Intel N97, N150 and i3-N305 Fanless Computers and SBCs
Intel Processor N and Core i3-N are low-power processors built from efficient cores only: two on the N50, four on the Intel N97 and N150 and eight on the Core i3-N305, at 6 to 15 W. That is enough for gateways, signage, kiosks and camera recording in a small fanless computer, and the range covers ultra-compact box PCs, IP67 waterproof PCs, expansion box PCs and 3.5-inch SBCs.
Options include Alder Lake-N and Twin Lake processors, single-channel DDR5, 2.5GbE, PoE+ for cameras, COM and digital I/O ports, Wi-Fi 6E and wide DC input, suited to retail, digital signage, logistics, in-vehicle and surveillance systems where power, heat and size matter more than peak performance.
Speak to an Intel Processor N specialist to match the processor, the I/O and the enclosure to your application.
Browse Our Alder Lake-N and Twin Lake Computers
-
TWLF51-BT-86N10
TWLF51 with Intel N100, quad-core Alder Lake-N, 8 GB LPDDR5 and 64 GB eMMC -
TWLF51-BT-86N15
TWLF51 with Intel N150, quad-core at 6 W, 8 GB LPDDR5 and 64 GB eMMC -
TWLF51-BT-86N35
TWLF51 with Intel Core 3 N355, eight cores, 8 GB LPDDR5 and 64 GB eMMC -
TWLF51-EC-86X72
TWLF51 with Intel Atom x7211RE, dual-core at 6 W and -20 to 70 °C -
TWLF51-EC-86X7213RE
TWLF51 with Intel Atom x7213RE, dual-core 2.0 GHz base, -20 to 70 °C -
TWLF51-EC-86X74
TWLF51 with Intel Atom x7433RE, four cores at 9 W and -20 to 70 °C -
TWLF51-EC-86X78
TWLF51 with Intel Atom x7835RE, eight cores and -20 to 70 °C
- Memory: 8GB Soldered On-board
- OS: Linux, Windows 11
- Display Outputs: 1x HDMI
- Ethernet: 1x GbE LAN [RJ45]
- USB: 2x USB 2.0 [Board], 2x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [Board]
- M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
- Storage: 64GB eMMC
- Power: 12V DC [Terminal Block]
- Certification: CE, FCC, RoHS, UKCA
- CPU: Intel Processor N Series Alder Lake
- Temp: -5°C to 65°C [23°F to 149°F]
- OS: Linux, Windows 10, Windows 11
- Ethernet: 1x 2.5 GbE LAN [Board]
- USB: 8x USB 2.0 [Board], 2x USB 3.2 Gen 2 [Board]
- Temp: -5°C to 65°C [23°F to 149°F]
- Certification: CE, FCC
- CPU: Intel Processor N Series Alder Lake
- Memory: 8GB Soldered On-board
- CPU: Intel Atom X Series Amston Lake, Intel Processor N Series Twin Lake
- Memory: 1x DDR5 4800MHz SO-DIMM, 16GB
- OS: Linux, Windows 10, Windows 11
- Display Outputs: 2x HDMI
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- M.2: 1x M.2 B-Key [PCIe x1/USB/SIM] [3042/3052], 1x M.2 E-Key [2230]
- Storage: 1x M.2 SSD [SATA]
- Power: 19-36V DC [Terminal Block]
- Temp: -40°C to 70°C [-40°F to 158°F]
- Certification: IEC 62368-1, CE, FCC, UKCA
- Mounting Options: DIN Mount, VESA Mount, Wall Mount
- USB: 2x USB 2.0 [Type A], 2x USB 3.2 Gen 1 [Type A]
- Serial: 1x RS232 [DB9], 2x RS232/422/485 [DB9]
- CPU: Intel Processor N Series Alder Lake
- Memory: 1x DDR5 4800MHz SO-DIMM, 16GB
- OS: Linux, Windows 10, Windows 11
- Display Outputs: 1x Display Port, 1x HDMI
- Ethernet: 2x GbE LAN [RJ45]
- USB: 2x USB 2.0 [Type A], 2x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS422/485 [DB9], 1x RS232/422/485 [DB9], 3x RS232 [DB9]
- M.2: 1x M.2 M-Key [SATA] [2280]
- PCIe: 1x PCIe [x4 Slot] [1-Lane Signal] [Gen3], 1x PCIe [x4 Slot] [Gen3]
- Storage: 1x M.2 SSD [SATA]
- Power: 12-24V DC [Terminal Block]
- Temp: -10°C to 70°C [14°F to 158°F]
- Certification: CE, FCC
- Mounting Options: Wall Mount
- CPU: Intel Atom X Series Alder Lake
- Memory: 1x DDR5 4800MHz SO-DIMM, 16GB
- OS: Linux, Windows 10, Windows 11
- Display Outputs: 2x HDMI
- USB: 2x USB 3.2 Gen 1 [Type A], 2x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS422/485 [DB9], 1x RS232/422/485 [DB9], 3x RS232 [DB9]
- M.2: 1x M.2 M-Key [SATA] [2280]
- Storage: 1x M.2 SSD [SATA]
- Power: 8-35V DC [Terminal Block]
- Temp: -25°C to 70°C [-13°F to 158°F]
- Certification: CE, FCC
- Mounting Options: DIN Mount, Wall Mount
- Ethernet: 3x 2.5 GbE LAN [RJ45]
- CPU: Intel Processor N Series Alder Lake
- Memory: 1x DDR5 4800MHz SO-DIMM, 16GB
- OS: Linux, Windows 10, Windows 11
- Ethernet: 2x 2.5 GBe LAN [M12]
- Serial: 1x RS422/485 [M12], 1x RS232 [M12]
- CANbus: 1x Isolated CANbus, M12
- M.2: 1x M.2 M-Key [PCIe x4 Gen3 / SATA] [2280]
- mPCIe: 1x mPCIe [PCIe/USB/SIM]
- Storage: 1x M.2 SSD [PCIe & SATA]
- Power: 8-35V DC [M12]
- Ignition Sensing: Supports Ignition Control
- Temp: -25°C to 70°C [-13°F to 158°F]
- Certification: IEC 62368-1, CE, FCC, UL 62368-1
- Mounting Options: DIN Mount, Wall Mount
- IP Rating: IP67
- Memory: 1x DDR5 4800MHz SO-DIMM, 16GB
- OS: Linux, Windows 10, Windows 11
- Display Outputs: 1x Display Port, 1x HDMI
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [DB9], 3x RS232 [DB9]
- M.2: 1x M.2 M-Key [PCIe x1/SATA] [2280]
- mPCIe: 1x mPCIe [PCIe/USB/SIM]
- Storage: 1x M.2 SSD [PCIe & SATA]
- Power: 8-35V DC [Terminal Block]
- Ignition Sensing: Supports Ignition Control
- Temp: -25°C to 60°C [-13°F to 140°F]
- Certification: CE, FCC
- Mounting Options: Wall Mount
- CPU: Intel Atom X Series Alder Lake
- Ethernet: 4x GbE LAN [RJ45]
- Memory: 1x DDR5 4800MHz SO-DIMM, 16GB
- OS: Linux, Windows 10, Windows 11
- Display Outputs: 1x Display Port, 1x HDMI
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232/422/485 [DB9], 3x RS232 [DB9]
- M.2: 1x M.2 M-Key [PCIe x1/SATA] [2280]
- mPCIe: 1x mPCIe [PCIe/USB/SIM]
- Storage: 1x M.2 SSD [PCIe & SATA]
- Ignition Sensing: Supports Ignition Control
- Temp: -25°C to 70°C [-13°F to 158°F]
- Mounting Options: DIN Mount, Wall Mount
- CPU: Intel Atom X Series Alder Lake
- Ethernet: 4x GbE LAN [RJ45]
- Power: 12-35V DC [Terminal Block]
- Certification: CE, FCC
- CPU: Intel Processor N Series Alder Lake
- Memory: 1x DDR5 4800MHz SO-DIMM, 16GB
- OS: Linux, Windows 10, Windows 11
- Display Outputs: 1x Display Port, 1x HDMI
- Ethernet: 1x 2.5 GbE LAN [RJ45], 4x GbE LAN [RJ45] [PoE]
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS422/485 [DB9], 1x RS232/422/485 [DB9], 2x RS232 [DB9]
- M.2: 1x M.2 M-Key [PCIe x1/SATA] [2280]
- mPCIe: 2x mPCIe [PCIe/USB]
- Storage: 1x M.2 SSD [PCIe], 1x M.2 SSD [SATA], 2x 2.5" HDD/SSD [SATA]
- Front Accessible Storage: Front Accessible Storage
- Hot Swappable Storage: Hot Swappable SSD Support
- RAID: RAID 0, RAID 1
- Power: 8-35V DC [Terminal Block]
- Ignition Sensing: Supports Ignition Control
- Temp: -10°C to 55°C [14°F to 131°F]
- Certification: CE, EN55032, FCC
- Mounting Options: DIN Mount, Wall Mount
- CPU: Intel Processor N Series Alder Lake
- Memory: 1x DDR5 4800MHz SO-DIMM, 16GB
- OS: Linux, Windows 10, Windows 11
- Display Outputs: 1x Display Port, 1x HDMI
- Ethernet: 4x GbE LAN [RJ45] [PoE]
- USB: 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS422/485 [DB9], 1x RS232/422/485 [DB9], 3x RS232 [DB9]
- CANbus: 2x Isolated CANbus, DB9
- M.2: 1x M.2 M-Key [SATA] [2280]
- mPCIe: 2x mPCIe [PCIe/USB]
- Storage: 1x M.2 SSD [SATA]
- Power: 8-35V DC [Terminal Block]
- Ignition Sensing: Supports Ignition Control
- Temp: -40°C to 70°C [-40°F to 158°F]
- Certification: CE, E-Mark, EN50121-3-2, EN50155, EN55032, FCC
- Mounting Options: Wall Mount
- CPU: Intel Processor N Series Alder Lake
- Memory: 1x DDR5 4800MHz SO-DIMM, 16GB
- OS: Linux Ubuntu 22.04, Windows 10, Windows 11
- Display Outputs: 1x Display Port, 1x HDMI
- USB: 2x USB 2.0 [Type A], 2x USB 3.2 Gen 1 [Type A]
- Serial: 2x RS232/422/485 [DB9]
- mPCIe: 1x mPCIe [PCIe/USB/SIM]
- Storage: 1x 2.5" HDD/SSD
- Power: 9-36V DC Input [Terminal Block]
- Ignition Sensing: Supports Ignition Control
- Temp: -40°C to 60°C [-40°F to 140°F]
- Certification: CE, FCC, UKCA
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- M.2: 1x M.2 E-Key [PCIe x1/USB 2.0] [2230]
- CPU: Intel Processor N Series Alder Lake
- Memory: 1x DDR4 3200MHz SO-DIMM Slot, 16GB
- OS: Linux
- Display Outputs: 1x eDP, 2x HDMI
- Ethernet: 2x 2.5 GbE LAN [RJ45]
- USB: 3x USB 2.0 [Board], 4x USB 3.2 Gen 2 [Type A]
- Serial: 1x RS232 [Board], 1x RS232/422/485 [Board]
- M.2: 1x M.2 M-Key [PCIe/SATA] [2242]
- mPCIe: 1x mPCIe [PCIe/USB/SIM]
- Storage: 1x M.2 SSD, 1x SATA Port
- Power: 12V DC [Barrel Connector]
- Temp: 0°C to 60°C [32°F to 140°F]
- Certification: CE, FCC, UKCA
All IntelBack to the full rangeIntel Processor N Ranges Configured by Things Embedded
We work with the leading manufacturers of low-power x86 computers and boards, so the ranges below are the ones we specify for gateways, signage and camera systems. Compare them by I/O, sealing and size, then browse the systems above or ask a specialist which range suits your application.
POC-700 Neousys Ultra-Compact Fanless Computers
Ultra-compact fanless computers on the Core i3-N305 with 4x PoE+, in standard, UL certified and flattop-heatsink builds for mounting against a cabinet wall.
POC-766AWP Neousys IP67 Waterproof Embedded PCs
Core i3-N305 computers sealed to IP67 in a stainless steel and aluminum chassis with M12 connectors, isolated serial, CAN and DIO, plus a developer kit for bench work.
POC-751VTC and POC-764VR Neousys In-Vehicle and Surveillance Computers
Core i3-N305 systems with 4x PoE+: the POC-751VTC for vehicles and the POC-764VR for camera recording with two 2.5-inch SSDs in RAID 0 or 1.
Nuvo-2822 Neousys Expansion Box PC
An Intel N97 compact industrial PC with two PCIe and two PCI slots, for acquisition and legacy I/O cards in a small chassis.
SBOX-2625 Sintrones Ultra-Compact Embedded Computers
Ultra-compact computers on the Intel N150 (Twin Lake) with builds for extra COM ports, 4-in 4-out digital I/O or 6x USB, for gateways and machine interfaces.
eBOX100A Axiomtek Fanless Compact Embedded Computers
Intel N97 fanless computers with two or four 2.5GbE ports, Wi-Fi 6E on the two-port build and -40 to 60 °C operation, for factory control and gateways.
X102 Nexcom 3.5-Inch SBCs
3.5-inch boards on the Intel N50 or N97 with dual 2.5GbE and triple display, for kiosks, signage players and HMIs.
Not sure which range fits? Tell us the application and we will recommend the right model.
What to Specify in an Intel N150 or N97 Computer
Our low-power computing specialists specify every Processor N system against the job, the I/O and the space it goes into. These are the choices we work through with you before recommending a range.
Processor and Power
N50 or N150 at 6 W for the coolest builds, the N97 for four faster cores, or the eight-core i3-N305 at 15 W.
Displays
Up to three independent displays on HDMI and DisplayPort for signage players, kiosks and HMIs.
Networking and PoE
2.5GbE ports, with PoE+ to power IP cameras on the recording and vehicle builds.
Serial and Digital I/O
COM, CAN and digital I/O ports for machines, meters and legacy controllers.
Sealing and Size
Ultra-compact fanless boxes, or IP67 waterproof builds with M12 connectors for outdoor sites.
Power Input
Wide DC input for vehicles, cabinets and PoE-powered installations.
Processor N Innovation & Low-Power Edge Insights
Speak to an Intel Processor N Specialist.
Tell us where the system will be installed, the approvals it must meet and the interfaces you need to connect. We will recommend the right form factor, then configure, image and test it before it ships.
