Premio RCO-3000-RPL Intel Core Series 2 or 14th Gen Rugged Fanless PC with Quad DisplayPort, Dual 2.5GbE and -25 to 70 °C

Vehicles, rail cabinets and machine enclosures are often cramped, hot or cold, and subject to vibration, so a fanless computer on wide-range DC usually suits. The Premio RCO-3000-RPL is a rugged fanless PC in a small form factor for Core Series 2 and 12th to 14th Gen Intel Core processors, with four DisplayPort outputs, dual 2.5GbE, an EDGEBoost I/O bracket and a 9 to 48 V DC input.

An LGA1700 socket on the Intel Q670E chipset takes 45 W Core 7 251TE, Core 5 221TE and Core 3 201TE processors, or 35 W 14th Gen T and 12th and 13th Gen TE Core i3 to i9 parts. One DDR5 4800/5600 SO-DIMM socket holds up to 48 GB. The RCO-3000-RPL is ready for an optional Hailo-8 AI module on its M.2 B key, and TPM 2.0 is on board, with Windows 11 and Linux supported.

Two Intel I226 2.5GbE ports support TSN, with six USB 3.2 Gen 2 ports, five RS-232/422/485 ports (two inside), two internal CAN 2.0 A/B headers and isolated 8-in/8-out digital I/O. Storage covers one internal and one hot-swappable 2.5″ SATA bay with RAID 0, 1 and 5, and two M.2 B key sockets take NVMe drives or optional 4G and 5G modules, with three external SIM sockets. The EDGEBoost I/O bracket takes one optional module, such as 4-port GbE (RJ45 or M12, PoE optional), dual 10GbE, USB or out-of-band management.

Power comes in on a 9 to 48 V DC 3-pin terminal block with ignition management and AT or ATX modes. The RCO-3000-RPL runs fanless from -25 °C to 70 °C with 35 W and 45 W processors, is designed to comply with MIL-STD-810H for shock and vibration, and meets EMC to EN 50121-3-2 (the EN 50155 EMC clause). It is UL listed to UL 61010-1 with CE, FCC and UKCA marks, and mounts on a vibration-isolated wall kit. We supply it configured and tested, with memory, storage, any EDGEBoost module and the OS image fitted. For GPU cards on EDGEBoost Nodes, see the RCO-6000-RPL-2E16, and for triple 2.5GbE on 9 to 36 V DC, the BCO-3000-RPL.
