Yuan AIR6N0-C NX SDVoE-F NVIDIA Jetson Orin NX Super Edge AI Computer with SDVoE Multi-Mode Fiber Input

When video is already traveling as SDVoE, running AI on it usually means converting back to baseband and capturing it in a separate computer. The AIR6N0-C NX SDVoE-F is Yuan’s NVIDIA Jetson Orin NX Super edge AI computer that takes the SDVoE stream directly. It suits analytics on live AV feeds, such as object detection, OCR or license plate recognition, without adding a receiver and capture card between the network and the AI computer.

The SDVoE input is a duplex LC port for 10G multi-mode fiber, and it works as a DHCP client. A further RJ45 port provides 10/100/1000 Ethernet, and a Mini DisplayPort 1.4 output drives a local display. For video, the module encodes AV1, H.265 and H.264 up to one 4K60 stream and decodes AV1 and H.265 up to 8K30, with H.264 and VP9 decode up to 4K60. Yuan’s QCAP SDK streams over RTSP, RTMP, HLS, SRT, TS and WebRTC, with NDI HX and Full NDI under a separate license.

Yuan offers the Jetson Orin NX 16GB Super at 157 TOPS or the 8GB Super at 117 TOPS. The unit has one USB 3.2 Gen2 Type-C port, an M.2 M-Key PCIe Gen4 x2 slot, an M.2 E-Key PCIe Gen4 x1 slot and eight MIPI CSI-2 lanes for MIPI cameras or capture cards. Power is a 12 to 36 V DC input. The QDEEP AI SDK and the optional Xtreamer web interface add analytics and set-up tools. The AIR6N0-C NX SDVoE-C is the same computer with a 10G copper SDVoE input, and the Multi to SDVoE Pro 4K-F is a matching SDVoE source for the fiber link.

The AIR6N0-C NX SDVoE-F runs JetPack 6.2 or higher, operates from 0 to 60 °C with airflow and carries CE and FCC marks. We supply it configured and tested, with the Jetson module, NVMe storage and JetPack image fitted before it ships.
