Sintrones VDB-810G u-blox M8 GPS Mini PCIe Card with G-Sensor

Fleet operators often want to know how a vehicle was driven as well as where it went, and that means motion data alongside the position fix. The Sintrones VDB-810G is the G-sensor build of the VDB-810 series: a full-size Mini PCIe GPS card with a u-blox M8 receiver and a 3-axis accelerometer on the same card, so one slot can provide both. The VDB-810 is the same card without the G-sensor.

The u-blox M8 engine on the VDB-810G has 72 channels and receives GPS/QZSS, GLONASS and BeiDou concurrently, with SBAS. Sintrones quotes -167 dBm tracking and navigation sensitivity, -160 dBm acquisition and -148 dBm for an autonomous cold start, with a 26 s cold start, 2 s aided start and 1 s hot start. Horizontal accuracy is under 2.5 m CEP autonomous or 2.0 m CEP with SBAS, and the timepulse is accurate to 30 ns RMS.

The card connects over USB 2.0 as a Mini PCIe V1.2 full-mini card, with NMEA 0183 V4.0, UBX and RTCM 2.3 output at up to 10 Hz with GPS and GLONASS or 18 Hz with GPS alone. AssistNow Online and Offline A-GPS is supported and OMA SUPL compliant, and the receiver handles velocities under 500 m/s and accelerations up to 4 g, with intelligent multipath detection and suppression.

Power is 3.3 V DC ±10%, with 150 mA peak, 74 mA in acquisition and 43 mA when tracking in eco mode. The VDB-810G is rated from -40 °C to 85 °C, stores across the same range and measures 51 x 30 mm. It suits Sintrones computers with a free full-size Mini PCIe slot carrying USB 2.0, and we fit and test it in the host computer as part of the build, with the antenna cabling routed to the enclosure. For dead reckoning in an M.2 2242 Key B slot, see the VDB-811DR-M2.
