Yuan Dante AV Ultra to HDMI2.0 HDMI 2.0 Dante AV Decoder with Dante AV Ultra, 8-Channel Audio and PoE at 4K60
Dante AV Ultra to HDMI2.0 Overview
Where audio already runs on Dante, carrying video on the same network keeps an AV system on one set of switches and one control model. The Yuan Dante AV Ultra to HDMI2.0 is the receiving end of that link: an HDMI 2.0 Dante AV decoder that takes Dante AV Ultra from the network and drives a display, projector or recorder, which can suit pro AV installs in venues, campuses and corporate spaces.
Input is one gigabit RJ45 port carrying Dante AV Ultra. Output is one HDMI 2.0 port from 4096×2160 and 3840×2160 at 60fps down to 1080p, 720p, PC modes and 480i or 576i. Audio arrives as up to eight channels of 24-bit Dante audio at 32 to 192kHz, passed to HDMI as eight channels, with a two-channel analog output at 48kHz. The Dante AV Ultra to HDMI2.0 supports Dante AV Ultra only, so it pairs with Dante AV Ultra transmitters.
A web interface covers setup and firmware updates, with an LED indicator and DHCP. Two USB 2.0 ports take a keyboard and mouse. Power comes from PoE or a 7.5 to 15V DC input. The matching transmitter is the HDMI2.0 to Dante AV Ultra, and for sites that need NDI or SRT alongside Dante AV-H the SC6G0N1 IP to UVC/HDMI2.0 is a decoder with a wider protocol list.
Check the network switches are set up for Dante before installation, as that is where most commissioning time goes. We supply the Dante AV Ultra to HDMI2.0 configured and tested with the transmitters, displays and network it will connect to.
Dante AV Ultra to HDMI2.0 Specifications
| Overview | |
|---|---|
| Brand & Model | Yuan Dante AV Ultra to HDMI2.0 |
| Features | PoE Powered |
| I/O | |
| Ethernet | 1x Ethernet Ports |
| 1x GbE LAN [RJ45] [PoE-PD] | |
| USB | 2x USB Ports |
| 2x USB 2.0 [Type A] | |
| Video Capture | |
| Simultaneous Video Inputs | 1 |
| Video Input | 1x RJ45 (1G) |
| Video Output | 1x HDMI2.0 |
| Video Resolution Output | 4K60 [4096x2160p @ 60/50/30/25/24fps] |
| Recording Mode | Hardware Compression |
| Streaming Protocols | Dante AV Ultra |
| Audio Output | 1x 3.5mm Audio Output 1x HDMI Embedded Audio Output |
| Power | |
| Power Input | 7.5-15V DC PoE Powered Device (PD) [RJ45] |
Official Yuan USA Distributor
Things Embedded is an official Yuan USA distributor, and we supply the Dante AV Ultra to HDMI2.0 configured and tested with the sources, displays and network it will connect to. Within the Yuan range, the HDMI2.0 to Dante AV Ultra is the transmitter that feeds this decoder, and the SC6E0N1 IP/UVC to HDMI2.0 V2 decodes RTSP, SRT and optional Dante AV-H streams to HDMI 2.0 and 3G-SDI.
Across our range, the Dante AV Ultra to HDMI2.0 sits with our Dante AV encoders and decoders, our AV over IP and our video encoders and decoders.
