US 17 Inch Panel PCs
17 Inch Industrial Touch Panel PCs for Operator Stations and Line Control
Seventeen inch panel PCs give operator stations, line control and SCADA clients a 5:4 screen that carries more than one process view. Available with resistive or PCAP touch and sealing from front IP65 and front IP66 bezels to fully sealed IP66 and IP69K units, they put a full control screen where the operator stands.
Options include panel-mount, chassis and VESA builds and stainless steel enclosures, suited to line control desks, process plant and hosed-down areas where the station has to survive the cleaning regime and the weather.
Speak to a panel PC specialist to match the sealing, touch technology and mounting to your operator station.
Browse Our 17 Inch Touch Screen Computers
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Optional Resistive Touch
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 9th Gen Coffee Lake
- Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
- OS: Linux Ubuntu 20.04, Windows 10
- Display Outputs: 1x Display Port
- Ethernet: 2x GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 1 [Type A]
- Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230], 1x M.2 M-Key [PCIe/SATA] [2242/2280]
- PCIe: 1x PCIe [x16 Slot] [Gen3]
- Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
- RAID: RAID 0, RAID 1
- Power: 12V DC [4-Pin], AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- Certification: CE, FCC
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Optional Resistive Touch
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 9th Gen Coffee Lake
- Memory: 2x DDR4 2400MHz SO-DIMM Slots, 64GB
- OS: Linux Ubuntu 20.04, Windows 10
- Display Outputs: 1x Display Port
- Ethernet: 2x GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 1 [Type A]
- Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230], 1x M.2 M-Key [PCIe/SATA] [2242/2280]
- PCIe: 1x PCIe [x16 Slot] [Gen3]
- Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
- RAID: RAID 0, RAID 1
- Power: 12V DC [4-Pin], AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Multi Touch PCAP
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 11th Gen Tiger Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 2x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230], 1x M.2 M-Key [PCIe] [2280]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 12V DC [Barrel Connector], AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Multi Touch PCAP
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Pentium N Series Apollo Lake
- OS: Linux Ubuntu 20.04, Windows 10
- Display Outputs: 1x Display Port
- Ethernet: 2x GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 1 [Type A]
- Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [SATA] [2242], 1x M.2 E-Key [2230]
- PCIe: 1x PCIe [x1 Slot] [Gen2]
- Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
- Power: 12V DC [4-Pin], AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Multi Touch PCAP
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 9th Gen Coffee Lake
- OS: Linux Ubuntu 20.04, Windows 10
- Display Outputs: 1x Display Port, 1x Optional HDMI
- Ethernet: 2x GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 1 [Type A]
- Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230], 1x M.2 M-Key [PCIe/SATA] [2242/2280]
- PCIe: 1x PCIe [x16 Slot] [Gen3]
- Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
- RAID: RAID 0, RAID 1
- Power: 12V DC [4-Pin], AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Multi Touch PCAP
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 11th Gen Tiger Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Serial: 1x RS232/422/485 [DB9]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 100-240V AC, 9-36V DC Input [MIL-STD]
- Temp: -20°C to 60°C [-4°F to 140°F]
- Certification: CE, FCC, MIL-STD-461, MIL-STD-810
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Optional 5-Wire Resistive Touch
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 11th Gen Tiger Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Serial: 1x RS232/422/485 [DB9]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 100-240V AC, 9-36V DC Input [MIL-STD]
- Temp: -20°C to 60°C [-4°F to 140°F]
- Certification: CE, FCC, MIL-STD-461, MIL-STD-810
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Optional Resistive Touch
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core 12th Gen Alder Lake
- Memory: 2x DDR5 4800MHz SO-DIMM Slot, 64GB
- OS: Linux Ubuntu 22.04, Windows 11
- Display Outputs: 1x Display Port
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230], 1x M.2 M-Key [PCIe] [2280]
- Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
- Power: 12V DC [4-Pin], AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- Certification: CE, FCC
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Optional Resistive Touch
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core 12th Gen Alder Lake
- Memory: 2x DDR5 4800MHz SO-DIMM Slot, 64GB
- OS: Linux Ubuntu 22.04, Windows 11
- Display Outputs: 1x Display Port
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230], 1x M.2 M-Key [PCIe] [2280]
- Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
- Power: 12V DC [4-Pin], AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- Certification: CE, FCC
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Optional Resistive Touch
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 14th Gen Raptor Lake Refresh, Intel Core 12th Gen Alder Lake
- Memory: 2x DDR5 4800MHz SO-DIMM Slot, 64GB
- OS: Linux Ubuntu 22.04, Windows 11
- Display Outputs: 1x Display Port
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
- M.2: 1x M.2 E-Key [2230], 1x M.2 M-Key [PCIe] [2280]
- Storage: 1x M.2 SSD, 2x 2.5" HDD/SSD
- Power: 12V DC [4-Pin], AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- Certification: CE, FCC
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Multi Touch PCAP
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 12th Gen Alder Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Ethernet: 1x GbE LAN [RJ45]
- USB: 2x USB 2.0 [M12]
- Serial: 1x RS232 [M12]
- Storage: 1x 2.5" HDD/SSD
- Power: 12V DC [M12]
- Temp: 0°C to 45°C [32°F to 113°F]
- IP Rating: IP69K
- Certification: CE, FCC
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Resistive Touch
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Processor N Series Twin Lake
- OS: Windows 11
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 1x USB 3.2 [Type C], 2x USB 3.2 [Type A]
- Serial: 1x RS232 [DB9]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 9-36V DC Input, AC Power Supply Included
- Temp: -15°C to 55°C [5°F to 131°F]
- IP Rating: Front IP66
- Certification: CE, FCC
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Multi Touch PCAP
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 12th Gen Alder Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Ethernet: 1x GbE LAN [RJ45]
- USB: 2x USB 2.0 [M12]
- Serial: 1x RS232 [M12]
- Storage: 1x 2.5" HDD/SSD
- Power: 12V DC [M12]
- Temp: 0°C to 45°C [32°F to 113°F]
- IP Rating: IP65
- Certification: CE, FCC
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Optional 5-Wire Resistive Touch
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 12th Gen Alder Lake
- OS: Linux Ubuntu 22.04, Windows 11
- USB: 1x USB 2.0 [MIL-STD]
- Serial: 2x RS232 [MIL-STD]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 100-240V AC, 9-36V DC Input [MIL-STD]
- Temp: -20°C to 60°C [-4°F to 140°F]
- Certification: CE, FCC, MIL-STD-461, MIL-STD-810
- Display: 17"[5:4, 1280 x 1024, SXGA]
- Touch: Optional Resistive Touch
- Brightness: 350
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 12th Gen Alder Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Ethernet: 1x GbE LAN [RJ45]
- USB: 2x USB 2.0 [M12]
- Serial: 1x RS232 [M12]
- Storage: 1x 2.5" HDD/SSD
- Power: 12V DC [M12]
- Temp: 0°C to 45°C [32°F to 113°F]
- IP Rating: IP65
- Certification: CE, FCC
17 Inch Panel PC Ranges Configured by Things Embedded
We work with the leading manufacturers of 5:4 operator stations, so the ranges below are the ones we specify for line control, SCADA clients and hosed-down cabinets. Compare them by sealing, processor and mounting, then browse the models above or ask a panel PC specialist which range suits your line.
IT3S Winmate Core-Class Panel Mount PCs
Fanless flush-mount HMIs on Intel Core i5 Tiger Lake from 10.4 to 23.8 inches, in standard and front IP65 builds, for control cabinets and consoles that need Core-class performance behind the screen.
IT7T Winmate Tiger Lake Panel Mount HMIs
Panel-mount touch computers on Intel Core i5 Tiger Lake from 15 to 23.8 inches, with resistive touch or a slim front IP65 PCAP bezel, for machine and console HMIs.
IT7T and IF7T Winmate Chassis-Mount Touch Computers
VESA and wall-mount units from 12.1 to 23.8 inches on Intel Pentium, Core i5 Tiger Lake or Core i3 to i7 Coffee Lake, with resistive touch and wide-temperature options, for arms, desks and walls.
IT7T and IE3S Winmate Open Frame Touch Computers
Housing-free modules from 7 to 23.8 inches with PCAP multi-touch, on Intel Celeron or Core i5 Tiger Lake with vPro, built to drop into kiosk, signage and OEM enclosures.
IE3S Winmate Stainless Steel Washdown PCs
Hygienic touch terminals from 10.1 to 23.8 inches in stainless steel on Intel Celeron N6210, in IP65 and full IP69K builds with M12 connectors, and push-button variants beside the screen.
IE3S Winmate IP65 and IP67 Stainless Chassis Computers
Sealed stainless chassis PCs on Intel Celeron N6210 from 10.4 to 23.8 inches, rated IP65 or IP67 with M12 connectors, for wipe-down and immersion-risk positions.
IT3S Winmate IP69K AISI 316 Stainless Panel PCs
Full IP69K AISI 316 stainless HMIs on Intel Core i5 Tiger Lake from 15 to 23.8 inches, with PCAP rain-mode touch for the wettest positions on the line.
Winmate ATEX and Class I Div 2 Panel PCs
Certified HMIs from 12.1 to 23.8 inches on Intel Atom, Celeron and Core i5, carrying UL Class I Division 2 with ATEX Zone 2 on selected models, for operator stations inside classified areas.
IT3S Winmate Marine Touch Computers
Front IP66 console computers on Intel Core i7 Tiger Lake from 12.1 to 24 inches, designed for bridge and engine room consoles.
DM Arestech Modular Panel PCs
Two-part systems built from a DM display and a PM-2000 Intel Celeron compute module, with PCAP touch and a front IP65 bezel, for panel or chassis mounting from 10.4 to 24 inches.
PPC-N Arestech Front IP66 HMIs
Fanless panel-mount computers with a front IP66 bezel in 15, 17 and 19 inch, on Intel Celeron, Pentium and Core i3 or i5, with PCAP or resistive touch for cabinet fronts on hosed-down lines.
VIO C&T Solution Modular Touch Computers
Modular HMIs that pair a VIO display with a fanless Intel Celeron compute module behind a front IP65 bezel, with resistive or PCAP touch, so the computer can be upgraded without changing the cabinet cut-out.
Not sure which range fits? Tell us the application and we will recommend the right model.
