DFI ARS103 Intel Arrow Lake-S Core Ultra Thin Mini-ITX SBCs with 12 to 28 V DC Input and Dual 2.5GbE
The DFI ARS103 series is a family of Thin Mini-ITX SBCs for Intel Core Ultra 200S (Arrow Lake-S) processors in the LGA 1851 socket, from the 10-core Core Ultra 5 225T to the 24-core Core Ultra 9 285, on a 12 to 28 V DC input. Every board has dual 2.5GbE, up to 96 GB DDR5, a PCIe x16 slot and four M.2 slots. The ARS103 series suits 24 V machine cabinets, slim panel PCs, carts and kiosks.
- 12 to 28 V DC Input: Wide-range 12 to 28 V DC on a barrel jack or 4-pin connector runs the board from 12 V, 24 V or battery supplies.
- Intel Core Ultra 200S on LGA 1851: Socketed Arrow Lake-S processors from the 10-core Core Ultra 5 225T to the 24-core Core Ultra 9 285, at up to 65 W TDP.
- Thin Mini-ITX at 170 x 170 mm: A low-profile Thin Mini-ITX board for slim enclosures, panel PCs and carts where the height above the board is limited.
- Dual 2.5GbE and DDR5: Two 2.5GbE ports on Intel I226 controllers and two DDR5 SO-DIMMs in dual channel, holding up to 96 GB.
- PCIe x16 and Four M.2 Slots: A PCIe x16 slot plus M.2 M, B, E and A keys for NVMe, cellular, Wi-Fi and display modules, with CE, FCC, UKCA and RoHS.
Intel- Linux
- Windows
Quad Display Support
2.5GbE
USB3- 4x M.2
- 1x PCIe
- Wi-Fi
- NVMe SSD
- CE
- FCC
Type C
ARS103 Description
Many slim systems do not sit on a tidy 12 V rail. A machine cabinet distributes 24 V DC, a medical or logistics cart runs from a battery pack, and a kiosk builder may fit whatever supply suits the enclosure. The DFI ARS103 series accepts 12 to 28 V DC directly, so a Thin Mini-ITX motherboard with a socketed Intel Core Ultra 200S (Arrow Lake-S) processor can go into those systems without a separate converter.
The LGA 1851 socket takes eight Core Ultra 200S processors: the Core Ultra 9 285 and 285T with 24 cores, the Core Ultra 7 265 and 265T with 20, and the Core Ultra 5 245, 245T, 225 and 225T with 14 or 10 cores, at up to 65 W TDP. DFI caps the processor’s maximum turbo power at 100 W on this board, or 80 W when a graphics card is fitted. Two DDR5 SO-DIMMs hold up to 96 GB in dual channel. Integrated Intel graphics drives HDMI 1.4b and DP++ outputs at 4K, with an optional M2A module for an eDP or LVDS panel.
Three chipset builds make up the range. ARS103-W880 pairs the W880 chipset with ECC memory support, Intel AMT, six rear USB 3.2 Gen 2 ports and a PCIe x16 Gen5 slot that splits into two x8 links. ARS103-Q870 keeps AMT and the bifurcating Gen5 slot without ECC, with five rear USB 3.2 Gen 2 ports. ARS103-H810 is the simpler H810 build, with HDMI and DP++, a PCIe x16 slot and a mix of USB 3.2 Gen 1 and USB 2.0 ports.
Every board carries two 2.5GbE ports on Intel I226 controllers, two internal RS-232/422/485 headers, 8-bit DIO and two SATA 3.0 ports. Four M.2 sockets take an NVMe or SATA SSD on the M-key, a cellular module with Nano SIM on the B-key, Wi-Fi on a 2230 E-key and the display module on the A-key. Realtek ALC888 audio, a Nuvoton TPM 2.0 and a watchdog programmable from 1 to 255 seconds are on board.
Power arrives on a barrel jack or 4-pin connector, both rated 12 to 28 V DC. The ARS103 series operates from -5 to 65 °C with CE, FCC, UKCA and RoHS compliance, and DFI lists Windows 10 and Windows 11 IoT Enterprise LTSC and Ubuntu 24.04. For a fixed 12 V supply, the ARS101 series is the same board on a 12 V input.
ARS103 Specifications
| Overview | |
|---|---|
| Brand & Model | DFI ARS103 |
| Features | Embedded Industrial |
| Performance | |
| Processor Series | Intel Core Ultra Series 2 Arrow Lake-S |
| Processor Models | Intel Core Ultra 5 225: 3.3~4.9GHz, 10 Cores, 10 Threads, 20MB Cache, 65W Intel Core Ultra 5 245: 3.5~5.1GHz, 14 Cores, 14 Threads, 24MB Cache, 65W Intel Core Ultra 5 225T: 2.5~4.9GHz, 10 Cores, 10 Threads, 20MB Cache, 35W Intel Core Ultra 5 245T: 2.2~5.1GHz, 14 Cores, 14 Threads, 24MB Cache, 35W Intel Core Ultra 7 265: 2.4~5.3GHz, 20 Cores, 20 Threads, 30MB Cache, 65W Intel Core Ultra 7 265T: 1.5~5.3GHz, 20 Cores, 20 Threads, 30MB Cache, 35W Intel Core Ultra 9 285: 2.5~5.6GHz, 24 Cores, 24 Threads, 36MB Cache, 65W Intel Core Ultra 9 285T: 1.4~5.4GHz, 24 Cores, 24 Threads, 36MB Cache, 35W |
| Performance Cores | 10 Cores 14 Cores 20 Cores 24 Cores |
| AI Performance | 13 TOPS |
| Memory | 2x DDR5 6400MHz SO-DIMM Slot, 96GB |
| Chipset | See Variant Specifications |
| BIOS | AMI |
| Secure Crypto Processor | TPM 2.0 (Trusted Platform Module) |
| Operating System | Linux Windows 11 |
| Graphics | |
| Integrated GPU | Intel UHD Series |
| Display Standards | DP++ HDMI 1.4b |
| Multi Display Support | Quad Display Support |
| Display Outputs | See Variant Specifications |
| Audio | |
| Interface | Line-Out Mic-In |
| I/O | |
| Ethernet | 2x Ethernet Ports |
| 2x 2.5 GbE LAN [RJ45] | |
| LAN Controllers | Intel I226 |
| USB | See Variant Specifications |
| Serial | 2x Serial Ports |
| 2x RS232/422/485 [Board] | |
| Digital I/O | DIO [8-lines] |
| Expansion | |
| M.2 | See Variant Specifications |
| PCIe | See Variant Specifications |
| Wireless Connectivity | Optional WiFi/Bluetooth |
| Storage | |
| Storage | 1x M.2 SSD 2x SATA Ports |
| NVMe | NVMe SSD Support |
| Power | |
| Power Input | 12-28V DC [4-Pin] 12-28V DC [Barrel Connector] |
| Environmental Conditions | |
| Operating Temperature | -5°C to 65°C [23°F to 149°F] |
| Storage Temperature | -40°C to 85°C [-40°F to 185°F] |
| Humidity | 5% - 90% (Non-condensing) |
| Certification | CE FCC RoHS UKCA |
| Mechanical Properties | |
| Dimensions | 170mm x 170mm (6.69" x 6.69") |
No specifications match your search.
See product variants.
ARS103 Variants
DFI ARS103-H810 Intel LGA 1851 Core Ultra 200S Thin Mini-ITX Motherboard with H810 Chipset, Dual 2.5GbE and 12 to 28 V DC Input
ARS103 with Intel H810, dual 2.5GbE, HDMI, DP++ and 12 to 28~V DC
| Overview | |
|---|---|
| Brand & Model | DFI ARS103-H810 |
| Performance | |
| Chipset | Intel H810 |
| Graphics | |
| Display Outputs | 1x Display Port, 1x HDMI |
| I/O | |
| USB | 8x USB Ports |
| 2x USB 2.0 [Board], 3x USB 3.2 Gen 1 [Type A], 3x USB 2.0 [Type A] | |
| Expansion | |
| M.2 | 4x M.2 Expansion Slots |
| 1x M.2 A-Key [PCIe x1 Gen4] [3030], 1x M.2 B-Key [PCIe x1 Gen4/USB 3.2 Gen 1/USB 2.0/SATA] [2242/3042/3052], 1x M.2 E-Key [PCIe x1 Gen4/USB 2.0] [2230], 1x M.2 M-Key [PCIe x1 Gen4/SATA] [2280] | |
| PCIe | 1x PCIe Slots |
| 1x PCIe [x16 Slot] [x16 Signal] [Gen4] | |
DFI ARS103-Q870 Intel Arrow Lake-S Core Ultra Thin ITX Motherboard with Q870 Chipset, Dual 2.5GbE and 12 to 28 V DC Input
ARS103 with Intel Q870, Intel AMT, PCIe x16 Gen5 and 12 to 28~V DC
| Overview | |
|---|---|
| Brand & Model | DFI ARS103-Q870 |
| Performance | |
| Chipset | Intel Q870 |
| Graphics | |
| Display Outputs | 1x Display Port, 1x HDMI, 1x USB Type C |
| I/O | |
| USB | 10x USB Ports |
| 1x USB 3.2 Gen 2x2 [Type C], 4x USB 2.0 [Board], 5x USB 3.2 Gen 2 [Type A] | |
| Remote Management | Intel AMT |
| Expansion | |
| M.2 | 4x M.2 Expansion Slots |
| 1x M.2 A-Key [PCIe x1 Gen4/USB 3.2 Gen 1/USB 2.0] [3030], 1x M.2 B-Key [PCIe x1 Gen4/USB 3.2 Gen 2/USB 2.0/SATA] [2242/3042/3052], 1x M.2 E-Key [PCIe x1 Gen4/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4 Gen4/SATA] [2280] | |
| PCIe | 1x PCIe Slots |
| 1x PCIe [x16 Slot] [1x16 Signal or 2x8 Signal] [Gen5] | |
DFI ARS103-W880 Intel Core Ultra 200S LGA 1851 Thin Mini-ITX SBC with W880 Chipset, Dual 2.5GbE and 12 to 28 V DC Input
ARS103 with Intel W880, ECC memory support, Intel AMT and 12 to 28~V DC
| Overview | |
|---|---|
| Brand & Model | DFI ARS103-W880 |
| Performance | |
| Chipset | Intel W880 |
| Graphics | |
| Display Outputs | 1x Display Port, 1x HDMI, 1x USB Type C |
| I/O | |
| USB | 10x USB Ports |
| 1x USB 3.2 Gen 2x2 [Type C], 4x USB 2.0 [Board], 5x USB 3.2 Gen 2 [Type A] | |
| Remote Management | Intel AMT |
| Expansion | |
| M.2 | 4x M.2 Expansion Slots |
| 1x M.2 A-Key [PCIe x1 Gen4/USB 3.2 Gen 1/USB 2.0] [3030], 1x M.2 B-Key [PCIe x1 Gen4/USB 3.2 Gen 2/USB 2.0/SATA] [2242/3042/3052], 1x M.2 E-Key [PCIe x1 Gen4/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4 Gen4/SATA] [2280] | |
| PCIe | 1x PCIe Slots |
| 1x PCIe [x16 Slot] [1x16 Signal or 2x8 Signal] [Gen5] | |
- ARS103 Datasheet Download
No related media available for this product series.
Official DFI USA Distributor
Things Embedded is an official DFI USA distributor, supplying the ARS103 series configured with the processor, memory, storage, wireless and an OS image, fitted with its cooling and tested before it ships. ARS101 is the same Thin Mini-ITX board on a single 12 V DC input, where the supply is already regulated. ADS103 and RPS103 bring wide-range DC input to Thin Mini-ITX boards for the LGA 1700 socket, for designs already qualified on 12th, 13th or 14th Gen Intel Core processors. Our team can advise on processor choice against the workload and thermal budget, supply wiring for 24 V cabinets and carts, memory and storage sizing, and cellular and Wi-Fi modules for the M.2 slots.
For other sizes and processors, browse our Mini-ITX embedded motherboards, the wider range of industrial motherboards and our Core Ultra products, from compact boards on mobile Core Ultra processors to socketed desktop designs. Speak to a DFI specialist on our team about the build that fits your supply.
