Nexcom NISE 53-E01 Intel Celeron J6413 Elkhart Lake Small Form Factor Industrial PC with 3x GbE

A machine controller with three screens or a retail system running a full application benefits from four cores, even inside a case thin enough to fit a crowded cabinet. The NISE 53-E01 is a Small Form Factor Industrial PC from the Nexcom NISE 53 series, built on the Intel Celeron J6413 in a fanless metal case 26 mm high. Its sibling, the NISE 53-E02, uses the dual-core Atom x6211E for lighter duties.

The quad-core Celeron J6413 at 1.8 GHz is an Elkhart Lake processor with Intel UHD graphics, and one DDR4 2133 SO-DIMM socket takes up to 16 GB. Storage can be an M.2 SATA module in the front-access Key B socket, an mSATA module in the mini-PCIe socket or the optional 32 GB eMMC. Windows 11, Windows 10 Enterprise 64-bit and Linux kernel 4.19 are supported on the NISE 53-E01.

Three HDMI ports drive three independent displays at 1920 x 1080 and 60 Hz. Networking is one Intel I210-AT port and two Marvell GbE ports, and two DB9 ports support RS232 or RS485, COM1 with auto flow control, which suits Modbus TCP and RTU links. There are two USB 3.0 and two USB 2.0 ports, and the mini-PCIe and internal M.2 Key B sockets share a nano SIM holder for 4G LTE, Wi-Fi or Bluetooth. Four GPI, four GPO and TPM 2.0 are onboard the NISE 53-E01.

Power is 12 V or 24 V DC through a three-pin terminal block, with AT and ATX modes and a remote power switch header, and a 24 V, 60 W adapter is the default. This Small Form Factor Industrial PC runs from -5 °C to 55 °C, is rated to 50 G shock and 2 Grms vibration, and carries CE and FCC Class A approval.
