UK Industrial IoT Gateways
Industry-Focussed IIoT Edge Gateways
Our Industrial IoT Gateways are intelligent industry focussed devices for the Internet of Things. Built rugged and designed to operate in harsh environments, our edge gateways are equipped with a variety of input output connections for data aggregation and AI inference.
Expandable I/O
Edge gateways are highly configurable for data collection from various sensors, devices, and machinery, and then channeling it to centralised systems or cloud platforms.
Redundant Connectivity
IIoT gateways can be configured with Wi-Fi and built-in 4G LTE or 5G cellular modems that are pre-approved for use on numerous leading global cellular networks.
// LOADING...
Browse Our Range Of IIoT Gateways
-
iEP-6020E-003
iEP-6020E-003 with Jetson Orin NX 16GB, 5G or 4G LTE module, Nano SIM, dual GbE -
iEP-6020E-000
iEP-6020E-000 with Jetson Orin NX 16GB, dual GbE, CAN, two COM and optional second SSD -
iEP-6020E-001
iEP-6020E-001 with Jetson Orin NX 16GB, two 802.3af PoE ports, dual GbE and CAN -
iEP-6020E-002
iEP-6020E-002 with Jetson Orin NX 16GB, four 802.3af PoE ports and dual GbE
- AI Performance: 100 TOPS
- SOM: NVIDIA Jetson Orin NX 16GB
- Memory: 16GB Soldered On-board
- OS: Linux, Linux Ubuntu 22.04
- Display Outputs: 1x HDMI
- USB: 2x USB 2.0 [Type A], 2x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
- CANbus: 1x CANbus [DB15]
- Power: 12-36V DC Input [Terminal Block]
- Temp: -25°C to 50°C [-13°F to 122°F]
- Certification: CE, FCC
- Ethernet: 2x GbE LAN [RJ45]
- M.2: 1x M.2 B-Key [PCIe x1 Gen3/USB 3.2 Gen 2] [2280/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4] [2280]
- Storage: 1x M.2 SSD, 1x Micro SD
- Mounting Options: DIN Mount, Wall Mount
- OS: Linux
- Storage: 1x Micro SD
- Power: 9-36V DC Input [Terminal Block]
- Temp: 0°C to 60°C [32°F to 140°F]
- Certification: CE, FCC
- AI Performance: 40 TOPS
- SOM: NVIDIA Jetson Orin Nano 8GB
- Memory: 8GB Soldered On-board
- OS: Linux, Linux Ubuntu 20.04
- Display Outputs: 1x HDMI
- USB: 2x USB 2.0 [Type A], 2x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
- CANbus: 1x CANbus [DB15]
- Storage: 1x Micro SD, 2x M.2 SSD
- Power: 12-36V DC Input [Terminal Block], 20V [USB-C]
- Temp: -25°C to 60°C [-13°F to 140°F]
- Certification: CE, FCC, LVD
- Ethernet: 2x GbE LAN [RJ45]
- M.2: 1x M.2 B-Key [PCIe x1 Gen3/USB 3.2 Gen 2] [2280/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 M-Key [PCIe x4/SATA] [2280]
- Mounting Options: DIN Mount, Wall Mount
- AI Performance: 100 TOPS
- SOM: NVIDIA Jetson Orin NX 16GB
- Memory: 16GB Soldered On-board
- OS: Linux, Linux Ubuntu 20.04
- Display Outputs: 1x HDMI
- USB: 2x USB 2.0 [Type A], 2x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
- CANbus: 1x CANbus [DB15]
- Storage: 1x Micro SD, 2x M.2 SSD
- Power: 12-36V DC Input [Terminal Block], 20V [USB-C]
- Temp: -25°C to 60°C [-13°F to 140°F]
- Certification: CE, FCC, LVD
- Ethernet: 2x GbE LAN [RJ45]
- M.2: 1x M.2 B-Key [PCIe x1 Gen3/USB 3.2 Gen 2] [2280/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 M-Key [PCIe x4/SATA] [2280]
- Mounting Options: DIN Mount, Wall Mount
-
iEP-5000G-002
iEP-5000G with 5x GbE, Wi-Fi option and -40 to 70 °C operation -
iEP-5000G-000
iEP-5000G with 3x GbE, DC jack 6-36 V input, 65 W adapter and 4G/5G option -
iEP-5000G-001
iEP-5000G with 2x IEEE 802.3af PoE, 5x GbE, Wi-Fi option and 19-36 V DC -
iEP-5000G-010
iEP-5000G with 3x GbE, terminal block 6-36 V input and 4G/5G option
- CPU: Intel Atom X Series Elkhart Lake
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 32GB
- OS: Linux, Windows 11
- Display Outputs: 1x HDMI, 1x VGA
- USB: 2x USB 2.0 [Type A], 2x USB 3.2 Gen 2 [Type A]
- Serial: 3x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD, 1x Micro SD
- Certification: CE, FCC
- Mounting Options: DIN Mount, Wall Mount
- Ethernet: 5x GbE LAN [RJ45]
- Power: 6-36V DC Input [Barrel Connector]
- Temp: -40°C to 70°C [-40°F to 158°F]
- CPU: Intel Core 13th Gen Raptor Lake
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
- OS: Linux, Linux Ubuntu 22.04, Windows 11
- Display Outputs: 2x Display Port
- USB: 1x USB 2.0 [Type A], 3x USB 3.2 Gen 2 [Type A]
- Serial: 4x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
- Temp: -40°C to 70°C [-40°F to 158°F]
- Certification: CE, FCC
- Mounting Options: DIN Mount, Wall Mount
- Ethernet: 2x GbE LAN [RJ45] [PoE], 3x GbE LAN [RJ45]
- Storage: 1x M.2 SSD, 1x Micro SD
- Power: 19-36V DC [Terminal Block]
- CPU: Intel Core 12th Gen Alder Lake
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
- OS: Linux, Windows 11
- Display Outputs: 1x Display Port, 1x HDMI, 1x VGA
- Ethernet: 2x 2.5 GbE LAN [RJ45] [PoE], 3x GbE LAN [RJ45]
- USB: 1x USB 2.0 [Board], 6x USB 3.1 Gen 1 [Type A]
- Serial: 2x RS232 [DB9], 4x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4/SATA] [2280]
- mPCIe: 2x mPCIe [PCIe/USB]
- Storage: 1x CFAST, 1x M.2 SSD, 4x 2.5" HDD/SSD
- Front Accessible Storage: Front Accessible Storage
- Power: 9-36V DC Input [Terminal Block]
- Ignition Sensing: Supports Ignition Control
- Temp: -40°C to 50°C [-40°F to 122°F], -40°C to 70°C [-40°F to 158°F]
- Certification: CE, FCC
- Mounting Options: Desktop
- CPU: Intel Core 12th Gen Alder Lake
- Memory: 2x DDR4 3200MHz SO-DIMM Slots, 64GB
- OS: Linux, Windows 11
- Display Outputs: 1x Display Port, 1x HDMI, 1x VGA
- Ethernet: 2x 2.5 GbE LAN [RJ45], 2x 2.5 GbE LAN [RJ45] [PoE]
- USB: 1x USB 2.0 [Board], 2x USB 2.0 [Type A], 2x USB 3.1 Gen 1 [Type A], 2x USB 3.2 Gen 2 [Type A]
- Serial: 2x RS232 [DB9], 4x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
- mPCIe: 2x mPCIe [PCIe/USB]
- Storage: 1x CFAST, 4x 2.5" HDD/SSD
- Front Accessible Storage: Front Accessible Storage
- Power: 9-36V DC Input [Terminal Block]
- Ignition Sensing: Supports Ignition Control
- Temp: -40°C to 50°C [-40°F to 122°F], -40°C to 70°C [-40°F to 158°F]
- Certification: CE, FCC
- Mounting Options: Desktop
- CPU: Intel Celeron N Series Apollo Lake, Intel Pentium N Series Apollo Lake
- Memory: 4GB Soldered On-board
- OS: Linux Ubuntu 20.04, Windows 10
- Display Outputs: 1x USB Type C
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 2.0 [Type A]
- Storage: 64GB eMMC
- Power: 9-36V DC Input [Terminal Block]
- Temp: 0°C to 55°C [32°F to 131°F]
- IP Rating: IP30
- Certification: CE, FCC
- Mounting Options: Desktop, Wall Mount
-
VIG-120M
VIG-120M with i.MX 6UL, 2x M12 LAN, 2x CAN bus and 4x RS-232/422/485 -
VIG-100
VIG-100 with i.MX 6UL, 2x RJ45 LAN, 2x RS-232/422/485 and mini PCIe -
VIG-100M
VIG-100M with i.MX 6UL, 2x M12 LAN, 2x RS-232/422/485 and mini PCIe -
VIG-110
VIG-110 with i.MX 6UL, 2x RJ45 LAN, 4x RS-232/422/485 and 8 GPIO -
VIG-110M
VIG-110M with i.MX 6UL, 2x M12 LAN, 4x RS-232/422/485 and 8 GPIO -
VIG-120
VIG-120 with i.MX 6UL, 2x CAN bus, 4x RS-232/422/485 and 8 GPIO
- CPU: i.MX 6UL
- Memory: 512MB Soldered On-board
- OS: Linux Debian 9, Linux
- USB: 1x USB 2.0 [Type A]
- mPCIe: 1x mPCIe [USB/SIM]
- Storage: 1x Micro SD, 512MB NAND Flash
- Power: 6-40V DC Input [Terminal Block]
- Temp: -25°C to 70°C [-13°F to 158°F]
- Certification: CE, EN50121-3-2, EN50155, FCC, RoHS
- Mounting Options: DIN Mount, Wall Mount
- Ethernet: 2x 10/100 LAN [M12]
- Serial: 2x RS232/422/485 [RJ45], 2x RS232/422/485 [DB9]
- CANbus: 2x CANbus [Terminal Block]
- CPU: Intel Celeron N Series Apollo Lake, Intel Pentium N Series Apollo Lake
- Memory: 4GB Soldered On-board
- OS: Linux Ubuntu 20.04, Windows 10
- Display Outputs: 1x Optional HDMI
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 3.2 Gen 1 [Type A]
- Storage: 32GB eMMC
- Power: 9-36V DC Input [Terminal Block]
- Temp: 0°C to 55°C [32°F to 131°F]
- IP Rating: IP30
- Certification: CE, FCC
- Mounting Options: Desktop, Wall Mount
- CPU: i.MX 6ULL
- Memory: 512MB Soldered On-board
- OS: Linux Debian 9, Linux
- Ethernet: 2x 10/100 LAN [RJ45]
- USB: 1x USB 2.0 [Type A]
- Serial: 2x RS232/485 [Terminal Block]
- mPCIe: 1x mPCIe [USB/SIM]
- Power: 9-50V DC Input [Terminal Block]
- Temp: -25°C to 70°C [-13°F to 158°F]
- Certification: CE, EN50121-3-2, EN50155, FCC, RoHS
- Mounting Options: DIN Mount, Wall Mount
- CANbus: 2x CANbus [Terminal Block]
- Storage: 1x Micro SD, 32GB eMMC
- CPU: Sitara AM3352
- Memory: 1GB Soldered On-board
- OS: Linux Debian 9
- Ethernet: 2x 10/100 LAN [RJ45]
- USB: 1x USB 2.0 [Type A]
- mPCIe: 1x mPCIe [USB/SIM]
- Storage: 2x Micro SD
- Power: 12-25V DC [Terminal Block], PoE Powered Device (PD) [RJ45]
- Temp: -25°C to 70°C [-13°F to 158°F]
- Certification: CE, FCC
- Mounting Options: DIN Mount
- Serial: 1x RS232/422/485 [Terminal Block], 1x RS485 [Terminal Block]
- CPU: Intel Celeron J Series Apollo Lake
- Memory: 1x DDR3L 1866MHz SO-DIMM Slot, 8GB
- OS: Linux, Windows 10
- Display Outputs: 1x Display Port
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 2.0 [Type A], 2x USB 3.0 [Type A]
- Serial: 1x RS232/485 [DB9], 2x RS232 [DB9]
- M.2: 1x M.2 A-Key [USB/PCIe] [2230], 1x M.2 B-Key [USB/SATA] [2242/3042]
- mPCIe: 1x mPCIe [PCIe/USB]
- Storage: 16GB eMMC, 1x M.2 SSD
- Power: 12-24V DC [Barrel Connector], Optional AC Power Supply
- Temp: -5°C to 55°C [23°F to 131°F]
- Certification: CE, FCC
- Mounting Options: Desktop, Wall Mount
- CPU: Sitara AM3352
- Memory: 1GB Soldered On-board
- Ethernet: 1x 10/100 LAN [RJ45]
- USB: 1x USB 2.0 [Type A]
- mPCIe: 1x mPCIe [USB/SIM]
- Storage: 2x Micro SD
- Power: 8-25V DC [Terminal Block]
- Temp: -25°C to 70°C [-13°F to 158°F]
- Certification: CE, FCC
- Mounting Options: DIN Mount
- OS: Linux Debian 8
- Serial: 2x RS232/422/485 [Terminal Block]
Industrial Internet of Things Solutions
As a leading system integrator for industrial edge computing, we support global manufacturing companies, energy management OEMs, and transportation operators implement edge gateways for their diverse monitoring, networking, and data gathering needs in demanding harsh environments. Whether it’s the high-temperature surroundings of a manufacturing floor, the unpredictable conditions of a transportation hub, or the critical operations of an energy management system, our edge gateways are engineered to perform consistently and reliably.
// Next Step
Tell us what you're building.
Send us the application, the deployment environment, and the lifecycle expectation. We'll come back with a platform recommendation, a BOM, and a service stack matched to it.
