US Sunlight Readable Panel PCs
Sunlight Readable Touch Screen PCs for Outdoor and In-Cab Use
Sunlight readable panel PCs put a 1,000 nit high-brightness screen where daylight falls on the glass: open cabs, decks, yards and outdoor enclosures. Available from 10 to 19 inches with PCAP or resistive touch and sealing from a front IP65 bezel to fully sealed IP66 and IP67, they stay legible where a standard panel washes out.
Options include optical bonding and anti-glare glass, M12 connectors, wide-range DC input with ignition control, 4G and 5G modems and NVIDIA Jetson AI models for vision on the vehicle, suited to agriculture, marine, mining and mobile machinery where the HMI works outdoors all day.
Speak to a panel PC specialist to match the brightness, sealing and power input to your cab or site.
Browse Our Outdoor High-Brightness Panel PCs
- Display: 12.1"[4:3, 1024 x 768, XGA]
- Touch: Multi Touch PCAP
- Brightness: 1000, 500
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Genio 510
- Memory: 4GB Soldered On-board
- OS: Android 13.0, Linux Ubuntu 22.04
- Display Outputs: 1x Optional Micro HDMI
- Ethernet: 1x GbE LAN [RJ45]
- USB: 1x USB 2.0 [Type C], 2x USB 2.0 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- Storage: 1x Micro SD
- Power: 12V DC [Terminal Block]
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 12.3"[, 1920 x 720, FHD]
- Touch: Multi Touch PCAP
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Stretched
- CPU: Intel Celeron N Series Elkhart Lake
- Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
- OS: Linux Ubuntu 22.04, Windows 11
- Display Outputs: 1x Optional HDMI
- Ethernet: 2x GbE LAN [RJ45]
- USB: 1x USB 2.0 [Type A], 1x USB 3.2 Gen 1 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [2242]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 12V DC [Barrel Connector], AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 12.3"[, 1920 x 720, FHD]
- Touch: Multi Touch PCAP
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Stretched
- CPU: Intel Celeron N Series Elkhart Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Display Outputs: 1x Optional HDMI
- Serial: 1x RS232/422/485 [DB9]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 12V DC, AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 12.3"[, 1920 x 720, FHD]
- Touch: Multi Touch PCAP
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Stretched
- CPU: Intel Celeron N Series Elkhart Lake
- OS: Linux Ubuntu 20.04, Windows 10
- Ethernet: 1x GbE LAN [M12]
- USB: 1x USB 2.0 [M12]
- Serial: 1x RS232/422/485 [DB9]
- Storage: 1x M.2 SSD, 1x Micro SD
- Power: 10-60V DC Input
- Ignition Sensing: Supports Ignition Control
- Temp: -20°C to 60°C [-4°F to 140°F]
- IP Rating: IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 12.3"[, 1920 x 720, FHD]
- Touch: Multi Touch PCAP
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Stretched
- CPU: Genio 510
- Memory: 4GB Soldered On-board
- OS: Android 13.0, Linux Ubuntu 22.04
- Ethernet: 1x GbE LAN [M12]
- USB: 1x USB 2.0 [M12], 1x USB OTG [Type C]
- Serial: 1x RS232/422/485 [M12]
- Storage: 1x Micro SD
- Power: 10-60V DC Input
- Ignition Sensing: Supports Ignition Control
- Temp: -20°C to 60°C [-4°F to 140°F]
- IP Rating: IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 12.3"[, 1920 x 720, FHD]
- Touch: Multi Touch PCAP
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Stretched
- CPU: Genio 510
- Memory: 4GB Soldered On-board
- OS: Android 13.0, Linux Ubuntu 22.04
- Display Outputs: 1x Optional Micro HDMI
- Ethernet: 1x GbE LAN [RJ45]
- USB: 1x USB OTG [Micro USB], 2x USB 2.0 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- Storage: 1x Micro SD
- Power: 12V DC [Terminal Block]
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 15"[4:3, 1024 x 768, XGA]
- Touch: Multi Touch PCAP
- Brightness: 1000, 300
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 11th Gen Tiger Lake
- OS: Linux Ubuntu 22.04, Windows 10, Windows 11
- Serial: 1x RS232/422/485 [DB9]
- M.2: 1x M.2 M-Key [PCIe/SATA] [2242/2280]
- Storage: 1x M.2 SSD, 1x SATA Port
- Power: 12V DC, AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 15"[4:3, 1024 x 768, XGA]
- Touch: Multi Touch PCAP
- Brightness: 1000, 300
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Celeron N Series Elkhart Lake
- OS: Linux Ubuntu 24.04, Windows 11
- Ethernet: 1x GbE LAN [M12]
- USB: 1x USB 2.0 [M12]
- Serial: 1x RS232/422/485 [M12]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 9-36V DC Input [M12]
- Temp: -15°C to 55°C [5°F to 131°F]
- IP Rating: IP65
- Certification: CE, FCC, MIL-STD-810
- Mounting Options: VESA Mount
- Display: 15"[4:3, 1024 x 768, XGA]
- Touch: Optional Resistive Touch
- Brightness: 1000, 300
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Celeron N Series Elkhart Lake
- Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
- OS: Linux Ubuntu 22.04, Windows 11
- Display Outputs: 1x Optional HDMI
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 2x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232 [DB9], 1x RS232/422/485 [DB9]
- M.2: 1x M.2 B-Key [2242], 1x M.2 E-Key [2230]
- Storage: 1x M.2 SSD
- Power: 9-36V DC Input [Terminal Block]
- Ignition Sensing: Supports Ignition Control
- Temp: -10°C to 55°C [14°F to 131°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 15"[4:3, 1024 x 768, XGA]
- Touch: 5-Wire Resistive Touch
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Celeron N Series Elkhart Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Ethernet: 1x GbE LAN [RJ45]
- USB: 2x USB 2.0 [M12]
- Serial: 1x RS232 [M12]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 9-36V DC Input [M12]
- Temp: -10°C to 55°C [14°F to 131°F], -40°C to 55°C [-40°F to 131°F]
- IP Rating: IP67
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 15"[4:3, 1024 x 768, XGA]
- Touch: Multi Touch PCAP
- Brightness: 1000, 300
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Celeron N Series Elkhart Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Display Outputs: 1x Optional HDMI
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 2x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 12V DC, AC Power Supply Included
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 15"[4:3, 1024 x 768, XGA]
- Touch: Multi Touch PCAP
- Brightness: 1000, 550
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Atom X Series Elkhart Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Ethernet: 1x GbE LAN [M12]
- USB: 2x USB 2.0 [M12]
- Serial: 1x RS232/422/485 [M12]
- M.2: 1x M.2 B-Key [SATA] [2242], 1x M.2 E-Key [2230]
- Storage: 1x M.2 SSD
- Power: 9-36V DC Input [M12], AC Power Supply Included
- Temp: -20°C to 60°C [-4°F to 140°F]
- IP Rating: IP65
- Certification: ATEX Zone 2, CE, FCC, IC (ICES-003), IECEx, UL Class 1 Division 2
- Mounting Options: VESA Mount
- Display: 15"[4:3, 1024 x 768, XGA]
- Touch: Multi Touch PCAP
- Brightness: 1000, 300
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Genio 510
- Memory: 4GB Soldered On-board
- OS: Android 13.0, Linux Ubuntu 22.04
- Display Outputs: 1x Optional Micro HDMI
- Ethernet: 1x GbE LAN [RJ45]
- USB: 1x USB 2.0 [Type C], 2x USB 2.0 [Type A]
- Serial: 1x RS232/422/485 [DB9]
- Storage: 1x Micro SD
- Power: 12V DC [Terminal Block]
- Temp: 0°C to 50°C [32°F to 122°F]
- IP Rating: Front IP65
- Certification: CE, FCC
- Mounting Options: VESA Mount
- Display: 15"[4:3, 1024 x 768, XGA]
- Touch: Multi Touch PCAP
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Intel Core 12th Gen Alder Lake
- OS: Linux Ubuntu 22.04, Windows 11
- Ethernet: 1x GbE LAN [RJ45]
- USB: 2x USB 2.0 [M12]
- Serial: 1x RS232 [M12]
- Storage: 1x 2.5" HDD/SSD, 1x M.2 SSD
- Power: 9-36V DC Input [M12]
- Temp: -10°C to 55°C [14°F to 131°F], -40°C to 55°C [-40°F to 131°F]
- IP Rating: IP67
- Certification: CE, FCC
- Display: 15"[4:3, 1024 x 768, XGA]
- Touch: Multi Touch PCAP
- Brightness: 1000
- Viewing Angle: Wide Viewing Angle
- Format: Standard
- CPU: Genio 510
- Memory: 4GB Soldered On-board
- OS: Android 13.0, Linux Ubuntu 22.04
- Ethernet: 1x GbE LAN [RJ45]
- USB: 2x USB 2.0 [M12]
- Serial: 1x RS232 [M12]
- Storage: 1x Micro SD
- Power: 9-36V DC Input [M12]
- Temp: -10°C to 55°C [14°F to 131°F], -40°C to 55°C [-40°F to 131°F]
- IP Rating: IP67
- Certification: CE, FCC
- Mounting Options: VESA Mount
Sunlight Readable Panel PC Ranges Configured by Things Embedded
We work with the leading manufacturers of high-brightness HMIs, so the ranges below are the ones we specify for open cabs, decks, yards and rail. Compare them by brightness, sealing and power input, then browse the models above or ask a panel PC specialist which range suits your cab or site.
Winmate G-WIN Full IP67 Rugged HMIs
Fully sealed IP67 rugged computers in 15 and 19 inch on Intel Celeron or Core i5, with high-bright screens and M12 connectors, for decks, vehicles and outdoor sites.
Winmate Vehicle Mount Rugged Computers
In-cab touch computers from 8.4 to 15 inches on Intel Celeron or Core i5, with sunlight-readable high-bright options and wide-range DC input, for forklifts, cabs and mobile machinery.
Winmate ATEX and Class I Div 2 Panel PCs
Certified HMIs from 12.1 to 23.8 inches on Intel Atom, Celeron and Core i5, carrying UL Class I Division 2 with ATEX Zone 2 on selected models, for operator stations inside classified areas.
NRU Neousys NVIDIA Jetson AI Panel PCs
10.1 inch IP66 AI computers on NVIDIA Jetson Orin NX and Orin Nano, with a 1,000 nit screen, M12 connectors and PoE+ camera ports, for vision and AI at the machine or on the vehicle.
GOT700 Axiomtek EN 50155 Railway and Vehicle Computers
Fanless 10.4 to 15 inch cab computers on Intel Atom with resistive touch, a front IP65 bezel and M12 connectors, certified to EN 50155 for driver desks and crew terminals, plus a vehicle-mount variant.
Not sure which range fits? Tell us the application and we will recommend the right model.
What to Specify in a Sunlight Readable HMI
Our panel PC specialists specify every sunlight readable panel PC against the light, the weather and the vehicle supply. These are the choices that decide whether a screen stays legible in daylight, and the ones we work through with you before recommending a range.
1,000 Nits
High-brightness panels that stay readable in direct sun where standard screens wash out.
Optical Bonding
Bonded touch glass cuts internal reflections and condensation, improving contrast outdoors.
Vehicle Power
Wide-range DC input and ignition control for cabs and mobile machinery.
Sealing
IP66 and IP67 builds for decks, yards and open cabs.
Sunlight Readable Panel PC Innovation & Outdoor HMI Insights
Speak to a Panel PC Specialist.
Tell us where the panel PC will be mounted, what it needs to run and connect to and the sealing the area needs, and we will recommend the right size and touch technology, then configure, image and test it before it ships.
