Displaying of 139 items

View All

ASRock Industrial

Industrial Edge Gateway with 5 GbE LAN and Atom CPU

iEP-5000G

Industrial Edge Gateway with 5 GbE LAN and Atom CPU

Available in 4 variations

View iEP-5000G-002 iEP-5000G Datasheet

View iEP-5000G-001 iEP-5000G Datasheet

View iEP-5000G-010 iEP-5000G Datasheet

View iEP-5000G-000 iEP-5000G Datasheet

iEP-5000G

Available in 4 variations

CPU: Atom X Series Elkhart Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
OS: Linux, Windows 10
Display Outputs: 1x HDMI, 1x VGA
Ethernet: 5 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
Serial: 3 x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD, 1x Micro SD
Power: 6-36V DC Input [Barrel Connector]
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: Atom X Series Elkhart Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
OS: Linux, Windows 10
Display Outputs: 1x HDMI, 1x VGA
Ethernet: 2 x GbE LAN [RJ45] [PoE], 3 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
Serial: 3 x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD, 1x Micro SD
Power: 19-36V DC [Terminal Block]
Temp: -40°C to 50°C [-40°F to 122°F]
Certification: CE, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: Atom X Series Elkhart Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
OS: Linux, Windows 10
Display Outputs: 1x HDMI, 1x VGA
Ethernet: 3 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
Serial: 3 x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD, 1x Micro SD
Power: 19-36V DC [Barrel Connector]
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: Atom X Series Elkhart Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
OS: Linux, Windows 10
Display Outputs: 1x HDMI, 1x VGA
Ethernet: 3 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
Serial: 3 x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD, 1x Micro SD
Power: 6-36V DC Input [Barrel Connector]
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, FCC
Mounting Options: DIN Mount, Wall Mount

Axiomtek

Intel Atom x5-E3940 Compact LTE Vehicle Gateway

UST210-83K-FL

Intel Atom x5-E3940 Compact LTE Vehicle Gateway

Available in 4 variations

View UST210-83K-FL-E3940-CANCOM-TVDC UST210-83K-FL Datasheet

View UST210-83K-FL-E3940-4POE-2COM-TVDC UST210-83K-FL Datasheet

View UST210-83K-FL-E3940-4POE-CANCOM-TVDC UST210-83K-FL Datasheet

View UST210-83K-FL-E3940-2COM-TVDC UST210-83K-FL Datasheet

UST210-83K-FL

Available in 4 variations

CPU: Atom X Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux, Windows 10
Display Outputs: 1x HDMI
Ethernet: 4 x GbE LAN [RJ45]
USB: 2 x USB 3.0 [Type A]
Serial: 1 x RS232/422/485 [Terminal Block]
CANbus: 1 x CANbus [Terminal Block]
mPCIe: 1 x Half-Size mPCIe [PCIe, USB], 1 x mPCIe [USB/SIM]
Storage: 1x 2.5" HDD/SSD, 1x mSATA
Power: 9-36V DC Input [Terminal Block]
Ignition Sensing: Supports Ignition Control
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, E-Mark, ECE-R10, EN55024, EN55032, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: Atom X Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux, Windows 10
Display Outputs: 1x HDMI
Ethernet: 4 x GbE LAN [RJ45]
USB: 2 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Terminal Block]
mPCIe: 1 x Half-Size mPCIe [PCIe, USB], 1 x mPCIe [USB/SIM]
Storage: 1x 2.5" HDD/SSD, 1x mSATA
Power: 9-36V DC Input [Terminal Block]
Ignition Sensing: Supports Ignition Control
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, E-Mark, ECE-R10, EN55024, EN55032, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: Atom X Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux, Windows 10
Display Outputs: 1x HDMI
Ethernet: 4 x GbE LAN [RJ45]
USB: 2 x USB 3.0 [Type A]
Serial: 1 x RS232/422/485 [Terminal Block]
CANbus: 1 x CANbus [Terminal Block]
mPCIe: 1 x Half-Size mPCIe [PCIe, USB], 1 x mPCIe [USB/SIM]
Storage: 1x 2.5" HDD/SSD, 1x mSATA
Power: 9-36V DC Input [Terminal Block]
Ignition Sensing: Supports Ignition Control
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, E-Mark, ECE-R10, EN55024, EN55032, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: Atom X Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux, Windows 10
Display Outputs: 1x HDMI
Ethernet: 4 x GbE LAN [RJ45]
USB: 2 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Terminal Block]
mPCIe: 1 x Half-Size mPCIe [PCIe, USB], 1 x mPCIe [USB/SIM]
Storage: 1x 2.5" HDD/SSD, 1x mSATA
Power: 9-36V DC Input [Terminal Block]
Ignition Sensing: Supports Ignition Control
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, E-Mark, ECE-R10, EN55024, EN55032, FCC
Mounting Options: DIN Mount, Wall Mount

Nexcom

Low Profile Quad Core IIoT Gateway

NISE 51

Low Profile Quad Core IIoT Gateway

View NISE 51 NISE 51 Datasheet

NISE 51

Low Profile Quad Core IIoT Gateway

CPU: Celeron N Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux, Windows 10
Display Outputs: 1x Display Port
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.0 [Type A]
Serial: 1 x RS232/485 [DB9], 2 x RS232 [DB9]
M.2: 1x M.2 A-Key [USB/PCIe] [2230], 1x M.2 B-Key [USB/SATA] [2242/3042]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 16GB eMMC, 1x M.2 SSD
Power: 12-24V DC [Barrel Connector], Optional AC Power Supply
Temp: -5°C to 55°C [23°F to 131°F]
Certification: CE, FCC
Mounting Options: Desktop, Wall Mount

ASRock Industrial

NVIDIA Jetson Orin Nano Wireless IoT Gateway

iEP-6012E

NVIDIA Jetson Orin Nano Wireless IoT Gateway

Available in 3 variations

View iEP-6012E-003 iEP-6012E Datasheet

View iEP-6012E-001 iEP-6012E Datasheet

View iEP-6012E-000 iEP-6012E Datasheet

iEP-6012E

Available in 3 variations

SOM: Orin Nano
OS: Linux
AI Accelerator: NVIDIA Jetson SOM
Display Outputs: 1x HDMI
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
Serial: 1 x RS232 [DB9], 1 x RS232/422/485 [DB9]
CANbus: 1 x CANbus [Board]
M.2: 1x M.2 B-Key [PCIe x2/USB 3.0/SATA] [2280/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x Micro SD, 2x M.2 SSD
Power: 12-36V DC Input [Terminal Block], 20V [USB-C]
Temp: -25°C to 60°C [-13°F to 147°F]
Certification: CE, FCC
Mounting Options: DIN Mount, VESA Mount, Wall Mount

SOM: Orin Nano
OS: Linux
AI Accelerator: NVIDIA Jetson SOM
Display Outputs: 1x HDMI
Ethernet: 2 x GbE LAN [RJ45], 2 x GbE LAN [RJ45] [PoE]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
Serial: 1 x RS232 [DB9], 1 x RS232/422/485 [DB9]
CANbus: 1 x CANbus [Board]
M.2: 1x M.2 B-Key [PCIe x2/USB 3.0/SATA] [2280/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x Micro SD, 2x M.2 SSD
Power: 12-36V DC Input [Terminal Block], 20V [USB-C]
Temp: -25°C to 60°C [-13°F to 147°F]
Certification: CE, FCC
Mounting Options: DIN Mount, VESA Mount, Wall Mount

SOM: Orin Nano
OS: Linux
AI Accelerator: NVIDIA Jetson SOM
Display Outputs: 1x HDMI
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
Serial: 1 x RS232 [DB9], 1 x RS232/422/485 [DB9]
CANbus: 1 x CANbus [Board]
M.2: 1x M.2 B-Key [PCIe x2/USB 3.0/SATA] [2280/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x Micro SD, 2x M.2 SSD
Power: 12-36V DC Input [Terminal Block], 20V [USB-C]
Temp: -25°C to 60°C [-13°F to 147°F]
Certification: CE, FCC
Mounting Options: DIN Mount, VESA Mount, Wall Mount

Axiomtek

Rail Certified Transportation Gateway with Atom x5-E3940 CPU

tBOX110

Rail Certified Transportation Gateway with Atom x5-E3940 CPU

Available in 3 variations

View tBOX110-APL-MR1 tBOX110 Datasheet

View tBOX110-APL-MR2 tBOX110 Datasheet

View tBOX110-APL-TV tBOX110 Datasheet

tBOX110

Available in 3 variations

CPU: Atom X Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux Ubuntu 20.04, Windows 10
Display Outputs: 2x HDMI
Ethernet: 2 x GbE LAN [M12]
USB: 2 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Terminal Block]
CANbus: 2x CANbus [Terminal Block]
mPCIe: 1x mPCIe [PCIe/USB/SIM/SATA], 1x mPCIe [PCIe/USB/SIM]
Storage: 1x mSATA, 1x SATA Port
Power: 24V DC [M12]
Ignition Sensing: Supports Ignition Control
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, EN45545-2, EN50155, FCC, ISO 7637-2
Mounting Options: DIN Mount, Wall Mount

CPU: Atom X Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux Ubuntu 20.04, Windows 10
Display Outputs: 2x HDMI
Ethernet: 2 x GbE LAN [M12]
USB: 2 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Terminal Block]
CANbus: 2x CANbus [Terminal Block]
mPCIe: 1x mPCIe [PCIe/USB/SIM/SATA], 1x mPCIe [PCIe/USB/SIM]
Storage: 1x mSATA, 1x SATA Port
Power: 36-110V DC [M12]
Ignition Sensing: Supports Ignition Control
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, EN45545-2, EN50155, FCC, ISO 7637-2
Mounting Options: DIN Mount, Wall Mount

CPU: Atom X Series Apollo Lake
Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux Ubuntu 20.04, Windows 10
Display Outputs: 2x HDMI
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 3.0 [Type A]
Serial: 2 x RS232/422/485 [Terminal Block]
CANbus: 2x CANbus [Terminal Block]
mPCIe: 1x mPCIe [PCIe/USB/SIM/SATA], 1x mPCIe [PCIe/USB/SIM]
Storage: 1x mSATA, 1x SATA Port
Power: 12-24V DC [Terminal Block]
Ignition Sensing: Supports Ignition Control
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, EN45545-2, EN50155, FCC, ISO 7637-2
Mounting Options: DIN Mount, Wall Mount

C&T Solution

Comet Lake Intel Core i3/i5/i7 Vehicle IoT Gateway

ACO-6000-CML

Comet Lake Intel Core i3/i5/i7 Vehicle IoT Gateway

Available in 13 variations

View ACO-6000-CML-5G ACO-6000-CML Datasheet

View ACO-6000-CML-8U3 ACO-6000-CML Datasheet

View ACO-6000-CML-4U3 ACO-6000-CML Datasheet

View ACO-6000-CML-D10G ACO-6000-CML Datasheet

View ACO-6000-CML-8PM12 ACO-6000-CML Datasheet

View ACO-6000-CML-8P ACO-6000-CML Datasheet

View ACO-6000-CML-4PM12 ACO-6000-CML Datasheet

View ACO-6000-CML-4P ACO-6000-CML Datasheet

View ACO-6000-CML-8LM12 ACO-6000-CML Datasheet

View ACO-6000-CML-8L ACO-6000-CML Datasheet

View ACO-6000-CML-4LM12 ACO-6000-CML Datasheet

View ACO-6000-CML-4L ACO-6000-CML Datasheet

View ACO-6000-CML ACO-6000-CML Datasheet

ACO-6000-CML

Available in 13 variations

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 6 x USB 3.2 Gen 2 [Type A]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 6 x USB 3.2 Gen 2 [Type A], 8 x USB 3.0 [Type A] [EDGEBoost I/O]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 4 x USB 3.0 [Type A] [EDGEBoost I/O], 6 x USB 3.2 Gen 2 [Type A]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x 10 GbE LAN [RJ45] [EDGEBoost I/O], 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 6 x USB 3.2 Gen 2 [Type A]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 8 x GbE LAN [M12] [PoE] [EDGEBoost I/O]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 6 x USB 3.2 Gen 2 [Type A]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 8 x GbE LAN [RJ45] [PoE] [EDGEBoost I/O]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 6 x USB 3.2 Gen 2 [Type A]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [M12] [PoE] [EDGEBoost I/O]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 6 x USB 3.2 Gen 2 [Type A]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [RJ45] [PoE] [EDGEBoost I/O]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 6 x USB 3.2 Gen 2 [Type A]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 8 x GbE LAN [M12] [EDGEBoost I/O]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 6 x USB 3.2 Gen 2 [Type A]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 8 x GbE LAN [RJ45] [EDGEBoost I/O]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 6 x USB 3.2 Gen 2 [Type A]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [M12] [EDGEBoost I/O]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 6 x USB 3.2 Gen 2 [Type A]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [RJ45] [EDGEBoost I/O]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 6 x USB 3.2 Gen 2 [Type A]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

CPU: 10th Gen Comet Lake
Memory: 2x DDR4 2666MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 1x DVI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Board], 3 x USB 3.2 Gen 1 [Type A], 6 x USB 3.2 Gen 2 [Type A]
Serial: 2x RS232/422/485 [DB9], 6 x RS232/422/485 [Board]
CANbus: 2 x CANbus [Board]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [SATA/USB/PCIe]
Storage: 1x M.2 SSD, 3x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Hot Swappable Storage: Hot Swappable SSD Support
RAID: RAID 0, RAID 1, RAID 5
Power: 48-110V DC [Terminal Block], 9-48V DC Input [Terminal Block], Optional AC Power Supply
Ignition Sensing: Supports Ignition Control
Temp: -25°C to 70°C [-13°F to 158°F]
Certification: CE, E-Mark, EN50121-3-2, EN50155, FCC, RoHS
Mounting Options: Wall Mount

ASRock Industrial

NVIDIA Jetson Orin NX Rugged Cellular Gateway

iEP-6010E

NVIDIA Jetson Orin NX Rugged Cellular Gateway

Available in 3 variations

View iEP-6010E-003 iEP-6010E Datasheet

View iEP-6010E-001 iEP-6010E Datasheet

View iEP-6010E-000 iEP-6010E Datasheet

iEP-6010E

Available in 3 variations

SOM: Orin NX
OS: Linux
AI Accelerator: NVIDIA Jetson SOM
Display Outputs: 1x HDMI
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
Serial: 1 x RS232 [DB9], 1 x RS232/422/485 [DB9]
CANbus: 1 x CANbus [Board]
M.2: 1x M.2 B-Key [PCIe x2/USB 3.0/SATA] [2280/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x Micro SD, 2x M.2 SSD
Power: 12-36V DC Input [Terminal Block], 20V [USB-C]
Temp: -25°C to 60°C [-13°F to 147°F]
Certification: CE, FCC
Mounting Options: DIN Mount, VESA Mount, Wall Mount

SOM: Orin NX
OS: Linux
AI Accelerator: NVIDIA Jetson SOM
Display Outputs: 1x HDMI
Ethernet: 2 x GbE LAN [RJ45], 2 x GbE LAN [RJ45] [PoE]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
Serial: 1 x RS232 [DB9], 1 x RS232/422/485 [DB9]
CANbus: 1 x CANbus [Board]
M.2: 1x M.2 B-Key [PCIe x2/USB 3.0/SATA] [2280/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x Micro SD, 2x M.2 SSD
Power: 12-36V DC Input [Terminal Block], 20V [USB-C]
Temp: -25°C to 60°C [-13°F to 147°F]
Certification: CE, FCC
Mounting Options: DIN Mount, VESA Mount, Wall Mount

SOM: Orin NX
OS: Linux
AI Accelerator: NVIDIA Jetson SOM
Display Outputs: 1x HDMI
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
Serial: 1 x RS232 [DB9], 1 x RS232/422/485 [DB9]
CANbus: 1 x CANbus [Board]
M.2: 1x M.2 B-Key [PCIe x2/USB 3.0/SATA] [2280/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x Micro SD, 2x M.2 SSD
Power: 12-36V DC Input [Terminal Block], 20V [USB-C]
Temp: -25°C to 60°C [-13°F to 147°F]
Certification: CE, FCC
Mounting Options: DIN Mount, VESA Mount, Wall Mount

ASRock Industrial

Expandable Rugged Edge AIoT GPU Computer with 12th Gen Core CPU

iEPF-9010S-EY4

Expandable Rugged Edge AIoT GPU Computer with 12th Gen Core CPU

View iEPF-9010S-EY4 iEPF-9010S-EY4 Datasheet

iEPF-9010S-EY4

Expandable Rugged Edge AIoT GPU Computer with 12th Gen Core CPU

CPU: 12th Gen Alder Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
AI Accelerator: Optional Graphics Cards
Display Outputs: 1x Display Port, 1x HDMI, 1x VGA
Ethernet: 2 x 2.5 GbE LAN [RJ45] [PoE], 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Board], 6 x USB 3.1 Gen 1 [Type A]
Serial: 2 x RS232 [DB9], 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
mPCIe: 2 x mPCIe [PCIe/USB]
PCIe: 2x PCIe [x16 Slot] [1x16 Signal or 2x8 Signal] [Gen4], 2x PCIe [x4 Slot] [Gen4]
Storage: 1x CFAST, 1x M.2 SSD, 4x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Power: 9-36V DC Input [Terminal Block]
Ignition Sensing: Supports Ignition Control
Temp: -40°C to 50°C [-40°F to 122°F], -40°C to 70°C [-40°F to 158°F]
Certification: CE, FCC
Mounting Options: Desktop

ASRock Industrial

Expandable Edge AIoT Computer with Alder Lake Core CPU

iEPF-9012S-EY4

Expandable Edge AIoT Computer with Alder Lake Core CPU

View iEPF-9012S-EY4 iEPF-9012S-EY4 Datasheet

iEPF-9012S-EY4

Expandable Edge AIoT Computer with Alder Lake Core CPU

CPU: 12th Gen Alder Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
AI Accelerator: Optional Graphics Cards
Display Outputs: 1x Display Port, 1x HDMI, 1x VGA
Ethernet: 2 x 2.5 GbE LAN [RJ45], 2 x 2.5 GbE LAN [RJ45] [PoE]
USB: 1 x USB 2.0 [Board], 2 x USB 2.0 [Type A], 2 x USB 3.1 Gen 1 [Type A], 2 x USB 3.2 Gen 2 [Type A]
Serial: 2 x RS232 [DB9], 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
mPCIe: 2 x mPCIe [PCIe/USB]
PCIe: 2x PCIe [x16 Slot]
Storage: 1x CFAST, 4x 2.5" HDD/SSD
Front Accessible Storage: Front Accesible SSD Storage Bays
Power: 9-36V DC Input [Terminal Block]
Ignition Sensing: Supports Ignition Control
Temp: -40°C to 50°C [-40°F to 122°F], -40°C to 70°C [-40°F to 158°F]
Certification: CE, FCC
Mounting Options: Desktop

ASRock Industrial

Raptor Lake Intel Core Rugged IIoT Gateway

iEP-7020E

Raptor Lake Intel Core Rugged IIoT Gateway

Available in 3 variations

View iEP-7020E-001 iEP-7020E Datasheet

View iEP-7020E-002 iEP-7020E Datasheet

View iEP-7020E-000 iEP-7020E Datasheet

iEP-7020E

Available in 3 variations

CPU: 13th Gen Raptor Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 2x Display Port
Ethernet: 2 x GbE LAN [RJ45] [PoE], 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Type A], 3 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x M.2 SSD, 1x Micro SD
Power: 19-36V DC [Terminal Block]
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: 13th Gen Raptor Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Type A], 3 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x M.2 SSD, 1x Micro SD
Power: 9-36V DC Input [Terminal Block]
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: 13th Gen Raptor Lake
Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
OS: Linux, Windows 10
Display Outputs: 2x Display Port
Ethernet: 3 x GbE LAN [RJ45]
USB: 1 x USB 2.0 [Type A], 3 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD, 1x Micro SD
Power: 9-36V DC Input [Terminal Block]
Temp: -40°C to 70°C [-40°F to 158°F]
Certification: CE, FCC
Mounting Options: DIN Mount, Wall Mount

Arestech

Ultra Compact IIoT Gateway PC with Pentium N4200

BPC-3025

Ultra Compact IIoT Gateway PC with Pentium N4200

Available in 2 variations

View BPC-3025-1A1 BPC-3025 Datasheet

BPC-3025

Available in 2 variations

CPU: Pentium N Series Apollo Lake
Memory: 2x DDR3L 1866MHz SO-DIMM Slot, 8GB
OS: Linux, Windows 10
Display Outputs: 1x HDMI, 1x VGA
Ethernet: 2 x GbE LAN [RJ45]
USB: 2 x USB 2.0 [Type A], 2 x USB 3.0 [Type A]
Serial: 1 x RS232 [DB9], 2x RS232/422/485 [DB9]
M.2: 1x M.2 M-Key [PCIe x4/SATA] [2242]
mPCIe: 1 x mPCIe [PCIe/USB]
Storage: 1x M.2 SSD
Power: 9-36V DC Input, Terminal Block
Temp: -20°C to 60°C [-4°F to 147°F]
Certification: CE, FCC
Mounting Options: DIN Mount, Wall Mount

Forecr

Jetson AGX Xavier Rugged Edge Computer

DSBOX-XV2

Jetson AGX Xavier Rugged Edge Computer

Available in 2 variations

View DSBOX-XV2-AA DSBOX-XV2 Datasheet

DSBOX-XV2

Available in 2 variations

SOM: AGX Xavier
OS: Linux
AI Accelerator: NVIDIA Jetson SOM
Display Outputs: 1x HDMI
Ethernet: 1 x GbE LAN [RJ45]
USB: 2 x USB 3.1 Gen 1 [Type A]
Serial: 1 x RS232/422/485 [Terminal Block]
CANbus: 1 x CANbus [Terminal Block]
M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
Storage: 1x M.2 SSD, 1x Micro SD, 32GB eMMC
Power: 18-30V DC [Terminal Block]
Temp: -25°C to 85°C [-13°F to 185°F]
Certification: CE, FCC, RoHS
Mounting Options: DIN Mount, Wall Mount

DFI

RC300-CS

EN50155 MXM GPU Computer

Available in 3 variations

View RC300L-CS111 RC300-CS Datasheet

View RC300H-CS122 RC300-CS Datasheet

View RC300H-CS111 RC300-CS Datasheet

RC300-CS

Available in 3 variations

CPU: 8th Gen Coffee Lake, 9th Gen Coffee Lake
Memory: 2x DDR4 2400MHz SO-DIMM, 16GB
OS: Linux
AI Accelerator: Optional Graphics Cards
Display Outputs: 1x Display Port, 1x HDMI, 1x VGA
Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [M12] [PoE]
USB: 2 x USB 2.0 [Type A], 4 x USB 3.0 [Type A]
Serial: 2x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe x1/USB/SIM] [3042/3052], 1x M.2 M-Key [PCIe x4/SATA] [2242/2260/2280], 1x M.2 M-Key [PCIe x4] [2280]
mPCIe: 1 x Half-Size mPCIe [PCIe, USB], 2x mPCIe [PCIe/SIM/USB]
Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
Power: 9-36V DC Input [Terminal Block]
Temp: -25°C to 55°C [-13°F to 131°F], -25°C to 70°C [-13°F to 158°F]
Certification: CE, EN50155, FCC
Mounting Options: Wall Mount

CPU: 8th Gen Coffee Lake, 9th Gen Coffee Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 32GB
OS: Linux
AI Accelerator: Optional Graphics Cards
Display Outputs: 1x Display Port, 1x HDMI, 1x VGA
Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [M12] [PoE]
USB: 2 x USB 2.0 [Type A], 4 x USB 3.0 [Type A]
Serial: 2x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe x1/USB/SIM] [3042/3052], 1x M.2 M-Key [PCIe x4/SATA] [2242/2260/2280], 1x M.2 M-Key [PCIe x4] [2280]
mPCIe: 1 x Half-Size mPCIe [PCIe, USB], 2x mPCIe [PCIe/SIM/USB]
Storage: 1x M.2 SSD, 4x 2.5" HDD/SSD
Power: 110V DC Input [Terminal Block]
Temp: -25°C to 55°C [-13°F to 131°F], -25°C to 70°C [-13°F to 158°F]
Certification: CE, EN50155, FCC
Mounting Options: Wall Mount

CPU: 8th Gen Coffee Lake, 9th Gen Coffee Lake
Memory: 2x DDR4 2400MHz SO-DIMM, 16GB
OS: Linux
AI Accelerator: Optional Graphics Cards
Display Outputs: 1x Display Port, 1x HDMI, 1x VGA
Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [M12] [PoE]
USB: 2 x USB 2.0 [Type A], 4 x USB 3.0 [Type A]
Serial: 2x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe x1/USB/SIM] [3042/3052], 1x M.2 M-Key [PCIe x4/SATA] [2242/2260/2280], 1x M.2 M-Key [PCIe x4] [2280]
mPCIe: 1 x Half-Size mPCIe [PCIe, USB], 2x mPCIe [PCIe/SIM/USB]
Storage: 1x M.2 SSD, 4x 2.5" HDD/SSD
Power: 110V DC Input [Terminal Block]
Temp: -25°C to 55°C [-13°F to 131°F], -25°C to 70°C [-13°F to 158°F]
Certification: CE, EN50155, FCC
Mounting Options: Wall Mount

Vecow

Intel Core Embedded PC with GPU

ECX-3000 PEG

Intel Core Embedded PC with GPU

Available in 6 variations

View ECX-3800 PEG ECX-3000 PEG Datasheet

View ECX-3600 PEG ECX-3000 PEG Datasheet

View ECX-3400 PEG ECX-3000 PEG Datasheet

View ECX-3200MX PEG ECX-3000 PEG Datasheet

View ECX-3200 PEG ECX-3000 PEG Datasheet

View ECX-3100 PEG ECX-3000 PEG Datasheet

ECX-3000 PEG

Available in 6 variations

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 4 x 2.5 GbE LAN [RJ45] [PoE]
USB: 1x USB 3.2 Gen 2 [Type C], 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB 3.0/USB] [2280/3042], 1x M.2 B-Key [PCIe/USB 3.0/USB] [2280/3052], 1x M.2 E-Key [USB/PCIe] [2230], 1x M.2 M-Key [PCIe x4] [2280]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
PCIe: 2x PCIe [x4 Slot] [Gen4], 2x PCIe [x8 Slot][1x8 Signal or 2x4 Signal] [Gen4]
Storage: 1x M.2 SSD, 4x 2.5" HDD/SSD, 4x SATA Ports
RAID: RAID 0, RAID 1, RAID 5, RAID 10
Power: 12V-50V DC Input [Terminal Block]
Temp: -20°C to 45°C [-4°F to 113°F]
Certification: CE, EN50155, FCC, UKCA
Mounting Options: Rack Mount, VESA Mount, Wall Mount

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 4 x 2.5 GbE LAN [RJ45] [PoE]
USB: 1x USB 3.2 Gen 2 [Type C], 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB 3.0/USB] [2280/3042], 1x M.2 B-Key [PCIe/USB 3.0/USB] [2280/3052], 1x M.2 E-Key [USB/PCIe] [2230], 1x M.2 M-Key [PCIe x4] [2280]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
PCIe: 1x PCIe [x4 Slot], 2x PCIe [x8 Slot][1x8 Signal or 2x4 Signal] [Gen4]
Storage: 1x M.2 SSD, 4x 2.5" HDD/SSD, 4x SATA Ports
RAID: RAID 0, RAID 1, RAID 5, RAID 10
Power: 12V-50V DC Input [Terminal Block]
Temp: -20°C to 45°C [-4°F to 113°F]
Certification: CE, EN50155, FCC, UKCA
Mounting Options: Rack Mount, VESA Mount, Wall Mount

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 4 x 2.5 GbE LAN [RJ45] [PoE]
USB: 1x USB 3.2 Gen 2 [Type C], 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB 3.0/USB] [2280/3042], 1x M.2 B-Key [PCIe/USB 3.0/USB] [2280/3052], 1x M.2 E-Key [USB/PCIe] [2230], 1x M.2 M-Key [PCIe x4] [2280]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
PCIe: 1x PCIe [x16 Slot] [1x16 Signal or 2x8 Signal] [Gen4], 1x PCIe [x4 Slot]
Storage: 1x M.2 SSD, 4x 2.5" HDD/SSD, 4x SATA Ports
RAID: RAID 0, RAID 1, RAID 5, RAID 10
Power: 12V-50V DC Input [Terminal Block]
Temp: -20°C to 45°C [-4°F to 113°F]
Certification: CE, EN50155, FCC, UKCA
Mounting Options: Rack Mount, VESA Mount, Wall Mount

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 4 x 2.5 GbE LAN [M12] [PoE]
USB: 1x USB 3.2 Gen 2 [Type C], 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB 3.0/USB] [2280/3042], 1x M.2 B-Key [PCIe/USB 3.0/USB] [2280/3052], 1x M.2 E-Key [USB/PCIe] [2230], 1x M.2 M-Key [PCIe x4] [2280]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
PCIe: 1x PCIe [x16 Slot] [1x16 Signal or 2x8 Signal] [Gen4]
Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD, 2x SATA Ports
RAID: RAID 0, RAID 1
Power: 12V-50V DC Input [Terminal Block]
Temp: -20°C to 45°C [-4°F to 113°F]
Certification: CE, EN50155, FCC, UKCA
Mounting Options: Rack Mount, VESA Mount, Wall Mount

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45], 4 x 2.5 GbE LAN [RJ45] [PoE]
USB: 1x USB 3.2 Gen 2 [Type C], 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB 3.0/USB] [2280/3042], 1x M.2 B-Key [PCIe/USB 3.0/USB] [2280/3052], 1x M.2 E-Key [USB/PCIe] [2230], 1x M.2 M-Key [PCIe x4] [2280]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
PCIe: 1x PCIe [x16 Slot] [1x16 Signal or 2x8 Signal] [Gen4]
Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD, 2x SATA Ports
RAID: RAID 0, RAID 1
Power: 12V-50V DC Input [Terminal Block]
Temp: -20°C to 45°C [-4°F to 113°F]
Certification: CE, EN50155, FCC, UKCA
Mounting Options: Rack Mount, VESA Mount, Wall Mount

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 2 x GbE LAN [RJ45]
USB: 1x USB 3.2 Gen 2 [Type C], 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [PCIe/USB 3.0/USB] [2280/3042], 1x M.2 B-Key [PCIe/USB 3.0/USB] [2280/3052], 1x M.2 E-Key [USB/PCIe] [2230], 1x M.2 M-Key [PCIe x4] [2280]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
PCIe: 1x PCIe [x16 Slot] [1x16 Signal or 2x8 Signal] [Gen4]
Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD, 2x SATA Ports
RAID: RAID 0, RAID 1
Power: 12V-50V DC Input [Terminal Block]
Temp: -20°C to 45°C [-4°F to 113°F]
Certification: CE, EN50155, FCC, UKCA
Mounting Options: Rack Mount, VESA Mount, Wall Mount

Vecow

Rugged PC with Hailo 8 AI Accelerator

ECX-3000 AI

Rugged PC with Hailo 8 AI Accelerator

Available in 7 variations

View ECX-3000-2G AI ECX-3000 AI Datasheet

View ECX-3000-2R AI ECX-3000 AI Datasheet

View ECX-3000-4G AI ECX-3000 AI Datasheet

View ECX-3000-4R AI ECX-3000 AI Datasheet

View ECX-3000-PoE AI ECX-3000 AI Datasheet

View ECX-3000-PoES AI ECX-3000 AI Datasheet

View ECX-3000-PoER AI ECX-3000 AI Datasheet

ECX-3000 AI

Available in 7 variations

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
AI Accelerator: Hailo-8 AI Accelerator
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 1 x 2.5 GbE LAN [RJ45], 1 x GbE LAN [RJ45]
USB: 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [USB 3.2/USB/SATA] [3042/3050], 1x M.2 E-Key [PCIe x2/USB] [2230]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
Storage: 1x mSATA, 2x 2.5" HDD/SSD, 2x SATA Ports, 4x M.2 SSD
RAID: RAID 0, RAID 1
Power: 9-50V DC Input [Terminal Block]
Temp: -40°C to 45°C [-40°F to 113°F], -40°C to 65°C [-40°F to 149°F]
Certification: CE, EN50155, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
AI Accelerator: Hailo-8 AI Accelerator
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 1 x 2.5 GbE LAN [RJ45], 1 x GbE LAN [RJ45]
USB: 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [USB 3.2/USB/SATA] [3042/3050], 1x M.2 E-Key [PCIe x2/USB] [2230]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
Storage: 1x mSATA, 2x 2.5" HDD/SSD, 2x SATA Ports
RAID: RAID 0, RAID 1
Power: 9-50V DC Input [Terminal Block]
Temp: -40°C to 45°C [-40°F to 113°F], -40°C to 65°C [-40°F to 149°F]
Certification: CE, EN50155, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
AI Accelerator: Hailo-8 AI Accelerator
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 1 x GbE LAN [RJ45], 3 x 2.5 GbE LAN [RJ45]
USB: 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [USB 3.2/USB/SATA] [3042/3050], 1x M.2 E-Key [PCIe x2/USB] [2230]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
Storage: 1x mSATA, 2x SATA Ports
RAID: RAID 0, RAID 1
Power: 9-50V DC Input [Terminal Block]
Temp: -40°C to 45°C [-40°F to 113°F], -40°C to 65°C [-40°F to 149°F]
Certification: CE, EN50155, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
AI Accelerator: Hailo-8 AI Accelerator
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 1 x GbE LAN [RJ45], 3 x 2.5 GbE LAN [RJ45]
USB: 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [USB 3.2/USB/SATA] [3042/3050], 1x M.2 E-Key [PCIe x2/USB] [2230]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
Storage: 1x mSATA, 2x 2.5" HDD/SSD, 2x SATA Ports
RAID: RAID 0, RAID 1
Power: 9-50V DC Input [Terminal Block]
Temp: -40°C to 45°C [-40°F to 113°F], -40°C to 65°C [-40°F to 149°F]
Certification: CE, EN50155, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
AI Accelerator: Hailo-8 AI Accelerator
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 1 x GbE LAN [RJ45], 4 x 2.5 GbE LAN [RJ45] [PoE], 5 x 2.5 GbE LAN [RJ45]
USB: 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [USB 3.2/USB/SATA] [3042/3050], 1x M.2 E-Key [PCIe x2/USB] [2230]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
Storage: 1x mSATA, 2x SATA Ports
RAID: RAID 0, RAID 1
Power: 9-50V DC Input [Terminal Block]
Temp: -40°C to 45°C [-40°F to 113°F], -40°C to 65°C [-40°F to 149°F]
Certification: CE, EN50155, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
AI Accelerator: Hailo-8 AI Accelerator
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 1 x GbE LAN [RJ45], 4 x 2.5 GbE LAN [RJ45] [PoE], 5 x 2.5 GbE LAN [RJ45]
USB: 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [USB 3.2/USB/SATA] [3042/3050], 1x M.2 E-Key [PCIe x2/USB] [2230]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
Storage: 1x mSATA, 2x SATA Ports, 4x M.2 SSD
RAID: RAID 0, RAID 1
Power: 9-50V DC Input [Terminal Block]
Temp: -40°C to 45°C [-40°F to 113°F], -40°C to 65°C [-40°F to 149°F]
Certification: CE, EN50155, FCC
Mounting Options: DIN Mount, Wall Mount

CPU: 12th Gen Alder Lake, 13th Gen Raptor Lake
Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
OS: Linux
AI Accelerator: Hailo-8 AI Accelerator
Display Outputs: 1x DVI, 1x HDMI, 2x Display Port
Ethernet: 1 x GbE LAN [RJ45], 4 x 2.5 GbE LAN [RJ45] [PoE], 5 x 2.5 GbE LAN [RJ45]
USB: 6 x USB 3.2 Gen 2 [Type A]
Serial: 4x RS232/422/485 [DB9]
M.2: 1x M.2 B-Key [USB 3.2/USB/SATA] [3042/3050], 1x M.2 E-Key [PCIe x2/USB] [2230]
mPCIe: 1x mPCIe [PCIe/USB/SATA]
Storage: 1x mSATA, 2x 2.5" HDD/SSD, 2x SATA Ports
RAID: RAID 0, RAID 1
Power: 9-50V DC Input [Terminal Block]
Temp: -40°C to 45°C [-40°F to 113°F], -40°C to 65°C [-40°F to 149°F]
Certification: CE, EN50155, FCC
Mounting Options: DIN Mount, Wall Mount

Displaying of 139 items

Industrial Internet of Things Solutions

As a leading system integrator for industrial edge computing, we support global manufacturing companies, energy management OEMs, and transportation operators implement edge gateways for their diverse monitoring, networking, and data gathering needs in demanding harsh environments. Whether it’s the high-temperature surroundings of a manufacturing floor, the unpredictable conditions of a transportation hub, or the critical operations of an energy management system, our edge gateways are engineered to perform consistently and reliably.
