Winmate M900AD 8″ Military Rugged Tablet with 12th Gen Intel Core i5, MIL-STD-461G and IP66
PCAP
Intel
Windows
Type C
USB3
GPS/GLONASS
Wi-Fi
Extended Temp
CE
FCCM900AD Overview
A soldier, inspector or field engineer working on foot often needs a full Windows computer that fits in one hand and survives rain, dust and drops. The M900AD is Winmate’s 8 inch military rugged tablet for that role, with an Intel Core i5-1235U, an 8″ optically bonded display, IP66 sealing and MIL-STD-461G EMC. Winmate names field service, inspection, industrial mobility and mission-critical applications as its uses.
The Core i5-1235U is a 12th Gen Alder Lake processor with Intel Iris Xe graphics, and an Intel Core 5 120U is offered as an option. Memory is 8 GB as standard with 16 GB optional, and storage is a 256 GB SSD with 512 GB and 1 TB options. TPM 2.0 is fitted, SOTI MobiControl is supported, and the tablet runs Windows 11 IoT Enterprise LTSC. The 8 inch screen shows 1280 x 800 at 800 nits with 1500:1 contrast, optical bonding and anti-glare treatment under projected capacitive multi-touch, and a capacitive stylus is optional.
A Gigabit LAN port, one USB 3.0 Type-A port and two lockable USB-C ports, with 20 V power delivery in and display output, sit on the tablet, alongside a 19-pin docking connector. Wi-Fi, Bluetooth, GPS and GLONASS are built in; 4G LTE, 5G and HF RFID are optional, with a Nano SIM slot. A 2 MP front camera, an 8 MP autofocus rear camera with LED light, light, G and gyro sensors, and three programmable keys complete it. The M101AD is the 10.1 inch model with the same processor and an optional barcode reader, and the M116AD is the 11.6 inch model with an 850 nit screen.
The M900AD is sealed to IP66, tested to MIL-STD-810H Methods 516.8 and 514.8 for shock, vibration and a 5 ft drop, and lists MIL-STD-461G and STANAG 4370 EMC tests. A fan cools it from -20 °C to 60 °C. The hot-swappable battery runs for around six hours, and power comes from a 20 V adapter or USB-C; a hand strap, vehicle charger and battery charger are optional. We supply it configured, with Windows installed, and tested, ready to deploy.
M900AD Specifications
| Overview | |
|---|---|
| Brand & Model | Winmate M900AD |
| Features | Rugged Waterproof |
| Display | |
| Display | 8"[8:5, 1280 x 800, WXGA] |
| Display Treatment | Anti-Glare Treatment Optical Bonding |
| Touch Controller | Multi Touch PCAP |
| Brightness | 800 Nits |
| Viewing Angle | Wide Viewing Angle |
| 160° Horizontal, 160° Vertical | |
| Aspect Ratio | 8:5 |
| Format | Widescreen |
| Contrast | 1500:1 |
| Performance | |
| Processor Series | Core Series 1 Raptor Lake Intel Core 12th Gen Alder Lake |
| Processor Models | Core 5 120U Intel Core i5-1235U: 1.3~4.4GHz, 10 Cores, 12 Threads, 12MB Cache, 15W |
| Performance Cores | 10 Cores |
| Secure Crypto Processor | TPM 2.0 (Trusted Platform Module) |
| Operating System | Windows 11 |
| Graphics | |
| Integrated GPU | Intel Graphics Intel Iris Xe Series |
| Display Outputs | 2x USB Type C |
| I/O | |
| Ethernet | 1x Ethernet Ports |
| 1x GbE LAN [RJ45] | |
| USB | 3x USB Ports |
| 1x USB 3.0 [Type A] 2x USB 3.2 Gen 1 [Type C] | |
| Expansion | |
| Wireless Connectivity | Optional 4G Modem Optional 5G Modem |
| Power | |
| Power Input | 20V [USB-C] AC Power Supply Included |
| Environmental Conditions | |
| Thermal Dissipation | Onboard Fan |
| Operating Temperature | -20°C to 60°C [-4°F to 140°F] |
| Storage Temperature | -30°C to 70°C [-22°F to 158°F] |
| Ingress Protection | IP66 IP66 [Dustproof, Protection against powerful water jets spraying from any direction] |
| Shock | MIL-STD-810H |
| Vibration | MIL-STD-810H |
| EMC | MIL-STD-461G |
| Certification | CE FCC MIL-STD-461 MIL-STD-810 |
| Mechanical Properties | |
| Weight | 1.0 Kg (2.2 Lbs) |
| Dimensions | 227mm x 148mm x 27mm (8.92" x 5.82" x 1.06") |
- M900AD Datasheet Download
Official Winmate USA Distributor
Things Embedded is an official Winmate USA distributor, supplying the M900AD configured and tested for USA defense, field service and inspection projects. Within the Winmate range the M101AD is the 10.1 inch model with the same Core i5-1235U and a 1920 x 1200 screen.
The M900AD sits among our military tablets, our Windows rugged tablets and our rugged tablets. Where a one-handed Windows tablet needs IP66 sealing and MIL-STD-461G EMC, this is the model to specify.
