Neousys NRU-162S-AWP NVIDIA Jetson Orin NX or Orin Nano IP66 Waterproof Computer with 4x M12 PoE+

Junctions, food lines and outdoor sites use IP and GigE cameras for AI inspection, and the computer often sits beside them in the weather. The Neousys NRU-162S-AWP is an IP66 waterproof computer for that job, with four Gigabit PoE+ ports on M12 X-coded connectors so the cameras run from one sealed cable each, in a small chassis that needs no enclosure. It is the PoE+ version of the NRU-160-AWP series.

The four camera ports run from an Intel I350-AM4 controller and supply IEEE 802.3at PoE+ from a 50 W total budget. Compute is an NVIDIA Jetson Orin NX with 8 or 16 GB LPDDR5, or an Orin Nano with 4 or 8 GB, bundled with JetPack. The Orin NX 16 GB reaches 100 sparse TOPS and transcodes up to eighteen 1080p streams. Storage is an M.2 2242 NVMe SSD on PCIe Gen3 x1.

A fifth Gigabit port on M12 X-coded links the NRU-162S-AWP to a host computer or LiDAR. Two USB 2.0 ports, a VGA output, an RS-232 port, a CAN FD port and an isolated GPS PPS input sit on M12 A-coded connectors, and a USB Type-C port under a service door handles flashing. A full-size mini PCIe socket takes a CAN, serial or Wi-Fi module, and an M.2 B key socket with dual micro SIM takes a 4G LTE or 5G NR module. EMC also meets EN 50121-3, the railway standard referenced by EN 50155.

Power is 8 to 35 V DC on an M12 A-coded connector with built-in ignition control, rising to 12 to 35 V above 60 W of system load and 20 to 35 V above 96 W. The unit runs fanless from -25 °C to 70 °C in the 20 W mode (to 60 °C in the 25 W MAXN mode), meets MIL-STD-810H for vibration and shock and carries CE and FCC Class A. The NRU-161V-AWP swaps the PoE+ ports for six GMSL2 camera inputs, and the NRU-230V-AWP / NRU-240S-AWP series moves to the Jetson AGX Orin for more AI performance.
