Yuan SC350N1-L 3D PCIe Analog Frame Grabber with Composite and S-Video Inputs, PAL and NTSC
PCI ExpressSC350N1-L 3D Overview
Composite video carries brightness and color on one wire, and poor separation shows up as color fringing on fine detail. The SC350N1-L 3D is Yuan’s PCIe Analog frame grabber for one composite or S-Video source, with a 3D Y/C comb filter to separate the two. It suits analog cameras and legacy outputs where the captured picture is inspected, recorded or analyzed.
The card captures NTSC at 720 x 480 and 29.97 fps or PAL at 720 x 576 and 25 fps, the D1 sizes. Yuan lists RGB24, RGB32, YUY2, YV12 and NV12 capture formats, and on-card cropping, scaling, auto signal detection and deinterlacing alongside the comb filter. S-Video sources, which already carry brightness and color separately, connect through their own input. Two RCA connectors capture audio at 16-bit, 48 kHz.
The card fits a PCIe x1 slot and carries 16 GPIO lines and a watchdog. Yuan lists multi-instance and multi-device support, and DirectShow and V4L2 drivers let vMix, OBS, Zoom, Skype, Teams, Discord, Slack, Cisco Webex and GoToMeeting use it, with Yuan’s Windows and Linux SDK for custom software. The SC300N1-L is the single-input card without the comb filter, and the SC350N4-L captures four composite feeds at up to 960 x 576.
Yuan lists Windows 7, Windows 8, Windows 8.1 and Windows 10, Linux 2.6.14 or higher in 32-bit and 64-bit builds, Linux on ARM, and NVIDIA Jetson TX2, Nano, AGX Xavier and Xavier NX, so the card can sit in an x86 PC or feed an ARM or Jetson based system. The board measures 101.03 x 68.9 mm. Yuan does not state an operating temperature range on its model page, so ask us where the card will run in an enclosed cabinet.
SC350N1-L 3D Specifications
| Overview | |
|---|---|
| Brand & Model | Yuan SC350N1-L 3D |
| Video Capture | |
| Host Interface | PCIe [x1, Gen1] |
| Simultaneous Video Inputs | 1 |
| Video Input | 1x Composite 1x S-Video |
| Video Resolution Input | 480p30 [720x480 @ 30fps] 576p25 [720x576 @ 25ps] |
| Video Resolution Output | 480p30 [720x480 @ 30fps] 576p25 [720x576 @ 25ps] |
| Color Format | NV12 RGB24 RGB32 YUY2 YV12 |
| Audio Input | 2x RCA Audio Input |
Official Yuan USA Distributor
Things Embedded is an official Yuan USA distributor, supplying the SC350N1-L 3D for USA analog video capture projects. Within the Yuan range the SC300N1-L is the single-input card without the comb filter, and the SC350N4-L takes four composite sources at up to 960 x 576.
As a single-input analog card the SC350N1-L 3D sits among our PCIe capture cards and our wider video capture card range. Where one composite source must be captured with clean color separation, this is the model to specify.
