NVIDIA Jetson PoE Systems

Our NVIDIA Jetson PoE embedded systems and carrier boards are pre-configured with Nano, TX2, Xavier, and Orin SOMs onboard to power sensors and cameras.

Loading...

Performance

I/O

Expansion

Storage

Power

Environmental Conditions

Displaying of 27 items
View All
  • SOM: Orin NX
  • OS: Linux
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 1 x GbE LAN [RJ45] [PoE-PD], 1 x GbE LAN [RJ45] [PoE], 4 x GbE LAN [RJ45] [PoE]
  • USB: 4 x USB 3.1 Gen 1 [Type A]
  • Serial: 2 x RS485 [DB9]
  • CANbus: 2x CANbus [Terminal Block]
  • M.2: 1x M.2 B-Key [USB] [3042/3052], 1x M.2 E-Key [USB/PCIe] [2230], 1x M.2 M-Key [PCIe x4] [2280]
  • Storage: 1x M.2 SSD
  • Power: 9-48V DC Input [Terminal Block], PoE Powered Device (PD) [RJ45]
  • Temp: -20°C to 60°C [-4°F to 147°F]
  • Certification: CE, FCC

AIE110-XNX

Nvidia Xavier NX Carrier Board

  • SOM: Xavier NX
  • OS: Linux
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 1 x GbE LAN [RJ45], 1 x GbE LAN [RJ45] [PoE]
  • USB: 1 x USB 2.0 [Type A], 1 x USB 3.2 Gen 2 [Type A]
  • M.2: 1x M.2 M-Key [PCIe x4] [2280]
  • mPCIe: 1 x mPCIe [PCIe/USB]
  • Storage: 1x M.2 SSD, 1x Micro SD
  • Power: 12V DC [Barrel Connector]
  • Temp: -10°C to 60°C [14°F to 147°F]
  • Certification: CE, FCC
  • SOM: Orin NX
  • OS: Linux
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 1 x GbE LAN [RJ45], 1 x GbE LAN [RJ45] [PoE]
  • USB: 1 x USB 2.0 [Type A], 1 x USB 3.2 Gen 2 [Type A]
  • M.2: 1x M.2 M-Key [PCIe x4] [2280]
  • mPCIe: 1 x mPCIe [PCIe/USB]
  • Storage: 1x M.2 SSD
  • Power: 12V DC [Barrel Connector]
  • Temp: -10°C to 60°C [14°F to 147°F]
  • Certification: CE, FCC
  • SOM: Orin Nano
  • OS: Linux
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 1 x GbE LAN [RJ45], 1 x GbE LAN [RJ45] [PoE]
  • USB: 1 x USB 2.0 [Type A], 1 x USB 3.2 Gen 2 [Type A]
  • M.2: 1x M.2 M-Key [PCIe x4] [2280]
  • mPCIe: 1 x mPCIe [PCIe/USB]
  • Storage: 1x M.2 SSD
  • Power: 12V DC [Barrel Connector]
  • Temp: -10°C to 60°C [14°F to 147°F]
  • Certification: CE, FCC

AIE510-ONX

Industrial Jetson Orin NX Box PC with PoE

  • SOM: Orin NX
  • OS: Linux
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 1 x 2.5 GbE LAN [RJ45] [PoE], 1 x GbE LAN [RJ45] [PoE]
  • USB: 2 x USB 3.2 Gen 2 [Type A]
  • Serial: 1 x RS232/422/485 [DB9]
  • M.2: 1x M.2 B-Key [PCIe x1/USB/SIM] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4] [2280]
  • mPCIe: 1 x mPCIe [PCIe/USB]
  • Storage: 1x M.2 SSD
  • Power: 24V DC
  • Temp: -25°C to 60°C [-13°F to 147°F]
  • Certification: CE, FCC
  • Mounting Options: DIN Mount, VESA Mount, Wall Mount
  • SOM: Orin NX
  • Simultaneous Video Inputs: 1
  • Video Input: 1x 12G-SDI
  • Video Output: 1x 12G-SDI
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 2x HDMI
  • Ethernet: 1 x GbE LAN [RJ45], Optional PoE Modules
  • USB: 1 x USB 3.0 [Board], 1 x USB 3.2 Gen 1 [Board], 4 x USB 3.2 Gen 2 [Type A]
  • Serial: 1 x RS232 [Board], 1 x RS485 [Board]
  • M.2: 1x M.2 M-Key [PCIe x1] [2280], 1x M.2 M-Key [PCIe x4] [2280]
  • Power: 24V DC
  • Temp: 0°C to 60°C [32°F to 147°F]
  • Certification: CE, FCC, UKCA
  • SOM: Orin Nano
  • OS: Linux
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 2 x GbE LAN [RJ45], 2 x GbE LAN [RJ45] [PoE]
  • USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
  • Serial: 1 x RS232 [DB9], 1 x RS232/422/485 [DB9]
  • CANbus: 1 x CANbus [Board]
  • M.2: 1x M.2 B-Key [PCIe x2/USB 3.0/SATA] [2280/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 M-Key [PCIe x4/SATA] [2280]
  • Storage: 1x Micro SD, 2x M.2 SSD
  • Power: 12-36V DC Input [Terminal Block], 20V [USB-C]
  • Temp: -25°C to 60°C [-13°F to 147°F]
  • Certification: CE, FCC
  • Mounting Options: DIN Mount, VESA Mount, Wall Mount
  • SOM: Orin NX
  • OS: Linux
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 2 x GbE LAN [RJ45], 2 x GbE LAN [RJ45] [PoE]
  • USB: 2 x USB 2.0 [Type A], 2 x USB 3.2 Gen 2 [Type A]
  • Serial: 1 x RS232 [DB9], 1 x RS232/422/485 [DB9]
  • CANbus: 1 x CANbus [Board]
  • M.2: 1x M.2 B-Key [PCIe x2/USB 3.0/SATA] [2280/3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 M-Key [PCIe x4/SATA] [2280]
  • Storage: 1x Micro SD, 2x M.2 SSD
  • Power: 12-36V DC Input [Terminal Block], 20V [USB-C]
  • Temp: -25°C to 60°C [-13°F to 147°F]
  • Certification: CE, FCC
  • Mounting Options: DIN Mount, VESA Mount, Wall Mount
  • SOM: Orin NX
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [RJ45] [PoE]
  • USB: 3 x USB 3.1 [Type A]
  • Serial: 2x RS232/422/485 [DB9]
  • CANbus: 1 x CANbus, DB9
  • M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 1x M.2 M-Key [PCIe x4] [2280], 2x M.2 B-Key [USB] [3042/3052]
  • Storage: 1x M.2 SSD, 1x Micro SD
  • Power: 9-50V DC Input [Terminal Block]
  • Ignition Sensing: Supports Ignition Control
  • Temp: -20°C to 70°C [-4°F to 158°F]
  • Certification: CE, EN50155, FCC
  • Mounting Options: DIN Mount, Wall Mount
  • SOM: AGX Orin
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [RJ45] [PoE]
  • USB: 1 x USB 3.2 Gen 2 [Type A], 4 x USB 3.1 Gen 1 [Type A]
  • Serial: 2x RS232/422/485 [DB9]
  • CANbus: 2 x Isolated CANbus, DB9
  • M.2: 1x M.2 B-Key [PCIe x2/USB 3.0/SATA] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 M-Key [PCIe x4/SATA] [2280]
  • PCIe: 1x PCIe [x8 Slot][Gen4]
  • Storage: 1x Micro SD, 2x M.2 SSD, 64GB eMMC
  • Power: 9-50V DC Input, Terminal Block
  • Ignition Sensing: Supports Ignition Control
  • Temp: -20°C to 70°C [-4°F to 158°F]
  • Certification: CE, EN50121-3-2, EN50155, FCC
  • Mounting Options: Desktop, DIN Mount, Wall Mount
  • SOM: AGX Orin
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 2 x GbE LAN [RJ45], 4 x GbE LAN [RJ45] [PoE]
  • USB: 1 x USB 3.2 Gen 2 [Type A], 4 x USB 3.1 Gen 1 [Type A]
  • Serial: 2x RS232/422/485 [DB9]
  • CANbus: 2 x Isolated CANbus, DB9
  • M.2: 1x M.2 B-Key [PCIe x2/USB 3.0/SATA] [3042/3052], 1x M.2 E-Key [PCIe x1/USB 2.0] [2230], 2x M.2 M-Key [PCIe x4/SATA] [2280]
  • PCIe: 1x PCIe [x8 Slot][Gen4]
  • Storage: 1x Micro SD, 2x M.2 SSD, 64GB eMMC
  • Power: 9-50V DC Input, Terminal Block
  • Ignition Sensing: Supports Ignition Control
  • Temp: -20°C to 70°C [-4°F to 158°F]
  • Certification: CE, EN50121-3-2, EN50155, FCC
  • Mounting Options: Desktop, DIN Mount, Wall Mount
  • SOM: Orin Nano
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 1 x GbE LAN [RJ45], 1 x GbE LAN [RJ45] [PoE]
  • USB: 1 x USB 2.0 [Type A], 1 x USB 3.2 Gen 2 [Type A]
  • M.2: 1x M.2 M-Key [PCIe x4] [2280]
  • mPCIe: 1 x mPCIe [PCIe/USB]
  • Storage: 1x M.2 SSD
  • Power: 12V DC [Barrel Connector]
  • Temp: -30°C to 50°C [-22°F to 122°F]
  • Certification: CE, FCC
  • Mounting Options: DIN Mount, Wall Mount

Axiomtek

AIE900-XNX

AMR Jetson Xavier NX Automotive Computer with 4 PoE and FPD-LINK III

AIE900-XNX

AMR Jetson Xavier NX Automotive Computer with 4 PoE and 4 FPD-LINK III

  • SOM: Xavier NX
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 1 x GbE LAN [RJ45] [PoE], 4 x GbE LAN [RJ45] [PoE]
  • USB: 2 x USB 3.2 Gen 2 [Type A]
  • Serial: 2x RS232/422/485 [DB9]
  • M.2: 1x M.2 B-Key [PCIe/USB] [3042/3052], 1x M.2 M-Key [PCIe x4] [2280]
  • mPCIe: 1 x mPCIe [PCIe/USB]
  • Storage: 1x M.2 SSD
  • Power: 9-36V DC Input [Terminal Block]
  • Ignition Sensing: Supports Ignition Control
  • Temp: -30°C to 60°C [-22°F to 147°F]
  • Certification: CE, FCC
  • Mounting Options: DIN Mount, VESA Mount, Wall Mount

Axiomtek

AIE800-904-FL

AC Powered Outdoor Waterproof NVIDIA Jetson Xavier NX Embedded System

AIE800-904-FL

AC Powered Outdoor Waterproof NVIDIA Jetson Xavier NX Embedded System

  • SOM: Xavier NX
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 1 x GbE LAN [M12] [PoE]
  • USB: 1 x USB 2.0 [C3]
  • M.2: 1x M.2 M-Key [PCIe x4] [2280]
  • mPCIe: 1 x mPCIe [PCIe/USB]
  • Storage: 1x M.2 SSD, 1x Micro SD
  • Power: 100-240V AC [M12]
  • Temp: -30°C to 50°C [-22°F to 122°F]
  • Certification: CE, FCC
  • Mounting Options: VESA Mount, Wall Mount

AIE800-904-FL-DC

Rugged IP67 NVIDIA Jetson Xavier NX Computer with GbE PoE

  • SOM: Xavier NX
  • AI Accelerator: NVIDIA Jetson SOM
  • Display Outputs: 1x HDMI
  • Ethernet: 1 x GbE LAN [M12] [PoE]
  • USB: 1 x USB 2.0 [C3]
  • M.2: 1x M.2 M-Key [PCIe x4] [2280]
  • mPCIe: 1 x mPCIe [PCIe/USB]
  • Storage: 1x M.2 SSD, 1x Micro SD
  • Power: 9-36V DC Input [M12]
  • Temp: -30°C to 50°C [-22°F to 122°F]
  • Certification: CE, FCC
  • Mounting Options: VESA Mount, Wall Mount
Displaying of 27 items

Need Help Choosing a NVIDIA Jetson PoE Solution?

Tell us about your application and a member of the team will get right back to you.
