Winmate W15L100-MLB3FP 15.6″ Military Rack Mount PCAP Touch Monitor with 3840 x 2160 UHD LCD
PCAP
CE
FCCW15L100-MLB3FP Overview
Defense consoles need a screen that shows fine map and sensor detail, passes the programme’s environmental and EMC tests and fits the existing rack. The W15L100-MLB3FP is Winmate’s 15.6 inch defense display for that role: a 3840 x 2160 UHD LCD with projected capacitive multi-touch in a fanless metal rack mount enclosure, compliant with MIL-STD-810G and MIL-STD-461E/F/G.
The UHD panel runs at 500 nits with a 1400:1 contrast ratio, 1.07 billion colors and viewing angles of 178° horizontally and vertically. The PCAP touch screen supports multi-touch, with a PCAP ITO film version as an option, and connects over a USB touch port. The seven-key front control panel includes Day/Night and Lock/Unlock keys alongside brightness and menu controls.
Video inputs are VGA, DVI and DisplayPort 1.2, with HDMI 1.4 and HDMI 2.0 as options, and an optional RS-232 port supports remote control, alongside an optional audio line-in. Winmate lists radiated and conducted emission and susceptibility tests under MIL-STD-461E/F/G, with EMI glass and touch as an option. The R17L100-MLA1FP and W24L100-MLA2FP are 17 inch and 23.8 inch rack mount military monitors in the same range.
Power is 100 to 240 V AC universal input on a MIL-DTL-38999/1 connector, with 9 to 36 V DC as an option. Vibration, humidity and transit drop are covered by MIL-STD-810G Methods 514.6, 507.4 and 516.5. The monitor operates from 0 °C to 50 °C at 10 to 95% humidity, stores from -25 °C to 60 °C, weighs 8.5 kg, rack mounts by its front flanges or uses 100 x 100 mm VESA holes, and carries CE and FCC marks.
W15L100-MLB3FP Specifications
| Overview | |
|---|---|
| Brand & Model | Winmate W15L100-MLB3FP |
| Features | Fanless Industrial Rugged |
| Display | |
| Display | 15.6"[16:9, 3840 x 2160, UHD] |
| Touch Interface | USB |
| Touch Controller | Multi Touch PCAP |
| Brightness | 500 Nits |
| Viewing Angle | Wide Viewing Angle |
| 178° Horizontal, 178° Vertical | |
| Aspect Ratio | 16:9 |
| Format | Widescreen |
| Contrast | 1400:1 |
| Number of Display Inputs | 5x Display Ports |
| Video Inputs | 1x Display Port Input 1x DVI Input 1x VGA Input 2 x Optional HDMI |
| Power | |
| Power Input | 9-36V DC Input [MIL-STD] Optional AC Power Supply |
| Environmental Conditions | |
| Operating Temperature | 0°C to 50°C [32°F to 122°F] |
| Storage Temperature | -25°C to 60°C [-13°F to 140°F] |
| Humidity | 10% - 95% (Non-condensing) |
| Certification | CE FCC |
| Mechanical Properties | |
| Dimensions | 458mm x 288mm x 69mm (18.03" x 11.34" x 2.72") |
- W15L100-MLB3FP Datasheet Download
Official Winmate USA Distributor
Things Embedded is an official Winmate USA distributor, supplying the W15L100-MLB3FP configured for USA defense programs. Within the Winmate range the R17L100-MLA1FP is a 17 inch rack mount PCAP military display, and the W24L100-MLA2FP offers a 23.8 inch FHD rack mount touch monitor.
For defense consoles the W15L100-MLB3FP sits among our military monitors, our rack mount monitors and our 15 inch industrial monitors. Where a console needs UHD detail with MIL-STD-461 compliance, this is the model to specify.
