UK Front IP66 Panel PCs
Front IP66 Touch Screen PCs for Hose-Down Cabinet Fronts
Front IP66 panel PCs take powerful water jets on the bezel and touch screen while the body sits inside the cabinet, for panel-mount HMIs on lines that are hosed down rather than wiped. Available from 12.1 to 24 inches with resistive or PCAP touch, they mount like a front IP65 unit with a step up in sealing at the front.
Options include Intel Core processors and 4:3, 5:4 and full HD formats, suited to food and beverage, pharmaceutical and plant cabinet fronts where the hose reaches the door. For units sealed on all six sides, see IP66 Panel PCs.
Speak to a panel PC specialist to match the size, touch technology and format to your cabinet front.
Browse Our Front IP66 Touch Screen Computers
- IP Rating: Front IP66
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- Memory: 2x DDR3L 1866MHz SO-DIMM Slot, 8GB
- OS: Linux, Windows 10
- Display Outputs: 1x HDMI, 1x VGA
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 2.0 [Type A], 2x USB 3.0 [Type A]
- Serial: 1x RS232/422/485 [DB9], 3x RS232 [DB9]
- M.2: 1x M.2 B/M-Key [SATA] [2242]
- mPCIe: 1x mPCIe [PCIe/USB]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 9-36V DC Input, Terminal Block
- Temp: -20°C to 60°C [-4°F to 140°F]
- Certification: CE, FCC
- Touch: 5-Wire Resistive Touch
- CPU: Intel Celeron N Series Apollo Lake
- IP Rating: Front IP66
- Display: 19"[5:4, 1280 x 1024, SXGA]
- Touch: Resistive Touch
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Processor N Series Twin Lake
- OS: Windows 11
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 1x USB 3.2 [Type C], 2x USB 3.2 [Type A]
- Serial: 1x RS232 [DB9]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 9-36V DC Input, AC Power Supply Included
- Temp: -15°C to 55°C [5°F to 131°F]
- Certification: CE, FCC
- IP Rating: Front IP66
- Display: 19"[5:4, 1280 x 1024, SXGA]
- Touch: Multi Touch PCAP
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Core Series 1 Raptor Lake, Intel Core 13th Gen Raptor Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Ethernet: 2x GbE LAN [RJ45]
- Serial: 1x RS232/422/485 [DB9]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 24V DC, 9-36V DC Input, AC Power Supply Included
- Temp: -15°C to 55°C [5°F to 131°F]
- Certification: CE, DNV GL, FCC, IACS E10, IEC 60945
- IP Rating: Front IP66
- Display: 19"[5:4, 1280 x 1024, SXGA]
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Celeron J Series Elkhart Lake
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
- OS: Linux, Windows 11
- Display Outputs: 2x HDMI
- Ethernet: 2x GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 1 [Type A]
- M.2: 1x M.2 M-Key [PCIe x2/SATA] [2280]
- mPCIe: 1x mPCIe [PCIe/USB/SIM]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD [PCIe & SATA]
- Power: 12-36V DC Input [Terminal Block]
- Temp: -20°C to 60°C [-4°F to 140°F]
- IP Rating: Front IP69K
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Touch: 5-Wire Resistive Touch
- IP Rating: Front IP66
- Display: 19"[5:4, 1280 x 1024, SXGA]
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 12th Gen Alder Lake
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
- OS: Linux, Windows 11
- Display Outputs: 2x HDMI
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230], 1x M.2 M-Key [PCIe x4 Gen4/SATA] [2280]
- mPCIe: 1x mPCIe [PCIe/USB/SIM]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD [PCIe & SATA]
- Power: 9-36V DC Input [Terminal Block]
- Temp: -20°C to 60°C [-4°F to 140°F]
- IP Rating: Front IP69K
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Touch: 5-Wire Resistive Touch
- IP Rating: Front IP66
- Display: 19"[5:4, 1280 x 1024, SXGA]
- Touch: Resistive Touch
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- Display Inputs: 1x Optional HDMI Input, 1x VGA Input
- CPU: Intel Core 11th Gen Tiger Lake
- Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
- OS: Linux Ubuntu 22.04, Windows 10
- Display Outputs: 1x HDMI, 1x VGA
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 3.0 [Type A]
- Serial: 1x RS232 [DB9], 4x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [USB/SATA] [2242], 1x M.2 M-Key [PCIe x4] [2280]
- Storage: 2x M.2 SSD
- Power: 24V DC
- Temp: -15°C to 55°C [5°F to 131°F]
- Certification: CE, FCC
- IP Rating: Front IP66
- Display: 21.5"[16:9, 1920 x 1080, FHD]
- Brightness: 250
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- CPU: Intel Celeron J Series Elkhart Lake
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
- OS: Linux, Windows 11
- Display Outputs: 2x HDMI
- Ethernet: 2x GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 1 [Type A]
- M.2: 1x M.2 M-Key [PCIe x2/SATA] [2280]
- mPCIe: 1x mPCIe [PCIe/USB/SIM]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD [PCIe & SATA]
- Power: 12-36V DC Input [Terminal Block]
- Temp: -20°C to 60°C [-4°F to 140°F]
- IP Rating: Front IP69K
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Touch: 5-Wire Resistive Touch
- IP Rating: Front IP66
- Display: 21.5"[16:9, 1920 x 1080, FHD]
- Brightness: 250
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- CPU: Intel Core 12th Gen Alder Lake
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
- OS: Linux, Windows 11
- Display Outputs: 2x HDMI
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230], 1x M.2 M-Key [PCIe x4 Gen4/SATA] [2280]
- mPCIe: 1x mPCIe [PCIe/USB/SIM]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD [PCIe & SATA]
- Power: 9-36V DC Input [Terminal Block]
- Temp: -20°C to 60°C [-4°F to 140°F]
- IP Rating: Front IP69K
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Touch: 5-Wire Resistive Touch
- IP Rating: Front IP66
- Display: 23.8"[16:9, 1920 x 1080, FHD]
- Touch: Resistive Touch
- Brightness: 250
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- CPU: Intel Processor N Series Twin Lake
- OS: Windows 11
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 1x USB 3.2 [Type C], 2x USB 3.2 [Type A]
- Serial: 1x RS232 [DB9]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 9-36V DC Input, AC Power Supply Included
- Temp: -15°C to 55°C [5°F to 131°F]
- Certification: CE, FCC
- IP Rating: Front IP66
- Display: 23.8"[16:9, 1920 x 1080, FHD]
- Touch: Multi Touch PCAP
- Brightness: 250
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- CPU: Core Series 1 Raptor Lake, Intel Core 13th Gen Raptor Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Ethernet: 2x GbE LAN [RJ45]
- Serial: 1x RS232/422/485 [DB9]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 24V DC, 9-36V DC Input, AC Power Supply Included
- Temp: -15°C to 55°C [5°F to 131°F]
- Certification: CE, DNV GL, FCC, IACS E10, IEC 60945
- IP Rating: Front IP66
- Display: 24"[16:9, 1920 x 1080, FHD]
- Touch: Resistive Touch
- Brightness: 300
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- Display Inputs: 1x Optional HDMI Input, 1x VGA Input
- CPU: Intel Core 11th Gen Tiger Lake
- Memory: 1x DDR4 2400MHz SO-DIMM Slot, 32GB
- OS: Linux Ubuntu 22.04, Windows 10
- Display Outputs: 1x HDMI, 1x VGA
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 3.0 [Type A]
- Serial: 1x RS232 [DB9], 4x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [USB/SATA] [2242], 1x M.2 M-Key [PCIe x4] [2280]
- Storage: 2x M.2 SSD
- Power: 24V DC
- Temp: -15°C to 55°C [5°F to 131°F]
- Certification: CE, FCC
- IP Rating: Front IP66
- Display: 27"[16:9, 1920 x 1080, FHD]
- Touch: Multi Touch PCAP
- Brightness: 300
- Viewing Angle: Wide Viewing Angle
- Format: Widescreen
- CPU: Core Series 1 Raptor Lake, Intel Core 13th Gen Raptor Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Serial: 1x RS232 [DB9]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 24V DC, 9-36V DC Input, AC Power Supply Included
- Temp: -15°C to 55°C [5°F to 131°F]
- Certification: CE, DNV GL, FCC, IACS E10, IEC 60945
Front IP66 Panel PC Ranges Configured by Things Embedded
We work with the leading manufacturers of front IP66 panel-mount HMIs, so the ranges below are the ones we specify for hosed cabinet fronts and marine consoles. Compare them by size, processor and touch, then browse the models above or ask a panel PC specialist which range suits your cabinet.
IT3S Winmate Marine Touch Computers
Front IP66 console computers on Intel Core i7 Tiger Lake from 12.1 to 24 inches, designed for bridge and engine room consoles.
PPC-N Arestech Front IP66 HMIs
Fanless panel-mount computers with a front IP66 bezel in 15, 17 and 19 inch, on Intel Celeron, Pentium and Core i3 or i5, with PCAP or resistive touch for cabinet fronts on hosed-down lines.
Not sure which range fits? Tell us the application and we will recommend the right model.
What to Specify in a Front IP66 HMI
Our panel PC specialists specify every front IP66 panel PC against the hose, the cabinet and the operators' gloves. These are the choices that decide how a front-sealed HMI copes with a hosed cabinet front, and the ones we work through with you before recommending a range.
What Front IP66 Covers
Powerful water jets on the bezel and screen, with the body protected inside the cabinet.
15, 17 and 19 Inch
The common cabinet sizes in 4:3, 5:4 and widescreen formats.
PCAP or Resistive
PCAP for a flush glass front, resistive for gloved operators and water on the screen.
Processor Choice
From Celeron and Pentium for HMIs to Core i7 for marine and SCADA consoles.
Front IP66 Panel PC Innovation & Hose-Down Insights
Speak to a Panel PC Specialist.
Tell us where the panel PC will be mounted, what it needs to run and connect to and the sealing the area needs, and we will recommend the right size and touch technology, then configure, image and test it before it ships.
