPU: R-Series
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux, Windows 10
Display Outputs: 4x Display Ports
Ethernet: 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Board], 1 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 M-Key [PCIe x4] [2242/2280]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: -5°C to 65°C [23°F to 149°F]
Certification: CE, FCC, RoHS

CPU: R-Series
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux, Windows 10
Display Outputs: 3x Display Port
Ethernet: 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Board], 1 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 M-Key [PCIe x4] [2242/2280]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: -30°C to 80°C [-22°F to 176°F]
Certification: CE, FCC, RoHS

CPU: V-Series
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux, Windows 10
Display Outputs: 4x Display Ports
Ethernet: 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Board], 1 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 M-Key [PCIe x4] [2242/2280]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: -30°C to 80°C [-22°F to 176°F]
Certification: CE, FCC, RoHS

CPU: R-Series
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux, Windows 10
Display Outputs: 1x LVDS, 2x Display Port
Ethernet: 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Board], 1 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 M-Key [PCIe x4] [2242/2280]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: -5°C to 65°C [23°F to 149°F]
Certification: CE, FCC, RoHS

CPU: R-Series
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux, Windows 10
Display Outputs: 3x Display Port
Ethernet: 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Board], 1 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 M-Key [PCIe x4] [2242/2280]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: -5°C to 65°C [23°F to 149°F]
Certification: CE, FCC, RoHS

CPU: V-Series
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux, Windows 10
Display Outputs: 4x Display Ports
Ethernet: 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Board], 1 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 M-Key [PCIe x4] [2242/2280]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: -30°C to 80°C [-22°F to 176°F]
Certification: CE, FCC, RoHS

CPU: V-Series
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux, Windows 10
Display Outputs: 1x LVDS, 3x Display Port
Ethernet: 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Board], 1 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 M-Key [PCIe x4] [2242/2280]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: -5°C to 65°C [23°F to 149°F]
Certification: CE, FCC, RoHS

CPU: V-Series
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux, Windows 10
Display Outputs: 4x Display Ports
Ethernet: 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Board], 1 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 M-Key [PCIe x4] [2242/2280]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 12V DC [4-Pin]
Temp: -5°C to 65°C [23°F to 149°F]
Certification: CE, FCC, RoHS

DFI

3.5″ Wide Temp Intel Celeron Single Board Computer with M.2 Expansion

WL551

3.5″ Wide Temp Intel Celeron Single Board Computer with M.2 Expansion

Available in 8 variations

View WL551-ECI-4305UE WL551 Datasheet

View WL551-ECI-8145UE WL551 Datasheet

View WL551-ECI-8365UE WL551 Datasheet

View WL551-ECI-8665UE WL551 Datasheet

View WL551-BCI-4305UE WL551 Datasheet

View WL551-BCI-8145UE WL551 Datasheet

View WL551-BCI-8365UE WL551 Datasheet

View WL551-BCI-8665UE WL551 Datasheet

WL551

Available in 8 variations

WL551

Available in 8 variations

WL551

Available in 8 variations

WL551

Available in 8 variations

WL551

Available in 8 variations

WL551

Available in 8 variations

WL551

Available in 8 variations

WL551

Available in 8 variations

DFI

Intel Atom x7-E3950 Mini IP67 Computer with HDMI Display

ECX700-AL

Intel Atom x7-E3950 Mini IP67 Computer with HDMI Display

Available in 6 variations

View 750-ECX700-600G ECX700-AL Datasheet

View 750-ECX700-500G ECX700-AL Datasheet

View 750-ECX700-400G ECX700-AL Datasheet

View 750-ECX700-300G ECX700-AL Datasheet

View 750-ECX700-200G ECX700-AL Datasheet

View 750-ECX700-100G ECX700-AL Datasheet

ECX700-AL

Available in 6 variations

ECX700-AL

Available in 6 variations

ECX700-AL

Available in 6 variations

ECX700-AL

Available in 6 variations

ECX700-AL

Available in 6 variations

ECX700-AL

Available in 6 variations

DFI

Dual Core Celeron 4305UE Rugged Extended Temperature 2.5″ Pico-ITX SBC

WL053

Dual Core Celeron 4305UE Rugged Extended Temperature 2.5″ Pico-ITX SBC

Available in 8 variations

View WL053-ECA-4305UE WL053 Datasheet

View WL053-ECA-8145UE WL053 Datasheet

View WL053-ECA-8365UE WL053 Datasheet

View WL053-ECA-8665UE WL053 Datasheet

View WL053-BCA-4305UE WL053 Datasheet

View WL053-BCA-8145UE WL053 Datasheet

View WL053-BCA-8365UE WL053 Datasheet

View WL053-BCA-8665UE WL053 Datasheet

WL053

Available in 8 variations

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 9-36V DC Input [Terminal Block]
Temp: -30°C to 80°C [-22°F to 176°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 9-36V DC Input [Terminal Block]
Temp: -30°C to 80°C [-22°F to 176°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 9-36V DC Input [Terminal Block]
Temp: -30°C to 80°C [-22°F to 176°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 9-36V DC Input [Terminal Block]
Temp: -30°C to 80°C [-22°F to 176°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 9-36V DC Input [Terminal Block]
Temp: -5°C to 60°C [23°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 9-36V DC Input [Terminal Block]
Temp: -5°C to 60°C [23°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 9-36V DC Input [Terminal Block]
Temp: -5°C to 60°C [23°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

CPU: 8th Gen Whiskey Lake
Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port / HDMI
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 B-Key [PCIe/USB/SATA] [2242/3042]
Storage: 2x M.2 SSD
Power: 9-36V DC Input [Terminal Block]
Temp: -5°C to 60°C [23°F to 147°F]
Certification: CE, FCC, RoHS, UKCA

DFI

1.8″ Industrial Dual Core Ryzen SBC with R2312 CPU

PCSF51

1.8″ Industrial Dual Core Ryzen SBC with R2312 CPU

Available in 3 variations

View PCSF51-BN-46R232 PCSF51 Datasheet

View PCSF51-BN-46R234 PCSF51 Datasheet

View PCSF51-BN-46R254 PCSF51 Datasheet

PCSF51

Available in 3 variations

CPU: R2000
Memory: 8GB Soldered On-board
OS: Linux Ubuntu 20.04, Windows 10, Windows 11
Display Outputs: 1x HDMI
Ethernet: 1 x GbE LAN [RJ45]
USB: 1 x USB 3.1 Gen 1 [Type A]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
Storage: 128GB eMMC
Power: 12V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

CPU: R2000
Memory: 8GB Soldered On-board
OS: Linux Ubuntu 20.04, Windows 10, Windows 11
Display Outputs: 1x HDMI
Ethernet: 1 x GbE LAN [RJ45]
USB: 1 x USB 3.1 Gen 1 [Type A]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
Storage: 128GB eMMC
Power: 12V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

CPU: R2000
Memory: 8GB Soldered On-board
OS: Linux Ubuntu 20.04, Windows 10, Windows 11
Display Outputs: 1x HDMI
Ethernet: 1 x GbE LAN [RJ45]
USB: 1 x USB 3.1 Gen 1 [Type A]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
Storage: 128GB eMMC
Power: 12V DC [Terminal Block]
Temp: 0°C to 60°C [32°F to 147°F]
Certification: CE, FCC, UKCA

DFI

Extended Temperature Elkhart Lake 3.5″ Single Board Computer

EHL556

Extended Temperature Elkhart Lake 3.5″ Single Board Computer

Available in 3 variations

View 770-EHL5561-200G EHL556 Datasheet

View 770-EHL5561-100G EHL556 Datasheet

View 770-EHL5561-000G EHL556 Datasheet

EHL556

Available in 3 variations

CPU: Atom X Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x LVDS, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 3.2 Gen 2 [Type A], 4 x USB 2.0 [Board]
Serial: 1 x RS232 [Board], 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [SATA] [2280], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC [Barrel Connector]
Temp: -40°C to 85°C [-40°F to 185°F]
Certification: CE, FCC

CPU: Atom X Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x LVDS, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 3.2 Gen 2 [Type A], 4 x USB 2.0 [Board]
Serial: 1 x RS232 [Board], 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [SATA] [2280], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC [Barrel Connector]
Temp: -40°C to 85°C [-40°F to 185°F]
Certification: CE, FCC

CPU: Celeron N Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 32GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x eDP, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 3.2 Gen 2 [Type A], 4 x USB 2.0 [Board]
Serial: 1 x RS232 [Board], 1 x RS232/422/485 [Board]
M.2: 1x M.2 B-Key [SATA] [2280], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD, 1x SATA Port
Power: 9-36V DC [Barrel Connector]
Temp: -40°C to 85°C [-40°F to 185°F]
Certification: CE, FCC

DFI

Industrial Low Profile PC

EC700-AL

Industrial Low Profile PC

View EC700-AL EC700-AL Datasheet

EC700-AL

Industrial Low Profile PC

CPU: Atom X Series Apollo Lake, Celeron J Series Apollo Lake, Celeron J Series Bay Trail, Celeron N Series Apollo Lake, Pentium N Series Apollo Lake
Memory: 1x DDR3L 1333MHz SO-DIMM Slot, 8GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port, 1x VGA
Ethernet: 4 x GbE LAN [RJ45]
USB: 4 x USB 3.0 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 1 x mPCIe [SATA], 1 x mPCIe [USB/SIM]
Storage: 1x 2.5" HDD/SSD, 1x mSATA
Power: 9-36V DC [Barrel Connector]
Temp: -20°C to 60°C [-4°F to 147°F], -40°C to 70°C [-40°F to 158°F]
Certification: CE, FCC, RoHS
Mounting Options: Desktop, VESA Mount, Wall Mount

Displaying of 16 items

Official UK DFI Distributor

Tell us about your application and a member of the team will get right back to you.

T: +44(0)1785 558 300 E: [email protected]

Added to basket

Your Basket ()

Search

DFI Shop

Browse DFI's Latest Products

EN50155 MXM GPU Computer

RC300-CS

RC300-CS

Wide Temp Quad Core SBC with PoE-PD

AL05P

AL05P

Extended Temp 2.5″ SBC with Quad Core Atom CPU

AL053

AL053

Compact Quad Core Single Board Computer

AL051

AL051

Intel Celeron 3965U Wide Temperature Dual Core SBC

KU551

KU551

Industrial Grade Mini ITX Elkhart Lake Motherboard with VGA and HDMI

EHL173

EHL173

12V DC Industrial Mini-ITX Embedded Motherboard with Celeron Elkhart Lake J6413 CPU

EHL171

EHL171

Pico ITX Fanless Motherboard with Celeron 4305UE

WL051

WL051

AMD Ryzen 3.5″ Single Board Computer with LVDS

GH551

GH551

3.5″ Wide Temp Intel Celeron Single Board Computer with M.2 Expansion

WL551

WL551

WL551

WL551

WL551

WL551

WL551

WL551

WL551

Intel Atom x7-E3950 Mini IP67 Computer with HDMI Display

ECX700-AL

ECX700-AL

ECX700-AL

ECX700-AL

ECX700-AL

ECX700-AL

ECX700-AL

Dual Core Celeron 4305UE Rugged Extended Temperature 2.5″ Pico-ITX SBC

WL053

WL053

1.8″ Industrial Dual Core Ryzen SBC with R2312 CPU

PCSF51

PCSF51

Extended Temperature Elkhart Lake 3.5″ Single Board Computer

EHL556

EHL556

Industrial Low Profile PC

EC700-AL

EC700-AL

Official UK DFI Distributor
