Premio JCO-1000-ORN-A-1L NVIDIA Jetson Orin NX or Orin Nano Fanless Embedded Computer with 4x USB 3.2 Gen 2

Machine vision stations and factory automation cells often need GPU inference and plain I/O in a unit with no fan to clog. The Premio JCO-1000-ORN-A-1L is the entry-level build of the JCO-1000-ORN series, a fanless edge AI computer on NVIDIA Jetson Orin NX or Orin Nano with four USB 3.2 Gen 2 ports and a single GbE port.

The module sets the performance, from 20 TOPS on Orin Nano 4GB and 40 TOPS on Orin Nano 8GB to 70 and 100 TOPS on Orin NX 8GB and 16GB, or up to 157 TOPS on Orin NX 16GB in Super Mode. Storage is an M.2 PCIe x4 NVMe SSD (128 GB by default) plus Micro SD. The JCO-1000-ORN-A-1L runs JetPack 6.2 on Ubuntu 22.04 or JetPack 7.2 on Ubuntu 24.04, with TPM 2.0 and a watchdog timer.

Four USB 3.2 Gen 2 ports suit USB cameras and peripherals, alongside a GbE port, two RS-232/422/485 DB9 ports, one CAN 2.0 B port, four isolated digital inputs and four outputs, and a microphone and line-out pair. An HDMI 2.0 output gives 4K at 60 Hz on Orin NX (30 Hz on Orin Nano). An M.2 B key socket with a dual nano-SIM socket takes an optional 4G/5G module, an M.2 E key socket takes optional Wi-Fi and Bluetooth, and internal MIPI CSI-2 connectors sit on the board.

Power is 9 to 36 V DC on a terminal block with AT and ATX modes, adjustable ignition management and an optional AC/DC adapter. The fanless unit runs from -20 °C to 55 °C at 15 W or 25 W and to 35 °C at 40 W, and is designed to comply with MIL-STD-810H for shock and vibration. It carries CE, FCC Class B, UKCA and UL 62368-1 marks, and mounts on a wall or an optional DIN rail. We supply the JCO-1000-ORN-A-1L configured and tested, with the NVMe SSD, JetPack image and any wireless modules fitted. The JCO-1000-ORN-B-2L adds 2.5GbE and E-Mark, and the JCO-1000-ORN-C-2M12 moves both LAN ports to M12.
