Browse Our Rugged Orin NX Computers
- Display Outputs: 1x HDMI
- Ethernet: 1x 2.5 GbE LAN [M12] [PoE], 1x GbE LAN [M12] [PoE]
- USB: 1x USB 3.2 Gen 1 [Type A]
- Serial: 1x RS232/422/485 [M8]
- CANbus: 1x CANbus, M8
- M.2: 1x M.2 B-Key [USB] [3042/3052], 1x M.2 E-Key [USB] [2230]
- Storage: 1x M.2 SSD
- Power: 9-60V DC Input [M12]
- Ignition Sensing: Supports Ignition Control
- Temp: -40°C to 60°C [-40°F to 140°F]
- IP Rating: IP66
- Certification: CE, E-Mark, EN50155, FCC
- AI Performance: 70 TOPS
- SOM: NVIDIA Jetson Orin NX 8GB
-
IBOX-600-IP66-ONX8
IBOX-600-IP66 with NVIDIA Jetson Orin NX 8GB and NVDLA accelerator -
IBOX-600-IP66-ON4
IBOX-600-IP66 with NVIDIA Jetson Orin Nano 4GB and 512-core GPU -
IBOX-600-IP66-ON8
IBOX-600-IP66 with NVIDIA Jetson Orin Nano 8GB and 1024-core GPU -
IBOX-600-IP66-ONX16
IBOX-600-IP66 with NVIDIA Jetson Orin NX 16GB and dual NVDLA accelerators
- Display Outputs: 1x HDMI
- Ethernet: 1x 2.5 GbE LAN [M12], 1x GbE LAN [M12]
- USB: 2x USB 3.2 Gen 1 [Type A]
- Serial: 1x RS232/422/485 [M8]
- CANbus: 1x CANbus, M8
- M.2: 1x M.2 B-Key [USB] [3042/3052], 1x M.2 E-Key [USB] [2230]
- mPCIe: 1x mPCIe [USB]
- Storage: 1x M.2 SSD
- Power: 9-60V DC Input [M12]
- Ignition Sensing: Supports Ignition Control
- Temp: -25°C to 70°C [-13°F to 158°F]
- IP Rating: IP66
- Certification: CE, E-Mark, EN50155, FCC
- AI Performance: 70 TOPS
- SOM: NVIDIA Jetson Orin NX 8GB
-
IBOX-600-M12X-ONX8
IBOX-600 with Jetson Orin NX 8GB, M12 X-coded LAN and M12 K-coded power -
IBOX-600-M12X-ON4
IBOX-600 with Jetson Orin Nano 4GB, M12 X-coded LAN and M12 K-coded power -
IBOX-600-M12X-ON8
IBOX-600 with Jetson Orin Nano 8GB, M12 X-coded LAN and M12 K-coded power -
IBOX-600-M12X-ONX16
IBOX-600 with Jetson Orin NX 16GB, M12 X-coded LAN and M12 K-coded power -
IBOX-600-ON4
IBOX-600 with Jetson Orin Nano 4GB, RJ-45 LAN and terminal-block power -
IBOX-600-ON8
IBOX-600 with Jetson Orin Nano 8GB, RJ-45 LAN and terminal-block power -
IBOX-600-ONX16
IBOX-600 with Jetson Orin NX 16GB, RJ-45 LAN and terminal-block power -
IBOX-600-ONX8
IBOX-600 with Jetson Orin NX 8GB, RJ-45 LAN and terminal-block power
- Display Outputs: 1x HDMI
- USB: 2x USB 3.2 Gen 1 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- CANbus: 1x CANbus, DB9
- M.2: 1x M.2 B-Key [USB] [3042/3052], 1x M.2 E-Key [USB] [2230]
- mPCIe: 1x mPCIe [USB]
- Storage: 1x M.2 SSD
- Ignition Sensing: Supports Ignition Control
- Temp: -25°C to 70°C [-13°F to 158°F]
- Certification: CE, E-Mark, EN50155, FCC
- AI Performance: 70 TOPS
- SOM: NVIDIA Jetson Orin NX 8GB
- Ethernet: 1x 2.5 GbE LAN [M12], 1x GbE LAN [M12]
- Power: 9-60V DC Input [M12]
-
DSBOARD-ORNXS-AB16
DSBOARD-ORNXS with Jetson Orin NX 16GB module, 100 TOPS -
DSBOARD-ORNXS-AA
DSBOARD-ORNXS with no module fitted, for Orin NX or Orin Nano -
DSBOARD-ORNXS-AB8
DSBOARD-ORNXS with Jetson Orin NX 8GB module, 70 TOPS -
DSBOARD-ORNXS-AC4
DSBOARD-ORNXS with Jetson Orin Nano 4GB module, 20 TOPS -
DSBOARD-ORNXS-AC8
DSBOARD-ORNXS with Jetson Orin Nano 8GB module, 40 TOPS
- OS: Linux
- Display Outputs: 1x Mini Display Port
- Ethernet: 2x GbE LAN [Board]
- USB: 2x USB 2.0 [Board]
- CANbus: 1x CANbus [Board]
- M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe] [2230]
- Storage: 1x M.2 SSD
- Power: 9-28V DC [2-Pin]
- Temp: -25°C to 85°C [-13°F to 185°F]
- Certification: CE, FCC
- AI Performance: 100 TOPS
- SOM: NVIDIA Jetson Orin NX 16GB
-
eNVP-JOX-IV-F4004
eNVP-JOX-IV with Orin NX 16GB, 6x GbE, 5x PoE out and PoE-PD input -
eNVP-JOX-IV-F3000
eNVP-JOX-IV with Orin NX 8GB, PoE-PD input and 1x PoE out -
eNVP-JOX-IV-F3004
eNVP-JOX-IV with Orin NX 8GB, 6x GbE, 5x PoE out and PoE-PD input -
eNVP-JOX-IV-F4000
eNVP-JOX-IV with Orin NX 16GB, PoE-PD input and 1x PoE out
- AI Performance: 70–100 TOPS
- SOM: NVIDIA Jetson Orin NX 16GB, NVIDIA Jetson Orin NX 8GB
- OS: Linux
- Display Outputs: 1x HDMI
- USB: 4x USB 3.1 Gen 1 [Type A]
- Serial: 2x RS485 [DB9]
- CANbus: 2x CANbus [Terminal Block]
- M.2: 1x M.2 B-Key [USB] [3042/3052], 1x M.2 E-Key [USB/PCIe] [2230], 1x M.2 M-Key [PCIe x4] [2280]
- Storage: 1x M.2 SSD
- Power: 9-48V DC Input [Terminal Block], PoE Powered Device (PD) [RJ45]
- Temp: -20°C to 60°C [-4°F to 140°F]
- Certification: CE, FCC
- Ethernet: 1x GbE LAN [RJ45] [PoE-PD], 1x GbE LAN [RJ45] [PoE], 4x GbE LAN [RJ45] [PoE]
- OS: Linux
- Display Outputs: 1x HDMI
- Ethernet: 1x GbE LAN [RJ45], 1x GbE LAN [RJ45] [PoE]
- USB: 1x USB 2.0 [Type A], 1x USB 3.2 Gen 2 [Type A]
- M.2: 1x M.2 M-Key [PCIe x4] [2280]
- mPCIe: 1x mPCIe [PCIe/USB]
- Storage: 1x M.2 SSD
- Power: 12V DC [Barrel Connector]
- Temp: -10°C to 60°C [14°F to 140°F]
- Certification: CE, FCC
- AI Performance: 100 TOPS
- SOM: NVIDIA Jetson Orin NX 16GB
- AI Performance: 100 TOPS
- SOM: NVIDIA Jetson Orin NX 16GB
- OS: Linux
- Display Outputs: 1x HDMI
- Ethernet: 1x 2.5 GbE LAN [RJ45] [PoE], 1x GbE LAN [RJ45] [PoE]
- USB: 2x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [PCIe x1/USB/SIM] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4] [2280]
- mPCIe: 1x mPCIe [PCIe/USB]
- Storage: 1x M.2 SSD
- Power: 24V DC
- Temp: -25°C to 60°C [-13°F to 140°F]
- Certification: CE, FCC
- Mounting Options: DIN Mount, VESA Mount, Wall Mount
- AI Performance: 70–100 TOPS
- SOM: NVIDIA Jetson Orin NX 16GB, NVIDIA Jetson Orin NX 8GB
- OS: Linux, Linux Ubuntu 22.04
- Display Outputs: 2x HDMI
- Ethernet: 1x GbE LAN [RJ45]
- USB: 1x USB 3.2 Gen 1 [Board], 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232 [Terminal Block], 1x RS485 [Terminal Block]
- M.2: 3x M.2 M-Key [PCIe] [2280]
- Power: 12-36V DC [Barrel Connector]
- Temp: 0°C to 60°C [32°F to 140°F]
- Certification: CE, FCC
- Mounting Options: Desktop
-
DSBOX-ORNX-LAN-AB16
DSBOX-ORNX-LAN with NVIDIA Jetson Orin NX 16GB, 100 TOPS, dual Gigabit Ethernet, CAN bus -
DSBOX-ORNX-LAN-AA
DSBOX-ORNX-LAN with a choice of Jetson Orin Nano or Orin NX, dual Gigabit Ethernet -
DSBOX-ORNX-LAN-AB8
DSBOX-ORNX-LAN with NVIDIA Jetson Orin NX 8GB, dual Gigabit Ethernet, 3x USB-C, CAN bus -
DSBOX-ORNX-LAN-AC4
DSBOX-ORNX-LAN with NVIDIA Jetson Orin Nano 4GB, dual Gigabit Ethernet, 3x USB-C, CAN bus -
DSBOX-ORNX-LAN-AC8
DSBOX-ORNX-LAN with NVIDIA Jetson Orin Nano 8GB, dual Gigabit Ethernet, 3x USB-C, CAN bus
- OS: Linux
- Display Outputs: 1x HDMI
- Ethernet: 2x GbE LAN [RJ45]
- USB: 3x USB 3.1 Gen 1 [Type-C]
- Serial: 1x RS232/422 [Terminal Block]
- CANbus: 1x CANbus [Terminal Block]
- M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4] [2280], 1x M.2 M-Key [PCIe] [2230]
- Storage: 2x M.2 SSD
- Power: 9-28V DC [Terminal Block]
- Temp: -25°C to 85°C [-13°F to 185°F]
- Certification: CE, FCC, RoHS
- Mounting Options: DIN Mount, Wall Mount
- AI Performance: 100 TOPS
- SOM: NVIDIA Jetson Orin NX 16GB
-
DSBOARD-ORNX-LAN-AB16
DSBOARD-ORNX-LAN with Jetson Orin NX 16GB module, 100 TOPS -
DSBOARD-ORNX-LAN-AA
DSBOARD-ORNX-LAN with no module fitted, for Orin NX or Orin Nano -
DSBOARD-ORNX-LAN-AB8
DSBOARD-ORNX-LAN with Jetson Orin NX 8GB module, 70 TOPS -
DSBOARD-ORNX-LAN-AC4
DSBOARD-ORNX-LAN with Jetson Orin Nano 4GB module, 20 TOPS -
DSBOARD-ORNX-LAN-AC8
DSBOARD-ORNX-LAN with Jetson Orin Nano 8GB module, 40 TOPS
- OS: Linux
- Display Outputs: 1x HDMI
- Ethernet: 2x GbE LAN [RJ45]
- USB: 3x USB 3.1 Gen 1 [Type-C]
- Serial: 1x RS232/422/485 [Terminal Block]
- CANbus: 1x CANbus [Terminal Block]
- M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4] [2280], 1x M.2 M-Key [PCIe] [2230]
- Storage: 2x M.2 SSD
- Power: 9-28V DC [Terminal Block]
- Temp: -25°C to 85°C [-13°F to 185°F]
- Certification: CE, FCC, RoHS
- AI Performance: 100 TOPS
- SOM: NVIDIA Jetson Orin NX 16GB
- AI Performance: 100 TOPS
- SOM: NVIDIA Jetson Orin NX 16GB
// Edge AI Specialists
Speak to a Jetson Orin NX Specialist.
Tell us where the system will be installed, the approvals it must meet and the cameras and interfaces you need to connect. We will recommend the right Orin NX module and system, then configure, image and test it before it ships.
