Yuan SDVoE to 12G-SDI-F 12G-SDI SDVoE Receiver with SFP+ Fibre Input, RS232 and IR
SDVoE to 12G-SDI-F Overview
Where 12G-SDI monitors and recorders sit away from the source, the SDVoE to 12G-SDI-F is Yuan’s 12G-SDI SDVoE receiver for the display end of a fixed fibre run. It takes an SDVoE stream from the 10G network and converts it back to 12G-SDI. Yuan describes SDVoE as lossless and zero-latency, which typically suits pro AV and live production work where a delay would show.
The SDVoE input is one SFP+ port for 10G fibre, and video leaves on one 12G-SDI output that follows the format of the incoming stream, so the transmitter sets resolution and frame rate. Analogue L/R audio travels both ways through a stereo phone jack, IR passes in both directions, and RS232 runs over the same link for controlling the source or display.
A separate RJ45 port handles control, and one USB port extends USB HID devices such as a keyboard and mouse. The unit runs from a 7.5 to 15 V DC input in a rugged case and is plug and play. The 12G-SDI to SDVoE-F is the matching transmitter on the same fibre link. If one site needs both cable types, the SDVoE to 12G-SDI V2 switches between copper and fibre and adds PoE power.
Yuan does not list operating temperature, certification or mounting for the SDVoE to 12G-SDI-F, so we confirm those against the site with you. We supply the SDVoE to 12G-SDI-F configured and tested with the sources, displays and network it will connect to, so the link is proven before it reaches site.
SDVoE to 12G-SDI-F Specifications
| Overview | |
|---|---|
| Brand & Model | Yuan SDVoE to 12G-SDI-F |
| Video Capture | |
| Simultaneous Video Inputs | 1 |
| Video Input | 1x SFP+ (10G) |
| Video Output | 1x 12G-SDI |
| Streaming Protocols | SDVoE |
| Audio Input | 1x 3.5mm Audio Input |
| Audio Output | 1x 3.5mm Audio Output |
| Power | |
| Power Input | 7.5-15V DC |
| Mechanical Properties | |
| Dimensions | 152mm x 116mm x 33mm (5.98" x 4.57" x 1.30") |
Official Yuan UK Distributor
Things Embedded is an official Yuan UK distributor, and we supply the SDVoE to 12G-SDI-F configured and tested with the sources, displays and network it will connect to. Within the Yuan range, the SDVoE to 12G-SDI-C is the same receiver with an RJ45 copper input, and the SDVoE to 12G-SDI V2 switches between copper and fibre and adds PoE.
Across our range, the SDVoE to 12G-SDI-F sits with our SDVoE receivers, our AV over IP encoders, decoders and extenders and our SDVoE capture cards for PC-based capture.
