Displaying of 1090 items

View All

R06IAN3S-OFA1 6.5″ Open Frame Panel PC with Quad-Core Intel N150 and Resistive Touch

Display: 6.5"[4:3, 640 x 480, VGA]
Touch: Optional Resistive Touch
Brightness: 700
Viewing Angle: Wide Viewing Angle
Format: Standard
CPU: Intel Processor N Series Twin Lake
Memory: 1x DDR5 4800MHz SO-DIMM, 16GB
OS: Linux Ubuntu 24.04, Windows 11
Display Outputs: 1x USB Type C
Ethernet: 2x 2.5 GbE LAN [RJ45]
USB: 1x USB 3.2 Gen 2 [Type C], 2x USB 3.2 Gen 1 [Type A]
Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
M.2: 1x M.2 E-Key [2230]
Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
Power: 12V DC [Barrel Connector], AC Power Supply Included
Temp: 0°C to 50°C [32°F to 122°F]
Certification: CE, FCC

Winmate

R06IAN3S-OFA16.5″ Open Frame Panel PC with Quad-Core Intel N150 and Resistive Touch

Datasheet

R06IE3S-PMA1 6.5″ Panel Mount Panel PC with Intel Celeron N6211 and 700 Nit VGA Screen

Display: 6.5"[4:3, 640 x 480, VGA]
Touch: Optional Resistive Touch
Brightness: 700
Viewing Angle: Wide Viewing Angle
Format: Standard
CPU: Intel Celeron N Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux Ubuntu 20.04, Windows 10, Windows 11
Ethernet: 2x GbE LAN [RJ45]
USB: 2x USB 3.2 Gen 2 [Type A]
Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB/SATA] [2242]
Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
Power: 12V DC, Optional AC Power Supply
Temp: 0°C to 50°C [32°F to 122°F]
Certification: CE, FCC

Winmate

R06IE3S-PMA16.5″ Panel Mount Panel PC with Intel Celeron N6211 and 700 Nit VGA Screen

Datasheet

R06L200-OFA1 6.5″ Open Frame Monitor with 640 x 480 LCD at 700 Nits

Display: 6.5"[4:3, 640 x 480, VGA]
Touch: Optional Resistive Touch
Brightness: 700
Viewing Angle: Wide Viewing Angle
Format: Standard
Display Inputs: 1x DVI Input, 1x HDMI Input, 1x VGA Input
Power: 12V DC
Temp: 0°C to 50°C [32°F to 122°F]
Certification: CE, FCC

Winmate

R06L200-OFA16.5″ Open Frame Monitor with 640 x 480 LCD at 700 Nits

Datasheet

M700DQ9 7″ Android Rugged Tablet with Qualcomm QCS6490 and Up to 20-Hour Battery

Display: 7"[16:9, 1280 x 720, HD]
Touch: Multi Touch PCAP
Brightness: 650
Viewing Angle: Wide Viewing Angle
Format: Widescreen
CPU: Qualcomm Dragonwing QCS6490
AI Performance: 12 TOPS
Memory: 8GB Soldered On-board
OS: Android 15.0
USB: 1x USB 3.0 [Type C]
Storage: 1x Micro SD
Power: 5V [USB-C], AC Power Supply Included
Temp: -10°C to 50°C [14°F to 122°F]
IP Rating: IP65
Certification: CE, FCC, MIL-STD-810

Winmate

M700DQ97″ Android Rugged Tablet with Qualcomm QCS6490 and Up to 20-Hour Battery

Datasheet

FM07P 7″ Forklift Computer with Intel Apollo Lake Celeron N3350 or Pentium N4200 and MIL-STD-810G

Display: 7"[17:10, 1024 x 600, WSVGA]
Touch: Multi Touch PCAP
Brightness: 1000
Viewing Angle: Wide Viewing Angle
Format: Widescreen
CPU: Intel Celeron N Series Apollo Lake, Intel Pentium N Series Apollo Lake
Memory: 1x DDR3L 1600MHz SO-DIMM Slot, 8GB
OS: Linux Ubuntu 20.04, Windows 10
Ethernet: 1x GbE LAN [M12]
M.2: 1x M.2 Slot
Storage: 1x M.2 SSD
Power: 9-36V DC Input
Ignition Sensing: Supports Ignition Control
Temp: -20°C to 60°C [-4°F to 140°F]
IP Rating: Front IP65
Certification: CE, FCC

Winmate

FM07P7″ Forklift Computer with Intel Apollo Lake Celeron N3350 or Pentium N4200 and MIL-STD-810G

Datasheet

FM07MG 7″ Android Vehicle Mount Computer with MediaTek Genio 510 and MIL-STD-810H

Display: 7"[17:10, 1024 x 600, WSVGA]
Touch: Multi Touch PCAP
Brightness: 1000
Viewing Angle: Wide Viewing Angle
Format: Widescreen
CPU: Genio 510
Memory: 4GB Soldered On-board
OS: Android 13.0, Linux Ubuntu 22.04
Ethernet: 1x GbE LAN [M12]
Serial: 1x RS232/422/485 [M12]
Storage: 1x Micro SD, 64GB eMMC
Power: 9-24V DC Input [M12]
Ignition Sensing: Supports Ignition Control
Temp: -20°C to 60°C [-4°F to 140°F]
IP Rating: IP65
Certification: CE, FCC

Winmate

FM07MG7″ Android Vehicle Mount Computer with MediaTek Genio 510 and MIL-STD-810H

Datasheet

FM07E 7″ Vehicle Mount Computer with Intel Atom x6413E and MIL-STD-810G

Display: 7"[17:10, 1024 x 600, WSVGA]
Touch: Multi Touch PCAP
Brightness: 1000
Viewing Angle: Wide Viewing Angle
Format: Widescreen
CPU: Intel Atom X Series Elkhart Lake
OS: Linux Ubuntu 22.04, Windows 11
Ethernet: 1x GbE LAN [M12]
Serial: 1x RS232/422/485 [M12]
M.2: 1x M.2 Slot
Storage: 1x M.2 SSD
Power: 9-36V DC Input [M12]
Ignition Sensing: Supports Ignition Control
Temp: -20°C to 60°C [-4°F to 140°F]
IP Rating: IP65
Certification: CE, FCC

Winmate

FM07E7″ Vehicle Mount Computer with Intel Atom x6413E and MIL-STD-810G

Datasheet

FM07 7″ Vehicle Mount Computer with Intel Celeron N3350 or Pentium N4200 and MIL-STD-810G

Display: 7"[17:10, 1024 x 600, WSVGA]
Touch: Multi Touch PCAP
Brightness: 1000
Viewing Angle: Wide Viewing Angle
Format: Widescreen
CPU: Intel Celeron N Series Apollo Lake, Intel Pentium N Series Apollo Lake
OS: Linux Ubuntu 20.04, Windows 10
Ethernet: 1x GbE LAN [M12]
Serial: 1x RS232/422/485 [M12]
M.2: 1x M.2 Slot
Storage: 1x M.2 SSD
Power: 9-36V DC Input [M12]
Ignition Sensing: Supports Ignition Control
Temp: -20°C to 60°C [-4°F to 140°F]
IP Rating: IP65
Certification: CE, E-Mark, FCC

Winmate

FM077″ Vehicle Mount Computer with Intel Celeron N3350 or Pentium N4200 and MIL-STD-810G

Datasheet

W07IE3S-GCO1HB 7″ G-WIN Front IP65 Panel PC with Intel Elkhart Lake Celeron N6211 and MIL-STD-810G

Display: 7"[17:10, 1024 x 600, WSVGA]
Touch: Multi Touch PCAP
Brightness: 1000
Viewing Angle: Wide Viewing Angle
Format: Widescreen
CPU: Intel Celeron N Series Elkhart Lake
OS: Linux Ubuntu 22.04, Windows 11
Display Outputs: 1x Optional HDMI
Ethernet: 2x 2.5 GbE LAN [RJ45]
USB: 2x USB 3.2 Gen 2 [Type A]
Serial: 1x RS232/422/485 [DB9]
Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
Power: 12V DC, AC Power Supply Included
Temp: 0°C to 50°C [32°F to 122°F]
IP Rating: Front IP65
Certification: CE, FCC
Mounting Options: VESA Mount

Winmate

W07IE3S-GCO1HB7″ G-WIN Front IP65 Panel PC with Intel Elkhart Lake Celeron N6211 and MIL-STD-810G

Datasheet

W07T700-IPO1HB 7″ Front IP65 Monitor with 1000 Nit WSVGA Display and Resistive Touch

Display: 7"[17:10, 1024 x 600, WSVGA]
Touch: Optional Resistive Touch
Brightness: 1000
Viewing Angle: Wide Viewing Angle
Format: Widescreen
Display Inputs: 1x Optional DVI Input, 1x Optional HDMI Input, 1x VGA Input
Power: 12V DC, AC Power Supply Included
Temp: 0°C to 50°C [32°F to 122°F]
IP Rating: Front IP65
Certification: CE, FCC

Winmate

W07T700-IPO1HB7″ Front IP65 Monitor with 1000 Nit WSVGA Display and Resistive Touch

Datasheet

W07T700-CHA4TR 7″ Chassis Monitor with Transflective LCD and Resistive Touch

Display: 7"[5:3, 800 x 480, WVGA]
Touch: Optional Resistive Touch
Brightness: 500
Viewing Angle: Wide Viewing Angle
Format: Widescreen
Display Inputs: 1x Optional DVI Input, 1x Optional HDMI Input, 1x VGA Input
Power: 12V DC, AC Power Supply Included
Temp: 0°C to 50°C [32°F to 122°F]
Certification: CE, FCC

Winmate

W07T700-CHA4TR7″ Chassis Monitor with Transflective LCD and Resistive Touch

Datasheet

W07IE3S-OFT1 7″ Open Frame Panel PC with Intel Celeron N6211 and Resistive Touch

Display: 7"[17:10, 1024 x 600, WSVGA]
Touch: Optional Resistive Touch
Brightness: 320
Viewing Angle: Wide Viewing Angle
Format: Widescreen
CPU: Intel Celeron N Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux Ubuntu 22.04, Windows 10, Windows 11
Ethernet: 2x 2.5 GbE LAN [RJ45]
USB: 2x USB 3.2 Gen 2 [Type A]
Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [SATA] [2242], 1x M.2 E-Key [2230]
Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
Power: 12V DC [Barrel Connector], AC Power Supply Included
Temp: 0°C to 50°C [32°F to 122°F]
Certification: CE, FCC

Winmate

W07IE3S-OFT17″ Open Frame Panel PC with Intel Celeron N6211 and Resistive Touch

Datasheet

W07IE3S-IPT1 7″ Front IP65 Panel PC with Intel Elkhart Lake Celeron N6211 and Resistive Touch

Display: 7"[17:10, 1024 x 600, WSVGA]
Touch: Optional Resistive Touch
Brightness: 320
Viewing Angle: Wide Viewing Angle
Format: Widescreen
CPU: Intel Celeron N Series Elkhart Lake
Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
OS: Linux Ubuntu 22.04, Windows 10, Windows 11
Ethernet: 2x 2.5 GbE LAN [RJ45]
USB: 2x USB 3.2 Gen 2 [Type A]
Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [SATA] [2242], 1x M.2 E-Key [2230]
Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
Power: 12V DC [Barrel Connector], AC Power Supply Included
Temp: 0°C to 50°C [32°F to 122°F]
IP Rating: Front IP65
Certification: CE, FCC

Winmate

W07IE3S-IPT17″ Front IP65 Panel PC with Intel Elkhart Lake Celeron N6211 and Resistive Touch

Datasheet

W07IE3S-PCT1AC-POE 7″ PCAP Touch Panel PC with Intel Celeron N6211 and PoE Power

Display: 7"[17:10, 1024 x 600, WSVGA]
Touch: Multi Touch PCAP
Brightness: 320
Viewing Angle: Wide Viewing Angle
Format: Widescreen
CPU: Intel Celeron N Series Elkhart Lake
OS: Linux Ubuntu 22.04, Windows 11
Ethernet: 1x 2.5 GbE LAN [RJ45] [PoE-PD], 1x 2.5 GbE LAN [RJ45]
USB: 2x USB 3.2 Gen 1 [Type A]
Serial: 1x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [SATA] [2242], 1x M.2 E-Key [2230]
Storage: 1x M.2 SSD
Power: 12V DC [Terminal Block], AC Power Supply Included, PoE Powered Device (PD) [RJ45]
Temp: 0°C to 50°C [32°F to 122°F]
IP Rating: Front IP65
Certification: CE, FCC
Mounting Options: VESA Mount, Wall Mount

Winmate

W07IE3S-PCT1AC-POE7″ PCAP Touch Panel PC with Intel Celeron N6211 and PoE Power

Datasheet

W07IE3S-PCT1-POE 7″ PCAP Touch Panel PC with Intel Elkhart Lake Celeron N6211 and PoE Power

Display: 7"[17:10, 1024 x 600, WSVGA]
Touch: Multi Touch PCAP
Brightness: 320
Viewing Angle: Wide Viewing Angle
Format: Widescreen
CPU: Intel Celeron N Series Elkhart Lake
OS: Linux Ubuntu 22.04, Windows 11
Ethernet: 1x 2.5 GbE LAN [RJ45] [PoE-PD], 1x 2.5 GbE LAN [RJ45]
USB: 2x USB 3.2 Gen 1 [Type A]
Serial: 1x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [SATA] [2242], 1x M.2 E-Key [2230]
Storage: 1x M.2 SSD
Power: 12V DC [Terminal Block], AC Power Supply Included, PoE Powered Device (PD) [RJ45]
Temp: 0°C to 50°C [32°F to 122°F]
IP Rating: Front IP65
Certification: CE, FCC
Mounting Options: VESA Mount, Wall Mount

Winmate

W07IE3S-PCT1-POE7″ PCAP Touch Panel PC with Intel Elkhart Lake Celeron N6211 and PoE Power

Datasheet
