US Managed Industrial Switches
Industrial Managed Switches with Layer 2 and Layer 3 Control
A managed industrial Ethernet switch lets you segment, prioritize and monitor the traffic in a cabinet or field network, so control data, video and IT traffic share the same cabling without getting in each other’s way. The range runs from five-port DIN-rail switches to 19-inch rackmount units, with SFP and 10G SFP+ uplinks, Layer 2+ static routing and full Layer 3 on selected models.
Options include VLANs, QoS, IGMP snooping, ERPS ring recovery in under 50 ms, Modbus TCP for PLC monitoring, PoE+ and PoE++ ports, and IEC 61850-3 and NEMA TS2 compliance on listed models, suited to factories, utilities, transport and surveillance networks where one fault must not take the whole line down.
Speak to an industrial networking specialist to plan the VLANs, redundancy and uplinks for your network.
Browse Our DIN Rail Managed Switches
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 16x 10/100/1000 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE+ 30W [802.3at]
- Power: 48-55V DC, Terminal Block
- IP Rating: IP30
- Certification: CE, FCC, IEC 61850-3, NEMA TS2, RoHS, UL 61010-1
- Mounting Options: Wall Mount
- Temp: -10°C to 70°C [14°F to 158°F]
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 4x 10/100/1000 BASE-TX [PoE++] [RJ45], 4x 10/100/1000 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE++ 90W [802.3bt]
- Fiber: 4x 100/1000 [SFP]
- Fiber Connectors: SFP
- Power: 12-55V DC [Terminal Block]
- Temp: -40°C to 75°C [-40°F to 167°F]
- IP Rating: IP30
- Certification: CE, FCC, RoHS
- Mounting Options: Wall Mount
-
LMP-1204G-SFP-bt-T-CC
LMP-1204G-SFP-bt-T-CC with 4x 90W PoE++, 4x SFP, conformal coating and -40 to 75°C -
LMP-1204G-SFP-bt
LMP-1204G-SFP-bt with 4x 90W PoE++, 4x PoE+, 4x SFP and 48-55V DC -
LMP-1204G-SFP-bt-24
LMP-1204G-SFP-bt-24 with 4x 90W PoE++, 4x PoE+, 4x SFP and 12-55V DC -
LMP-1204G-SFP-bt-24-T
LMP-1204G-SFP-bt-24-T with 4x 90W PoE++, 4x SFP, 12-55V DC and -40 to 75°C -
LMP-1204G-SFP-bt-T
LMP-1204G-SFP-bt-T with 4x 90W PoE++, 4x PoE+, 4x SFP and -40 to 75°C
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 4x 10/100/1000 BASE-TX [PoE++] [RJ45], 4x 10/100/1000 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE++ 90W [802.3bt]
- Fiber: 4x 100/1000 [SFP]
- Fiber Connectors: SFP
- IP Rating: IP30
- Mounting Options: Wall Mount
- Power: 48-55V DC, Terminal Block
- Temp: -40°C to 75°C [-40°F to 167°F]
- Certification: CE, FCC, NEMA TS2, RoHS, UL 61010-1
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 4x 10/100/1000 BASE-TX [PoE++] [RJ45], 4x 10/100/1000 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE++ 90W [802.3bt]
- Fiber: 4x 100/1000 [SFP]
- Fiber Connectors: SFP
- Power: 48-55V DC, Terminal Block
- Temp: -40°C to 75°C [-40°F to 167°F]
- IP Rating: IP30
- Certification: CE, FCC, RoHS
- Mounting Options: Wall Mount
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 8x 10/100/1000 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE+ 30W [802.3at]
- Fiber: 4x 100/1000 [SFP]
- Fiber Connectors: SFP
- Power: 48-55V DC, Terminal Block
- IP Rating: IP30
- Certification: ATEX Zone 2, CE, FCC, NEMA TS2, RoHS, UL 61010-1, UL Class 1 Division 2
- Mounting Options: Wall Mount
- Temp: -40°C to 75°C [-40°F to 167°F]
-
LMP-1202M-SFP-24
LMP-1202M-SFP-24 with 8x 10/100 PoE+, 2x SFP and 12-55V DC input -
LMP-1202M-SFP
LMP-1202M-SFP with 8x 10/100 PoE+ (240W), 2x Gigabit RJ45 and 2x SFP -
LMP-1202M-SFP-24-T
LMP-1202M-SFP-24-T with 8x 10/100 PoE+, 2x SFP, 12-55V DC and -40 to 75 °C -
LMP-1202M-SFP-T
LMP-1202M-SFP-T with 8x 10/100 PoE+ (240W), 2x SFP and -40 to 75 °C operation
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 2x 10/100/1000 BASE-TX [RJ45], 8x 10/100 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE+ 30W [802.3at]
- Fiber: 2x 100/1000 [SFP]
- Fiber Connectors: SFP
- IP Rating: IP30
- Certification: CE, FCC, NEMA TS2, RoHS, UL 61010-1, UL Class 1 Division 2
- Mounting Options: Wall Mount
- Power: 12-55V DC [Terminal Block]
- Temp: -10°C to 70°C [14°F to 158°F]
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 2x 10/100/1000 BASE-TX [RJ45], 8x 10/100/1000 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE+ 30W [802.3at]
- Fiber: 2x 100/1000 [SFP]
- Fiber Connectors: SFP
- Power: 48-55V DC, Terminal Block
- IP Rating: IP30
- Certification: ATEX Zone 2, CE, FCC, NEMA TS2, RoHS, UL 61010-1, UL Class 1 Division 2
- Mounting Options: Wall Mount
- Temp: -10°C to 70°C [14°F to 158°F]
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 8x 10/100/1000 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE+ 30W [802.3at]
- Fiber: 2x 100/1000 [SFP]
- Fiber Connectors: SFP
- Power: 12-55V DC [Terminal Block]
- IP Rating: IP30
- Certification: ATEX Zone 2, CE, FCC, NEMA TS2, RoHS, UL 61010-1, UL Class 1 Division 2
- Mounting Options: Wall Mount
- Temp: -10°C to 70°C [14°F to 158°F]
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 8x 10/100/1000 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE+ 30W [802.3at]
- Fiber: 2x 100/1000 [SFP]
- Fiber Connectors: SFP
- Power: 48-55V DC, Terminal Block
- IP Rating: IP30
- Certification: ATEX Zone 2, CE, FCC, NEMA TS2, RoHS, UL 61010-1, UL Class 1 Division 2
- Mounting Options: Wall Mount
- Temp: -10°C to 70°C [14°F to 158°F]
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 8x 10/100/1000 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE+ 30W [802.3at]
- Fiber: 2x 1G/10G [SFP+]
- Fiber Connectors: SFP
- Power: 12-55V DC [Terminal Block]
- Temp: -40°C to 60°C [-40°F to 140°F]
- IP Rating: IP30
- Certification: CE, FCC, RoHS, UL 61010-1
- Mounting Options: Wall Mount
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 4x 10/100/1000 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE+ 30W [802.3at]
- Fiber: 4x 100/1000 [SFP]
- Fiber Connectors: SFP
- Power: 48-55V DC, Terminal Block
- IP Rating: IP30
- Certification: CE, FCC, RoHS, UL 61010-1
- Mounting Options: Wall Mount
- Temp: -40°C to 75°C [-40°F to 167°F]
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 8x 10/100/1000 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE+ 30W [802.3at]
- Power: 48-55V DC, Terminal Block
- IP Rating: IP30
- Certification: CE, FCC, RoHS, UL 61010-1
- Mounting Options: Wall Mount
- Temp: -40°C to 75°C [-40°F to 167°F]
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 8x 10/100/1000 BASE-TX [PoE+] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE+ 30W [802.3at]
- Power: 12-55V DC [Terminal Block]
- IP Rating: IP30
- Certification: CE, FCC, RoHS, UL 61010-1
- Mounting Options: Wall Mount
- Temp: -40°C to 75°C [-40°F to 167°F]
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 1x 10/100/1000 BASE-TX [RJ45], 4x 10/100/1000 BASE-TX [PoE++] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE++ 90W [802.3bt]
- Fiber: 2x 100/1000 [SFP]
- Fiber Connectors: SFP
- Power: 48-55V DC, Terminal Block
- IP Rating: IP30
- Certification: CE, FCC, RoHS
- Mounting Options: Wall Mount
- Temp: -40°C to 75°C [-40°F to 167°F]
- Mounting Options: DIN Mount
- Switch Type: Managed
- Ethernet: 1x 10/100/1000 BASE-TX [RJ45], 4x 10/100/1000 BASE-TX [PoE++] [RJ45]
- Ethernet Connectors: RJ45
- PoE Standard: PoE++ 90W [802.3bt]
- Fiber: 2x 100/1000 [SFP]
- Fiber Connectors: SFP
- Power: 12-55V DC [Terminal Block]
- IP Rating: IP30
- Certification: CE, FCC, RoHS
- Mounting Options: Wall Mount
- Temp: -40°C to 75°C [-40°F to 167°F]
Managed Industrial Switch Ranges Supplied by Things Embedded
We work with a leading manufacturer of managed industrial switches, so the ranges below are the ones we specify for plant and field networks. Compare them by ports, uplinks and PoE, then browse the models above or ask an industrial networking specialist which suits your network.
LMX and QMX Antaira Managed Switches
Managed switches with VLANs, QoS and ERPS ring redundancy, Layer 2+ or Layer 3 routing and SFP or 10G SFP+ uplinks.
LMP and QMP Antaira Managed PoE Switches
Managed PoE+ and PoE++ switches with budgets up to 720 W, ERPS ring redundancy and SFP or 10G SFP+ uplinks.
Not sure which range fits? Tell us the application and we will recommend the right model.
What to Specify in an Industrial Managed Switch
Our industrial networking specialists work through these choices with you before recommending a managed switch.
Layer 2 or Layer 3
VLANs, QoS and IGMP snooping at Layer 2; static routing at Layer 2+; OSPF, RIP and VRRP on full Layer 3 models.
Ring Redundancy
ERPS recovers a broken fiber or copper ring in under 50 ms.
Ports and 10G Uplinks
Gigabit or Fast Ethernet copper for devices, SFP and 10G SFP+ for uplinks back to the core.
PoE Budget
PoE+ models power cameras and access points from the same switch.
Redundant DC Input
Dual DC inputs protect the network against a supply failure.
Substation and Traffic Approvals
IEC 61850-3 and NEMA TS2 compliance on listed models for substations and roadside cabinets.
Explore Our Network Switches by Type
Compare every networking category, from board-level switch modules to sealed rugged switches and DIN-rail PoE switches, and go straight to the switches that fit your system.
Managed Industrial Switch Innovation & Network Design Insights
Speak to an Industrial Networking Specialist.
Tell us the devices the switch must connect, the vehicle, enclosure or cabinet it goes into and the power and temperature it has to handle. We will recommend the right switch, supply it with the manufacturer's documentation and support you as you bring it into your system.
