Winmate OMIVEAC-IAD7T Intel Core i7-14700T 2U Fanless Rack Server with Wide Temperature

A server in an equipment room or a cabinet beside the process often has to cope with heat, dust and supply quality that would trouble a fan-cooled IT box. The OMIVEAC-IAD7T is Winmate’s fanless 2U rack server for that environment, pairing an Intel Core i7-14700T with fiber and copper networking and a listing against IEC 61850-3.

The Core i7-14700T runs at up to 5.2 GHz with 33 MB of cache on the Intel R680E chipset. One DDR5-4800 SO-DIMM carries 32 GB, and storage is a 512 GB NVMe SSD on an M.2 2280 M-key slot, with two optional front 2.5″ SATA III bays for RAID 0 and 1. TPM 2.0 is on board, with Windows 11 IoT Enterprise, Windows 11 Pro or Linux Ubuntu 22.04. That gives the OMIVEAC-IAD7T room for SCADA, historians and virtualized control workloads without moving parts in the cooling path.

Networking is the stand-out: a dual-port 10GbE SFP+ fiber riser card in the PCIe x16 slot ships as standard, alongside four 2.5GbE RJ45 ports, on five Intel Ethernet controllers. There are two front USB 2.0 ports and four rear USB 3.2 Gen 2×1 ports, one RS-232/422/485 port and two RS-232 ports, DisplayPort 1.4a at up to 4096 x 2160 at 60 Hz, optional HDMI 2.0b, mic in and line out. Within the Winmate range the IAD7T-RK2U is the fan-cooled 2U server with a choice of Core i5, i7 or i9 and an optional GPU, and the W4U-IRP-S is a 4U server with more expansion slots.

Power is 110 to 240 V AC or DC, plus or minus 20%, on a Phoenix Contact terminal block, and the server operates from -10 to 60 °C at 10 to 95% humidity. Its certification row lists IEC 61850-3, IEC 60068-2-64 and IEC 60068-2-2 with CE and FCC. We supply the OMIVEAC-IAD7T configured, with the OS installed, and tested before dispatch.
